Page 3417 of 4323

± BODY ELECTRICALTROUBLESHOOTING
BE±5
3409 Author: Date:
2005 SEQUOIA (RM1146U) Taillight does not go off when light control switch is in OFF posi-
tion.
1. TAILLIGHT Relay
2. Light Control Switch
3. Wire Harness
4. Body ECUBE±27
BE±27
±
±
Headlight does not come on when engine is running and light
control switch is in OFF position .
1. ECU±B Fuse
2. MAIN Fuse
3. HEAD Relay
4. DRL Fuse
5. DRL No. 4 Relay
6. DIMMER Relay
7. Parking Brake Switch
8. Wire Harness
9. Body ECUBE±14
BE±14
BE±27
BE±14
BE±27
BE±55
BE±55
±
±
FOG LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Fog light does not come on with light control switch is in HEAD
position.
(Headlight is normal.)
1. FOG Fuse
2. FOG LIGHT Relay
3. Fog Light Switch
4. Wire Harness
5. Body ECUBE±14
BE±27
BE±34
±
±
Fog light does not come on with light control switch is in HEAD
position.
(Headlight does not light).1.*1 Other Parts
2. Wire Harness±
±
Only one light does not come on.1. Bulb
2. Wire Harness±
±
*1: Inspect Headlight System
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. GAUGE Fuse
2. TURN±HAZ Fuse
3. Ignition Switch
4. Turn Signal Flasher Relay
5. Wire HarnessBE±14
BE±14
BE±24
BE±24
±
Hazard warning light does not light up.
(Turn is normal)1. Hazard Warning Switch
2. Wire Harness
3. Turn Signal Flasher RelayBE±36
±
BE±36
Turn signal does not light up.
(Hazard is normal)1. Turn Signal Switch
2. Wire Harness
3. Turn Signal Flasher RelayBE±36
±
BE±36
Turn signal does not light up in one direction.1. Bulb
2. Wire Harness±
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±
INTERIOR LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the interior lights do not come on.
1. DOME Fuse
2. Illumination Circuit
3. Body ECUBE±14
DI±1759
±
Page 3418 of 4323

BE±6
± BODY ELECTRICALTROUBLESHOOTING
3410 Author: Date:
2005 SEQUOIA (RM1146U) The interior light does not come on when the driver's door is
opened.
1. Driver's Door Courtesy Light Switch
2. Wire Harness
3. Body ECUBE±40
±
±
The light does not come on when the passenger's door is opened.
1. Passenger's Door Courtesy Light Switch
2. Wire Harness
3. Body ECUBE±40
±
±
The light does not come on when the rear±right door is opened.
1. Rear±Right Door Courtesy Light Switch
2. Wire Harness
3. Body ECUBE±40
±
±
The light does not come on when the rear±left door is opened.
1. Rear±Left Door Courtesy Light Switch
2. Wire Harness
3. Body ECUBE±40
±
±
Only one of the bulbs comes on.Bulb±
The illumination does not fade out when all the doors are closed.1. Courtesy Light Switch
2. Body ECUBE±40
±
The illumination does not fade out immediately when all the doors
are locked within 15 seconds after they are closed.1. Door Unlock Detection Switch
2. Body ECUBE±79
±
Front personal light does not come on.
1. Bulb
2. Front Personal Light
3. Wire Harness±
BE±40
±
Room light does not come on.
1. Bulb
2. Room Light
3. Wire Harness±
BE±40
±
Vanity light does not come on.
1. Bulb
2. Vanity Light
3. Wire Harness±
BE±40
±
Luggage Room light does not come on.
1. Bulb
2. Back Door Courtesy Light Switch
3. Body ECU±
BE±40
±
Courtesy light does not come on.
1. Bulb
2. Door Courtesy Light Switch
3. Body ECU±
BE±40
±
Does not operate the illuminated entry1. Illumination Circuit
2. Body ECUDI±1759
±
All functions of the body control system do not operate.1. Power Source Circuit
2. Body ECUDI±1700
±
BACK±UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back±Up Light does not come on.
