TOYOTA SEQUOIA 2001 Service Repair Manual DIDGO±01
A08841
Hand±held Tester
DLC3
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1151
1345 Author: Date:
2005 SEQUOIA (RM1146U)
CHECK MODE PROCEDURE
Using hand±held tester:
CHECK MODE (SIG

Page 1354 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDGP±01
DI±1152
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1346 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
HINT:
By accessing the DATA LIST displayed by the hand±held tester

Page 1355 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1153
1347 Author: Date:
2005 SEQUOIA (RM1146U)
2. DATA LIST FOR OCCUPANT CLASSIFICATION ECU
(a) Connect the hand±held tester to the DLC3.
(b) Turn

Page 1356 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±1154
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1348 Author: Date:
2005 SEQUOIA (RM1146U)
RL SENS RANGE
Rear left sensor range in-
formation/
OK: Sensor range is ±17
to 37 kg (±37.48 to 81.

Page 1357 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDGQ±01
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1155
1349 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
1. DTCS FOR SUPPLEMENTAL RESTRAINT SYSTEM
If a trouble code i

DIDGQ±01
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1155
1349 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
1. DTCS FOR SUPPLEMENTAL RESTRAINT SYSTEM
If a trouble code is displayed during the DTC check, check the circuit listed for the code in the table below
(Proceed to the page listed for that circuit).
HINT:
When the SRS warning light remains on and the DTC output is the normal system code, a voltage
source drop is likely to occur. This malfunction is not stored in the memory by the airbag sensor assem-
bly. If the power source voltage returns to normal, the SRS warning light will automatically go off.
When 2 or more codes are indicated, the code with the lower number appears first.
If a code is not listed on the display chart, the airbag sensor assembly may have failed.
In the case of any malfunction concerning an open circuit, short to ground, or short to B+ due to a squib,
other malfunction codes may not be detected. In this case, repair the malfunction currently indicated
and then perform malfunction diagnosis again.
Mark in the check mode column:
ºº: DTC is corresponding to the check mode.
º º: DTC is not corresponding to the check mode.
When the DTC B1650/32 is detected as a result of troubleshooting for the Supplemental Restraint Sys-
tem, perform troubleshooting for the occupant classification system as shown in the chart below.
DTC No.
(See
Page)
Detection ItemTrouble AreaCheck ModeSRS
Warning Light
B1000/31
(DI±1161)Airbag sensor assembly malfunctionAirbag sensor assemblyON
B1610/13
(DI±1162)Front airbag sensor RH malfunction
Front airbag sensor RH
Airbag sensor assembly
Cowl wire
Engine room main wire
ON
B1615/14
(DI±1171)Front airbag sensor LH malfunction
Front airbag sensor LH
Airbag sensor assembly
Cowl wire
Engine room main wire
ON
B1620/21
(*1)
(DI±1180)
Side airbag sensor assembly RH malfunction
Side airbag sensor assembly RH
Airbag sensor assembly
Floor wire
ON
B1625/22
(*1)
(DI±1186)
Side airbag sensor assembly LH malfunction
Side airbag sensor assembly LH
Airbag sensor assembly
Floor wire No. 2
ON
B1630/23
(*1)
(DI±1192)
Curtain shield airbag sensor RH malfunction
Curtain shield airbag sensor assembly RH
Airbag sensor assembly
Floor wire
ON
B1635/24
(*1)
(DI±1198)
Curtain shield airbag sensor LH malfunction
Curtain shield airbag sensor assembly LH
Airbag sensor assembly
Floor wire No. 2
ON
B1650/32
(DI±1204)Occupant classification system malfunction
Occupant classification system
Airbag sensor assembly
Floor wire
Seat wire No. 1
ON
B1653/35
(DI±1213)Seat position sensor assembly malfunction
Seat position airbag sensor assembly
Airbag sensor assembly
Floor wire No. 2
ON

Page 1358 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±1156
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1350 Author: Date:
2005 SEQUOIA (RM1146U)B1656/38
(DI±1220)
Seat belt buckle switch LH malfunction
Front seat inner belt LH
Airbag sensor a

