Page 3097 of 4323
SA249±03
F07266
Cutout
± SUSPENSION AND AXLEFRONT STABILIZER BAR
SA±93
3089 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL STABILIZER BAR LINKS
(a) Install the 2 bushings, retainers and stabilizer bar link to
the stabilizer bar.
(b) Hold the stabilizer bar link, and install a new nut.
Torque: 19 N´m (190 kgf´cm, 14 ft´lbf)
(c) Use the same procedures described above to the other
side.
2. INSTALL STABILIZER BAR
(a) Install the 2 bushings with their cutout facing to the rear-
ward of the stabilizer bar.
(b) Install the stabilizer bar and 2 brackets with the nuts and
bolts.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
3. CONNECT STABILIZER BAR LINKS TO LOWER SUS-
PENSION ARM
Torque: 69 N´m (700 kgf´cm, 51 ft´lbf)
HINT:
If the ball joint turns together with the nut, use a hexagon (6 mm)
wrench to hold the nut.
Page 3098 of 4323
SA17R±04
F14272
122 (1,244, 90)
Oil Seal
O±ring
Parking Brake Assembly
Disc Brake Caliper
Bearing Retainer
Speed Sensor Rotor
Snap Ring
Bearing Retainer
Spring Washer
Backing PlateSerration Bolt
Hub Bolt
Oil Deflector
GasketAxle Shaft
N´m (kgf´cm, ft´lbf): Specified torque
Non±reusable partx6
105 (1,070, 77)
15.5 (158, 11)
Clip
Parking Brake Cable
Hub Bolt
8.0 (82, 71 in.´lbf)
Bearing Assembly SA±94
± SUSPENSION AND AXLEREAR AXLE SHAFT
3090 Author: Date:
2005 SEQUOIA (RM1146U)
REAR AXLE SHAFT
COMPONENTS
Page 3099 of 4323

SA17S±04
F14273
SST
F14274
F14275
± SUSPENSION AND AXLEREAR AXLE SHAFT
SA±95
3091 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 110 N´m (1,150 kgf´cm, 83 ft´lbf)
2. DISCONNECT BRAKE LINE
Using SST, disconnect the brake line and remove the clip.
SST 09023±00101
Torque: 15.5 N´m (158 kgf´cm, 11 ft´lbf)
3. REMOVE BRAKE CALIPER AND DISC
Remove the 2 bolts, brake caliper and disc.
Torque: 105 N´m (1,070 kgf´cm, 77 ft´lbf)
4. CHECK BEARING BACKLASH AND AXLE SHAFT
DEVIATION
(a) Using a dial indicator, check the backlash in the bearing
shaft direction.
Maximum: 0.6 mm (0.024 in.)
If the backlash exceeds the maximum, replace the bearing.
(b) Using a dial indicator, check the deviation at the surface
of the axle shaft outside the hub bolt.
Maximum: 0.1 mm (0.0040 in.)
If the deviation exceeds the maximum, replace the axle shaft.
5. REMOVE PARKING BRAKE ASSEMBLY
(a) Remove the parking brake assembly (See page
BR±43).
(b) Remove the 2 bolts and pull out the parking brake cable
from the backing plate.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
(c) Use the same procedures described above to the other
side.
Page 3100 of 4323
F14276
SA±96
± SUSPENSION AND AXLEREAR AXLE SHAFT
3092 Author: Date:
2005 SEQUOIA (RM1146U)
6. REMOVE AXLE SHAFT ASSEMBLY
(a) Remove the 4 nuts.
Torque: 122 N´m (1,244 kgf´cm, 90 ft´lbf)
(b) Pull out the axle shaft assembly.
NOTICE:
Be careful not to damage the oil seal.
(c) Remove the O±ring from the axle housing.
Page 3101 of 4323

SA24A±02
F14277
F14278
F14279
F05103
SST
F14280
± SUSPENSION AND AXLEREAR AXLE SHAFT
SA±97
3093 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE BEARING RETAINER (DIFFERENTIAL SIDE)
AND SPEED SENSOR ROTOR
(a) Attach the 4 nuts to the serration bolts and remove the
serration bolts from the backing plate using a hammer.
NOTICE:
Do not reuse the nuts previously removed from the vehicle.
(b) Grind the retainer and sensor rotor surfaces using a grind-
er, then pry them out with a chisel and hammer.
2. REMOVE SNAP RING FROM AXLE SHAFT
Using a snap ring expander, remove the snap ring.
3. REMOVE REAR AXLE SHAFT FROM BACKING
PLATE AND BEARING ASSEMBLY
(a) Attach the washers and nut to the serration bolts, then
torque the nuts to install the serration bolts to the backing
plate.
(b) Remove the 4 nuts from the serration bolts.
(c) Position SST on the backing plate with the 4 nuts.
SST 09521±25011, 09521±25021
(d) Using a press, remove the rear axle shaft, spring washer
and bearing retainer from the backing plate.
(e) Remove the SST.
SST 09521±25011, 09521±25021
4. REMOVE OIL DEFLECTOR AND GASKET
Using a brass bar and hammer, remove the 6 hub bolts, oil de-
flector and gasket.
Page 3102 of 4323
F14282
SA±98
± SUSPENSION AND AXLEREAR AXLE SHAFT
3094 Author: Date:
2005 SEQUOIA (RM1146U)
5. REMOVE BEARING ASSEMBLY
Attach the 4 nuts to the serration bolts and remove the serration
bolts from the backing plate using a hammer.
NOTICE:
Do not reuse the nuts previously removed from the vehicle.
Page 3103 of 4323
SA17U±04
R12254
± SUSPENSION AND AXLEREAR AXLE SHAFT
SA±99
3095 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
INSPECT AXLE SHAFT
Using a dial indicator, measure the runout of the shaft and
flange.
Maximum shaft runout: 2.0 mm (0.079 in.)
Maximum flange runout: 0.1 mm (0.0040 in.)
If the rear axle shaft or flange are damaged or worn, or if runout
is greater than the maximum, replace the rear axle shaft.
Page 3104 of 4323
SA17V±06
F14283
SST
F05106
SST
SA±100
± SUSPENSION AND AXLEREAR AXLE SHAFT
3096 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACE OIL SEAL (INNER SIDE)
(a) Using SST, remove the oil seal.
SST 09308±00010
(b) Using SST and a hammer, install a new oil seal.
SST 09950±60020 (09951±00730),
09950±70010 (09951±07150)
(c) Apply MP grease to the oil seal lip.