1. Bulb
2. GAUGE Fuse
3. BACK±UP LIGHT Relay
4. Instrument Panel J/B (IPO) Circuit
5. Ignition Switch
6. Wire Harness±
BE±14
BE±45
BE±20
BE±24
±
Back±Up Light always remains on.
1. Park/Neutral Position Switch
2. BACK±UP LIGHT Relay
3. Wire HarnessDI±576
BE±45
±
Only one light does not come on.1. Bulb
2. Wire Harness±
±
Page 3419 of 4323

± BODY ELECTRICALTROUBLESHOOTING
BE±7
3411 Author: Date:
2005 SEQUOIA (RM1146U)
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not come on.
1. STOP Fuse
2. Stop Light Switch
3. Wire HarnessBE±14
BE±47
±
Stop light always come on.1. Stop Light Switch
2. Wire HarnessBE±47
±
Only one light does not come on.1. Bulb
2. Wire Harness±
±
WIPER AND WASHER SYSTEM
SymptomSuspect AreaSee page
Wipers and washer do not operate.
1. AM1 Fuse
2. Wiper Switch
3. Wire HarnessBE±14
BE±49
±
Wipers do not operate.
1. WIP Fuse
2. Wiper Switch
3. Wiper Motor
4. Wire HarnessBE±14
BE±49
BE±49
±
Washer motor does not operate.
1. WSH Fuse
2. Washer Switch
3. Washer Motor
4. Wire HarnessBE±14
BE±49
BE±49
±
Wipers do not operate when washer switch ON.
1. WSH Fuse
2. Washer Switch
3. Wiper Motor
4. Wire HarnessBE±14
BE±49
BE±49
±
Washer fluid is not injected.Washer Hose and Nozzle±
When wiper switch is in HI position, the wiper blade is in contact
with the body.
When the wiper switch is OFF, the wiper blade does not retract
or the retract position is wrong.
1. Wiper Motor *1
2. Wire harness *1BE±49
±
*1: Inspect wiper arm and blade set positions.
REAR WIPER AND WASHER SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Rear Wiper does not operate.
1. Rear Wiper and Washer Switch
2. Rear Wiper Motor
3. Back Door ECU
4. Body ECUBE±49
BE±49
±
±
Rear Washer does not operate.
1. Rear Wiper and Washer Switch
2. Rear Washer Motor
3. Back Door ECU
4. Body ECUBE±49
BE±49
±
±
COMBINATION METER
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Combination meter system abnormal operation.See DIAGNOSIS SYSTEMDI±1610
Page 3420 of 4323

BE±8
± BODY ELECTRICALTROUBLESHOOTING
3412 Author: Date:
2005 SEQUOIA (RM1146U)
DEFOGGER SYSTEM
SymptomSuspect AreaSee page
Rear window defogger does not operate.
1. HTR Fuse
2. DEFOG Fuse
3. DEFOG Relay
4. Defogger Switch (in A/C Panel Switch)
5. Defogger Wire
6. Wire HarnessBE±14
BE±14
BE±14
BE±65
BE±65
±
Mirror defogger does not operate.
1. MIR±HTR Fuse
2. HTR Fuse
3. Mirror Heater Relay
4. Mirror Heater
5. Wire HarnessBE±14
BE±14
BE±65
BE±65
±
POWER WINDOW CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power door lock system is normal.)
1. POWER MAIN Relay
2. Driver Door ECU (Power Window Master Switch)
3. Body ECU
4. Wire HarnessBE±69
DI±1788
±
±
Only the driver's window does not operate.
1. Power Window Motor
2. Power Window Pulse Sensor Circuit
3. Power Window Limit Switch Circuit
4. Driver Door ECU (Power Window Master Switch)BE±69
DI±1803
DI±1800
±
ºWindow lock functionº does not operate.Driver Door ECU (Power Window Master Switch)BE±69
Only the rear LH window does not operate.
