Page 2817 of 4323
B17493
Engine Wire
VSV Connector
for Air Injection
System Engine Wire
Throttle Body
ConnectorFuel Return Hose
Engine WireInjector Connector
VSV Connector for
EVAP
VVT Sensor 2
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable partGasket
VVT Sensor 1
VSV Connector
for ACIS
VVT Sensor ConnectorVVT Sensor Connector
18 (185, 13)
18 (185, 13)
7.5 (76, 66 in.´lbf)
± SFIVVT SENSOR
SF±75
2809 Author: Date:
2005 SEQUOIA (RM1146U)
Page 2818 of 4323
SF0PW±03
B17494
Ohmmeter SF±76
± SFIVVT SENSOR
2810 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
NOTICE:
ºColdº and ºHot in these sentences express the tempera-
ture of the sensors themselves. ºColdº is from ± 10°C
(14°F) to 50°C (122°F) and ºHotº is from 50 °C (122°F) to
100°C (212°F).
1. REMOVE THROTTLE BODY COVER
2. REMOVE INTAKE MANIFOLD ASSEMBLY
(See page EM±36)
3. INSPECT VVT SENSOR RESISTANCE
(a) Disconnect the VVT sensor connector.
(b) Using an ohmmeter, measure the resistance between the
terminals.
Resistance:
Cold835 to 1,400 W
Hot1,060 to 1,645 W
If the resistance is not as specified, replace the sensor.
(c) Reconnect the VVT sensor connector.
(d) Connect the VVT sensor connector.
4. REINSTALL INTAKE MANIFOLD ASSEMBLY
(See page EM±60)
5. REINSTALL THROTTLE BODY COVER
Page 2819 of 4323
SF1XY±01
± SFIVVT SENSOR
SF±77
2811 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
1. REMOVE THROTTLE BODY COVER
2. REMOVE INTAKE MANIFOLD ASSEMBLY
(See page EM±36)
3. REMOVE VVT SENSOR
(a) Disconnect the VVT sensor connector.
(b) Remove the bolt and VVT sensor.
4. INSTALL VVT SENSOR
(a) Attach a new VVT sensor to the cylinder head.
(b) Install the VVT sensor with the bolt.
Torque: 6.5 N´m (65 kgf´cm, 58 in.´lbf)
5. REINSTALL INTAKE MANIFOLD ASSEMBLY
(See page EM±60)
6. REINSTALL THROTTLE BODY COVER
Page 2820 of 4323
SF1UM±05
B16380
Accelerator Pedal
Assembly
N´m (kgf´cm, ft´lbf) : Specified torqueAccelerator Pedal
Position Sensor
Accelerator Pedal Position
Sensor Connector
5.0 (51, 44 in.´lbf)
SF±78
± SFIACCELERATOR PEDAL POSITION SENSOR
2812 Author: Date:
2005 SEQUOIA (RM1146U)
ACCELERATOR PEDAL POSITION SENSOR
COMPONENTS
Page 2821 of 4323
SF1UN±02
± SFIACCELERATOR PEDAL POSITION SENSOR
SF±79
2813 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
INSPECT ACCELERATOR PEDAL POSITION SENSOR (See page DI±370)
If necessary, replace the accelerator pedal assembly.
NOTICE:
Be care not to give a shock to the accelerator pedal assembly.
Be care not to disassemble the accelerator pedal assembly.
Page 2822 of 4323
SF0Q0±14
B07642
ECM Connector
ECM and Bracket Assembly
Glove Compartment DoorLower No.2 Finish Panel
ECM Bracket
ECM Bracket
ECM
Heater to Register Duct
SF±80
± SFIENGINE CONTROL MODULE (ECM)
2814 Author: Date:
2005 SEQUOIA (RM1146U)
ENGINE CONTROL MODULE (ECM)
COMPONENTS
Page 2823 of 4323
SF0Q1±12
± SFIENGINE CONTROL MODULE (ECM)
SF±81
2815 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. DISCONNECT CABLE FROM NEGATIVE (±) BATTERY TERMINAL
2. REMOVE REMOVE GLOVE COMPARTMENT
(a) Remove the 2 screws and glove compartment door.
(b) Remove the 3 screws and lower No.2 finish panel.
3. REMOVE HEATER TO REGISTER DUCT
4. REMOVE ECM
(a) Disconnect the 5 connectors.
(b) Remove the 2 bolts and ECM.
5. INSPECT ECM (See page DI±34)
6. REINSTALL ECM
(a) Install the ECM with the 2 bolts.
(b) Connect the 5 connectors.
7. INSTALL HEATER TO REGISTER DUCT
8. INSTALL GLOVE COMPARTMENT
(a) Install the lower No.2 finish panel with 3 screws.
(b) Install the glove compartment door with the 2 screws.
9. CONNECT CABLE TO NEGATIVE (±) BATTERY TERMINAL
10. PERFORM INITIALIZATION (See page IN±20)
Some system need initialzation when disconnecting the cable from the battery terminal.
Page 2824 of 4323
SF0Q2±16
D13872
Hand±Held Tester
DLC3
CAN VIM
B04432
Sound Scope
SF±82
± SFIFUEL CUT RPM
2816 Author: Date:
2005 SEQUOIA (RM1146U)
FUEL CUT RPM
INSPECTION
1. WARM UP ENGINE
Allow the engine to warm up to normal operating temperature.
2. CONNECT HAND±HELD TESTER
(a) Connect a hand±held tester to the Controller Area Net-
work Vehicle Interface Module (CAN VIM). Then connect
the CAN VIM to the Date Link Connector 3 (DLC3).
(b) Please refer to the hand±held tester operator's manual
for further details.
3. INSPECT FUEL CUTOFF RPM OPERATION
(a) Increase the engine speed to at least 2,500 rpm.
(b) Check for injector operating noise.
(c) Check that when the throttle lever is released, injector op-
eration noise stops momentarily and then resumes.
HINT:
The vehicle should be stopped.
Measure with the A/C OFF.
Fuel return speed: 1,400 rpm
(d) Disconnect the hand±held tester and CAN VIM from the
DLC3.
