Page 3385 of 4323
RS11M±01
RS±94
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
3377 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the side airbag sensor assembly with a new one.
The side airbag assembly has been deployed in a collision.
The side airbag sensor assembly has been found to be faulty in troubleshooting.
The side airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the side airbag sensor assembly, see page RS±92 and RS±95. Be sure
to follow the correct procedure.
Page 3386 of 4323

RS11N±01
H20066
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
RS±95
3378 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
Never use SRS parts from another vehicle. When re-
placing parts, replace them with new ones.
Never reuse the side airbag sensor assembly in-
volved in a collision when the airbag has deployed.
If the side airbag sensor assembly center has been
dropped, or there are any cracks, dents or other de-
fects in the case, bracket or connector, replace it with
a new one.
When installing the side airbag sensor assembly, be
careful that the SRS wiring does not interfere with
other parts and that it is not pinched between other
parts.
After installing, shake the side airbag sensor assem-
bly to check that there is no looseness.
1. INSTALL SIDE AIRBAG SENSOR ASSEMBLY LH
(a) Install the side airbag sensor assembly LH with the 3
bolts.
Torque: 17.5 N´m (179 kgf´cm, 13 ft´lbf)
(b) Connect the connector to the side airbag sensor assem-
bly LH.
2. INSTALL FRONT SEAT OUTER BELT RETRACTOR
(SEE PAGE BO±172)
3. INSTALL CENTER PILLAR LOWER GARNISH
(SEE PAGE BO±108)
4. INSTALL FRONT SEAT OUTER BELT FLOOR AN-
CHOR (SEE PAGE BO±108 )
5. INSTALL REAR DOOR SCUFF PLATE
(SEE PAGE BO±97)
6. INSTALL FRONT DOOR SCUFF PLATE
(SEE PAGE BO±97)
7. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
8. PERFORM INITIALIZATION (SEE PAGE BE±77)
Some system need initialization when disconnecting the cable
from the negative battery terminal.
9. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)
Page 3387 of 4323
RS11O±01
H23904: Specified torqueN´m (kgf´cm, ft´lbf)Rear Door Scuff Plate Rear Seat No. 2 AssemblyCurtain Shield Airbag
Sensor Assembly LH Rear Floor Panel Support Plate
Quarter Trim Plate
17.5 (179, 13)
RS±96
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
3379 Author: Date:
2005 SEQUOIA (RM1146U)
CURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
COMPONENTS
Page 3388 of 4323

RS11P±01
H23905
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
RS±97
3380 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
If the wiring connector of the SRS is disconnected
with the ignition switch in the ON position, DTCs will
be recorded.
Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.
1. PRECAUTION (SEE PAGE RS±1 and RS±3)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
3. REMOVE REAR SEAT NO. 2 ASSEMBLY
(SEE PAGE BO±157)
4. REMOVE REAR DOOR SCUFF PLATE
(SEE PAGE BO±101)
5. REMOVE REAR FLOOR PANEL SUPPORT PLATE
(SEE PAGE BO±101)
6. REMOVE QUARTER TRIM PLATE
(SEE PAGE BO±101)
7. REMOVE CURTAIN SHIELD AIRBAG SENSOR AS-
SEMBLY LH
(a) Disconnect the curtain shield airbag sensor assembly LH
connector.
NOTICE:
Disconnect the connector with the sensor assembly
installed.
(b) Remove the 2 nuts and curtain shield airbag sensor as-
sembly LH.
Page 3389 of 4323
RS11Q±01
RS±98
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
3381 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
Perform a diagnostic system check (see page DI±1147).
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS NOT DEPLOYED
Perform a diagnostic system check (see page DI±1147).
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED
Replace the curtain shield airbag sensor assembly (see page DI±1147).
Page 3390 of 4323
RS11R±01
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
RS±99
3382 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the curtain shield airbag sensor assembly with a new one.
The curtain shield airbag assembly has been deployed in a collision.
The curtain shield airbag sensor assembly has been found to be faulty in troubleshooting.
The curtain shield airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the curtain shield airbag sensor assembly, see page RS±97 and
RS±100. Be sure to follow the correct procedure.
Page 3391 of 4323

RS11S±01
H23905
RS±100
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
3383 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
Never use SRS parts from another vehicle. When re-
placing parts, replace them with new ones.
Never reuse the curtain shield airbag sensor assem-
bly involved in a collision when the airbag has
deployed.
If the curtain shield airbag sensor assembly center
has been dropped, or there are any cracks, dents or
other defects in the case, bracket or connector, re-
place it with a new one.
When installing the curtain shield airbag sensor as-
sembly center, be careful that the SRS wiring does
not interfere with other parts and that it is not pinched
between other parts.
After installing, shake the curtain shield airbag sen-
sor assembly to check that there is no looseness.
1. INSTALL CURTAIN SHIELD AIRBAG SENSOR AS-
SEMBLY LH
(a) Install the curtain shield airbag sensor assembly LH with
the 2 nuts.
Torque:17.5 N´m (179 kgf´cm, 13 ft´lbf)
(b) Connect the curtain shield airbag sensor assembly LH
connector.
2. INSTALL RETRACTOR OF FRONT SEAT OUTER BELT
3. INSTALL QUARTER TRIM PLATE
(SEE PAGE BO±108)
4. INSTALL REAR FLOOR PANEL SUPPORT PLATE
(SEE PAGE BO±108)
5. INSTALL REAR DOOR SCUFF PLATE
(SEE PAGE BO±108)
6. INSTALL REAR SEAT NO. 2 ASSEMBLY
(SEE PAGE BO±158)
7. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
Page 3392 of 4323
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG SENSOR ASSEMBLY
RS±101
3384 Author: Date:
2005 SEQUOIA (RM1146U)
8. PERFORM INITIALIZATION (SEE PAGE BE±77)
Some system need initialization when disconnecting the cable
from the negative battery terminal.
9. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)