1. Power Window Motor
2. Power Window Switch
3. Body ECUBE±69
BE±69
±
Only the rear RH window does not operate.
1. Power Window Motor
2. Power Window Switch
3. Body ECUBE±69
BE±69
±
Only the front passenger's window does not operate.
1. Power Window Motor
2. Power Window Pulse Sensor Circuit
3. Power Window Limit Switch Circuit
4. Passenger Door ECUBE±69
DI±1841
DI±1838
±
The Key related power window operations do not operate with
driver side door key cylinder.
(Master switch operation is normal.)1. Door Key Lock and Unlock Switch Circuit
2. Driver Door ECU (Power Window Master Switch)DI±1791
±
º Auto up º or º Auto down º does not operate. *1
1. Power Window Pulse Sensor Circuit
2. Power Window Limit Switch Circuit
3. Driver Door ECU (Power Window Master Switch)DI±1803
DI±1800
±
*1: º Auto up º or º Auto down º may not function when the manual switch is pressed and held for 2 sec. or
more with the window glass fully open or closed. In this case, by performing a sequence of the window glass
operations (full open, fully close and then half open), the function can be restored. If not, replace the driver
door ECU or passenger door ECU.
Page 3421 of 4323

± BODY ELECTRICALTROUBLESHOOTING
BE±9
3413 Author: Date:
2005 SEQUOIA (RM1146U)
POWER DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the doors cannot be locked or unlocked.
(Power window control system is normal.)1. Door Unlock Detection Switch
2. Door Key Lock and Unlock Switch
3. Driver Door ECUBE±79
BE±79
±
Only one back lock control does not operate.
1. Back Door Lock Motor
2. Back Door Unlock Detection Switch
3. Back Door Key Lock and Unlock Switch
4. Back Door ECUBE±79
BE±79
BE±79
±
Driver door key related function does not operate.1. Door Key Lock and Unlock Switch
2. Driver Door ECUBE±79
±
Front passenger door key related function does not operate.1. Door Key Lock and Unlock Switch
2. Passenger Door ECUBE±79
±
Back door key related function does not operate.1. Door Key Lock and Unlock Switch
2. Back Door ECUBE±79
±
THEFT DETERRENT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
The theft deterrent system cannot be set.
1. Key Unlock Warning Switch Circuit
2. Door Unlock Detection Switch Circuit (Driver Door ECU)
Door Unlock Detection Switch Circuit (Passenger Door
ECU)
Door Unlock Detection Switch Circuit (Back Door ECU)
Door Unlock Detection Switch Circuit (Body ECU)
3. Engine Hood Courtesy Switch Circuit
4. Back Door Courtesy Light Switch
5. Courtesy Light Switch Circuit
6. Glass Breakage Sensor Circuit (*1)
7. Body ECUDI±1715
DI±1791
DI±1829
DI±1869
DI±1723
DI±1725
DI±1864
DI±1728
DI±1774
±
The system cannot be canceled when the ignition switch is turned
ON with a key.
1. AM1 Fuse
2. AM2 Fuse
3. Key Unlock Warning Switch Circuit
4. Ignition Switch
5. Body ECUBE±14
BE±14
DI±1715
BE±24
±
The system cannot be canceled when the back door is unlocked
with a key.
1. Back Door Unlock Detection Switch Circuit
2. Back Door Key Lock and Unlock Switch Circuit
3. Back door ECU
4. Body ECUDI±1869
DI±1882
±
±
The system does not operate when the engine hood is opened.1. Engine Hood Courtesy Switch Circuit
2. Body ECUDI±1725
±
Some of the system does not operate.
(Headlight does not come on.)