DI±1156
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1350 Author: Date:
2005 SEQUOIA (RM1146U)B1656/38
(DI±1220)
Seat belt buckle switch LH malfunction
Front seat inner belt LH
Airbag sensor assembly
Floor wire No. 2
ON
B1660/43
(DI±1227)Passenger airbag ON/OFF indicator malfunction
Integration control and panel (Passenger
airbag ON/OFF indicator)
Airbag sensor assembly
Cowl wire
ON
B1661/44
(*1)
(DI±1238)
Roll over cut off indicator malfunction
Combination meter (RSCA OFF indicator)
Airbag sensor assembly
Cowl wire
ON
B1662/45
(DI±1247)SRS warning light circuit malfunction
Combination meter (SRS warning light)
Airbag sensor assembly
Cowl wire
ON
B1800/51
(DI±1352)Short in D squib circuit
Steering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1801/51
(DI±1352)Open in D squib circuit
Steering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1802/51
(DI±1352)Short in D squib circuit (to ground)
Steering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1803/51
(DI±1352)Short in D squib circuit (to B+)
Steering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1805/52
(DI±1374)Short in P squib circuit
Front passenger airbag assembly (P squib)
Airbag sensor assembly
Cowl wire
ON
B1806/52
(DI±1374)Open in P squib circuit
Front passenger airbag assembly (P squib)
Airbag sensor assembly
Cowl wire
ON
B1807/52
(DI±1374)Short in P squib circuit (to ground)
Front passenger airbag assembly (P squib)
Airbag sensor assembly
Cowl wire
ON
B1808/52
(DI±1374)Short in P squib circuit (to B+)
Front passenger airbag assembly (P squib)
Airbag sensor assembly
Cowl wire
ON
B1810/53
(DI±1384)Short in D squib (Dual stage ± 2nd step) circuit
Steering wheel pad (D squib, Dual stage ±
2nd step)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1811/53
(DI±1384)Open in D squib (Dual stage ± 2nd step) circuit
Steering wheel pad (D squib, Dual stage ±
2nd step)
Spiral cable
Airbag sensor assembly
Cowl wire
ON

Page 1359 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1157
1351 Author: Date:
2005 SEQUOIA (RM1146U)B1812/53
(DI±1384)
Short in D squib (Dual stage ± 2nd step) circuit
(to ground)
Steering wheel pa

± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1157
1351 Author: Date:
2005 SEQUOIA (RM1146U)B1812/53
(DI±1384)
Short in D squib (Dual stage ± 2nd step) circuit
(to ground)
Steering wheel pad (D squib, Dual stage ±
2nd step)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1813/53
(DI±1384)Short in D squib (Dual stage ± 2nd step) circuit
(to B+)
Steering wheel pad (D squib, Dual stage ±
2nd step)
Spiral cable
Airbag sensor assembly
Cowl wire
ON
B1815/54
(DI±1406)Short in P squib (Dual stage ± 2nd step) circuit
Front passenger airbag assembly (P squib,
Dual stage ± 2nd step)
Airbag sensor assembly
Cowl wire
ON
B1816/54
(DI±1406)Open in P squib (Dual stage ± 2nd step) circuit
Front passenger airbag assembly (P squib,
Dual stage ± 2nd step)
Airbag sensor assembly
Cowl wire
ON
B1817/54
(DI±1406)Short in P squib (Dual stage ± 2nd step) circuit
(to ground)
Front passenger airbag assembly (P squib,
Dual stage ± 2nd step)
Airbag sensor assembly
Cowl wire
ON
B1818/54
(DI±1406)Short in P squib (Dual stage ± 2nd step) circuit
(to B+)
Front passenger airbag assembly (P squib,
Dual stage ± 2nd step)
Airbag sensor assembly
Cowl wire
ON
B1820/55
(*1)
(DI±1416)
Short in side squib RH circuit
Side airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor wire
ON
B1821/55
(*1)
(DI±1416)
Open in side squib RH circuit
Side airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor wire
ON
B1822/55
(*1)
(DI±1416)
Short in side squib RH circuit (to ground)
Side airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor wire
ON
B1823/55
(*1)
(DI±1416)
Short in side squib RH circuit (to B+)
Side airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor wire
ON
B1825/56
(*1)
(DI±1426)
Short in side squib LH circuit
Side airbag assembly LH (Side squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1826/56
(*1)
(DI±1426)
Open in side squib LH circuit
Side airbag assembly LH (Side squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1827/56
(*1)
(DI±1426)
Short in side squib LH circuit (to ground)
Side airbag assembly LH (Side squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1828/56
(*1)
(DI±1426)
Short in side squib LH circuit (to B+)
Side airbag assembly LH (Side squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1830/57
(*1)
(DI±1436)
Short in curtain shield airbag RH squib circuit
Curtain shield airbag assembly RH
(Curtain shield airbag RH squib)
Airbag sensor assembly
Floor wire
ON

