TOYOTA SEQUOIA 2001 Service Repair Manual DI939±04
Vehicle Brought to Workshop
Customer Problem Analysis
P. DI±896
Check and Clear DTC
P. DI±911Items inside
are titles of pages in this manual,
with the page number in the bottom portion.

Page 1098 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI93A±03
Inspector s
Name:
Customer s Name
Date Vehicle
Brought InRegistration DateRegistration No.
Frame No.
Odometer Reading/ /
/ /
Date Problem First Occurred
Frequency

Page 1099 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDLY±01
F09750
DLC3
Ts
Tc
CG
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±897
1091 Author: Date:
2005 SEQUOIA (RM1146U)
CALIBRATION
1. ZERO POINT CALIBRATION OF MASTER CYLINDER
PRESSU

Page 1100 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±898
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1092 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Stop the vehicle. Use the hand±held tester to check
that the steering angle value on the

Page 1101 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDLZ±01
F09750
DLC3Ts
CG
BR3904
0.13 sec. 0.13 sec.
ON
OFF
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±899
1093 Author: Date:
2005 SEQUOIA (RM1146U)
TEST MODE PROCEDURE
1. When not u

Page 1102 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F02135
Start Position
End PositionWithin ± 5° DI±900
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1094 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Check the yaw rate and deceleration sensor

F02135
Start Position
End PositionWithin ± 5° DI±900
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1094 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Check the yaw rate and deceleration sensor.
Shift the shift lever to the D position and drive the vehicle
at a vehicle speed of approx. 3 mph (5 km/h), turn the
steering wheel either to the left or right for 90° or more,
and turn the vehicle through 180 degrees. Check that the
VSC buzzer sounds for 3 seconds upon start off.
Stop the vehicle and shift the shift lever to the P position,
and check that the VSC buzzer sounds again for 3 se-
conds.
HINT:
If the VSC buzzer sounds twice, the sensor check has
been completed normally.
If the VSC buzzer does not sound, check the VSC buzzer
circuit (See page DI±1052), then do the sensor check
again.
Drive the vehicle through 180°. At the end of the turn, the
direction of the vehicle should be within 180° ± 5° of its
start position.
Do not spin the wheels.
If the buzzer sounds after start off, then the deceleration
sensor check has passed its check. If the buzzer sounds
at the completion of a curve, then the yaw rate sensor
check has passed its check. The buzzer sound should be
heard twice during the sensor checks.
(c) Check the master cylinder pressure sensor.
(1) Turn the ignition switch to the ON position.
(2) Keep the vehicle in a stationary condition on a level
surface for 2 sec. or more.
(3) Keeping the vehicle in a stationary condition and
not pressing on the brake pedal for 1 sec. or more,
depress the brake pedal with 147 N (15 kgf, 33 lbf)
or more for 2 sec. or more.
NOTICE:
If zero point calibration has never been performed on a new
ECU, master cylinder pressure sensor check cannot be
completed correctly. Perform zero point calibration first
(See page DI±897).
HINT:
At this time, the buzzer sounds for 3 seconds.
(d) Check the speed sensor.
Drive the vehicle straight forward.
When driving the vehicle at the speed of 28 mph (45 km/h)
or higher for several seconds, check that the ABS warn-
ing light goes off.
HINT:
There is a possibility that the sensor check is not completed if
the vehicle has its wheels spun or its steering wheel turned dur-
ing this check.
(e) Stop the vehicle.

Page 1103 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F09750
CG TcDLC3
BR3893
Trouble Code (Example Code 72, 76)
ON
OFF
4 sec. 1.5 sec.
Repeat 2.5 sec.
0.5 sec. 0.5 sec. 0.5 sec. 0.5 sec.7726
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±901
10

Page 1104 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual D05981
Hand±held
Tester
DLC3
BR3904
0.13 sec. 0.13 sec.
ON
OFF
F02135
Start Position
End PositionWithin ± 5° DI±902
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1096 Author: Date:
2005 S