1. Bulb
2. HEAD Relay
3. DIMMER Relay
4. DRL No. 4 Relay
5. Headlight Dimmer Switch
6. Light Control Switch
7. Wire Harness
8. Body ECU±
BE±27
BE±27
BE±27
BE±27
BE±27
±
±
Page 3422 of 4323

BE±10
± BODY ELECTRICALTROUBLESHOOTING
3414 Author: Date:
2005 SEQUOIA (RM1146U) Some of the system does not operate.
(Taillight does not come on.)
1. TAIL Fuse
2. TAILLIGHT Relay
3. Light Control Switch
4. Wire Harness
5. Body ECUBE±14
BE±27
BE±27
±
±
Some of the system do not operate.
(Theft deterrent horn or vehicle horn does not sound.)
1. HORN Fuse
2. SECURITY HORN Fuse
3. HORN Relay Circuit
4. Theft Deterrent Horn Circuit
5. Horn
6. Body ECUBE±14
BE±14
BE±145
BE±92
BE±145
±
While the warning is given, the system cannot be canceled by
unlocking the door with a key or transmitter.
1. Door Key Lock and Unlock Switch Circuit (Driver Door
ECU)
Door Key Lock and Unlock Switch Circuit (Passenger
Door ECU)
Door Key Lock and Unlock Switch Circuit (Back Door
ECU)
2. Body ECUDI±1794
DI±1832
DI±1882
±
*1: w/ Glass breakage sensor
WIRELESS DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
HINT:
Troubleshooting of the wireless door lock control system is based on the premise that the door lock
control system operates normally. Accordingly, before troubleshooting the wireless door lock control
system, first make certain that the door lock control system operates normally.
If the trouble still reappears even though there are no abnormalities in any of the other circuits, check
and replace the Wireless Door Lock Control Receiver as the last step.
SymptomSuspect AreaSee page
All functions of wireless door lock control system do not operate.
1. Transmitter
2. Wireless Door Lock Control Receiver Circuit
3. Body ECUBE±98
DI±1737
±
Wireless door lock operates, but the buzzer does not sound.
(The buzzer does not sound when the customize function prohib-
its.)1. Wireless Door Lock Buzzer Circuit
2. Body ECUDI±1741
±
POWER SEAT CONTROL SYSTEM (w/o Driving Position Memory)
SymptomSuspect AreaSee page
Both Driver and Passenger Power seats do not operate.1. PWR SEAT Fuse
2. Wire HarnessBE±14
±
Driver's seat does not operate.1. Power Seat Switch (D)
2. Wire HarnessBE±109
±
Passenger's seat does not operate.1. Power Seat Switch (P)
2. Wire HarnessBE±109
±
ºSlide operationº does not operate.
1. Power Seat Switch (D, P)
2. Slide Motor (D, P)
3. Wire HarnessBE±109
BE±109
±
ºFront Vertical Operationº does not operate.
1. Power Seat Switch (D)
2. Front Vertical Motor (D)
3. Wire HarnessBE±109
BE±109
±
ºLifter Operationº does not operate.
1. Power Seat Switch (D)
2. Lifter Motor (D)
3. Wire HarnessBE±109
BE±109
±
Page 3423 of 4323

± BODY ELECTRICALTROUBLESHOOTING
BE±11
3415 Author: Date:
2005 SEQUOIA (RM1146U) ºReclining Operationº does not operate.
1. Power Seat Switch (D, P)
2. Reclining Motor (D, P)
3. Wire HarnessBE±109
BE±109
±
ºLumbar Support Operationº does not operate.
1. Power Seat Switch (D)
2. Lumbar Support Motor (D)
3. Wire HarnessBE±109
BE±109
±
(D): Driver's Seat
(P): Passenger's Seat
POWER SEAT CONTROL SYSTEM (w/ Driving Position Memory)
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspected AreaSee Page
Power seat control system abnormal operation.See DIAGNOSIS SYSTEMDI±1505
POWER MIRROR CONTROL SYSTEM (w/o Driving Position Memory)
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Mirror does not operate.1. Mirror Switch
2. Wire HarnessBE±115
±
Mirror operates abnormally.