Page 1360 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±1158
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1352 Author: Date:
2005 SEQUOIA (RM1146U)B1831/57
(*1)
(DI±1436)
Open in curtain shield airbag RH squib circuit
Curtain shield airbag assemb

DI±1158
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1352 Author: Date:
2005 SEQUOIA (RM1146U)B1831/57
(*1)
(DI±1436)
Open in curtain shield airbag RH squib circuit
Curtain shield airbag assembly RH
(Curtain shield airbag RH squib)
Airbag sensor assembly
Floor wire
ON
B1832/57
(*1)
(DI±1436)Short in curtain shield airbag RH squib circuit
(to ground)
Curtain shield airbag assembly RH
(Curtain shield airbag RH squib)
Airbag sensor assembly
Floor wire
ON
B1833/57
(*1)
(DI±1436)Short in curtain shield airbag RH squib circuit
(to B+)
Curtain shield airbag assembly RH
(Curtain shield airbag RH squib)
Airbag sensor assembly
Floor wire
ON
B1835/58
(*1)
(DI±1447)
Short in curtain shield airbag LH squib circuit
Curtain shield airbag assembly LH
(Curtain shield airbag LH squib)
Airbag sensor assembly
Floor wire No. 2
ON
B1836/58
(*1)
(DI±1447)
Open in curtain shield airbag LH squib circuit
Curtain shield airbag assembly LH
(Curtain shield airbag LH squib)
Airbag sensor assembly
Floor wire No. 2
ON
B1837/58
(*1)
(DI±1447)Short in curtain shield airbag LH squib circuit
(to ground)
Curtain shield airbag assembly LH
(Curtain shield airbag LH squib)
Airbag sensor assembly
Floor wire No. 2
ON
B1838/58
(*1)
(DI±1447)Short in curtain shield airbag LH squib circuit
(to B+)
Curtain shield airbag assembly LH
(Curtain shield airbag LH squib)
Airbag sensor assembly
Floor wire No. 2
ON
B1900/73
(DI±1458)Short in P/T squib RH circuit
Front seat outer belt RH (P/T squib RH)
Airbag sensor assembly
Floor wire
ON
B1901/73
(DI±1458)Open in P/T squib RH circuit
Front seat outer belt RH (P/T squib RH)
Airbag sensor assembly
Floor wire
ON
B1902/73
(DI±1458)Short in P/T squib RH circuit (to ground)
Front seat outer belt RH (P/T squib RH)
Airbag sensor assembly
Floor wire
ON
B1903/73
(DI±1458)Short in P/T squib RH circuit (to B+)
Front seat outer belt RH (P/T squib RH)
Airbag sensor assembly
Floor wire
ON
B1905/74
(DI±1469)Short in P/T squib LH circuit
Front seat outer belt LH (P/T squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1906/74
(DI±1469)Open in P/T squib LH circuit
Front seat outer belt LH (P/T squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1907/74
(DI±1469)Short in P/T squib LH circuit (to ground)
Front seat outer belt LH (P/T squib LH)
Airbag sensor assembly
Floor wire No. 2
ON
B1908/74
(DI±1469)Short in P/T squib LH circuit (to B+)
Front seat outer belt LH (P/T squib LH)
Airbag sensor assembly
Floor wire No. 2
ON

Load next 8 pages

Page: < prev 1-10 ... 1321-1328 1329-1336 1337-1344 1345-1352 1353-1360 1361-1368 1369-1376 1377-1384 1385-1392 ... 4328 next >

center console display seat adjustment TPMS reset tow fuel