1. Mirror Switch
2. Mirror Motor
3. Wire HarnessBE±115
BE±115
±
POWER MIRROR CONTROL SYSTEM (w/ Driving Position Memory)
SymptomSuspect AreaSee page
Remote control mirror LH only does not operate.
(w/ Driving position memory)1. Remote control mirror motor LH circuit
2. Remote control mirror position sensor LH circuit
3. Driver door ECUDI±1808
DI±1810
±
Remote control mirror RH only does not operate.
(w/ Driving position memory)1. Remote control mirror motor RH circuit
2. Remote control mirror position sensor RH circuit
3. Passenger door ECUDI±1845
DI±1847
±
ELECTRO CHROMIC MIRROR SYSTEM
SymptomSuspect AreaSee page
Electro Chromic Inner Mirror does not operate.
1. ECU±IG Fuse
2. Electro Chromic Inner Mirror
3. Wire HarnessBE±14
BE±122
±
SEAT HEATER SYSTEM
SymptomSuspect AreaSee page
Seat heaters do not operate.
(Driver's and Passenger's)
1. SEAT HTR Fuse
2. Seat Heater Switch (D, P)
3. Seat Heater
4. Wire HarnessBE±14
BE±124
BE±124
±
Driver's seat heater does not operate.1. Seat Heater Switch (D, P)
2. Wire HarnessBE±124
±
Passenger's seat heater does not operate.1. Seat Heater Switch (D, P)
2. Wire HarnessBE±124
±
Seat heater temperature is too hot.Seat HeaterBE±124
AUDIO SYSTEM
SymptomSuspect AreaSee page
Audio system abnormal operation.See DIAGNOSIS SYSTEMDI±1962
Page 3424 of 4323

BE±12
± BODY ELECTRICALTROUBLESHOOTING
3416 Author: Date:
2005 SEQUOIA (RM1146U)
NAVIGATION SYSTEM
SymptomSuspect AreaSee page
Navigation system abnormal operation.See DIAGNOSIS SYSTEMDI±2172
REAR SEAT ENTERTAINMENT SYSTEM
SymptomSuspect AreaSee page
Rear seat entertainment system abnormal operation.See DIAGNOSIS SYSTEMDI±2083
REAR SEAT AUDIO SYSTEM
SymptomSuspect AreaSee page
Rear seat audio system abnormal operation.See DIAGNOSIS SYSTEMDI±2048
CLOCK SYSTEM
SymptomSuspect AreaSee page
Clock does not operate.TROUBLESHOOTING NO.1BE±127
Clock loses or gains time.TROUBLESHOOTING NO.2BE±127
GARAGE DOOR OPENER SYSTEM
SymptomSuspect AreaSee page
The equipment of which code has been registered does not oper-
ate.1. Garage Door Opener Switch
2. Wire Harness
3. *BE±134
±
±
LED does not come on. (Even though either switch is pressed.)1. Garage Door Opener Switch
2. Wire HarnessBE±134
±
LED does not come on. (Only one switch is pressed.)Garage Door Opener SwitchBE±134
* As the GARAGE DOOR OPENER on the vehicle side seems to be normal, check the OPENER on the
equipment side, of which code has been registered.
ENGINE IMMOBILISER SYSTEM
SymptomSuspect AreaSee page
Engine immobilizer system does not operate.See DIAGNOSIS SYSTEMBE±143
HORN SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Horn system does not operate.
1. HORN Fuse
2. HORN Relay Circuit
3. Horn Switch Circuit
4. Horn
5. Body ECUBE±14
BE±145
BE±145
BE±145
±
Horn blow all the time.
1. HORN Relay Circuit
2. Horn Switch Circuit
3. Body ECUBE±145
BE±145
±
One horn operates but the other horn does not operate.1. Horn
2. Wire HarnessBE±145
±
