Page 1585 of 4323

H01024H23360
P Squib
Airbag
Sensor
Assembly
C D
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1383
1577 Author: Date:
2005 SEQUOIA (RM1146U)
10 Check front passenger airbag assembly (P squib).
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
(c) From the step 9:
Disconnect the SST from connector ºCº.
(d) Connect the connector to the front passenger airbag as-
sembly.
(e) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1805, B1806, B1807 or B1808 is not output.
HINT:
Codes other than DTC B1805, B1806, B1807 and B1808 may
be output at this time, but they are not related to this check.
NG Replace front passenger airbag assembly
(see page DI±1137).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).
HINT:
Perform the simulation method by selecting the check mode with the hand±held tester (see page
DI±1151).
After selecting the check mode, perform the simulation method by wiggling each connector of the air-
bag system or driving the vehicle on a city or rough road (see page DI±1151).
Page 1586 of 4323

DI±1384
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1578 Author: Date:
2005 SEQUOIA (RM1146U)
DTC B1810/53 Short in D Squib (Dual stage ± 2nd step)
Circuit
DTC B1811/53 Open in D Squib (Dual stage ± 2nd step)
Circuit
DTC B1812/53 Short in D Squib (Dual stage ± 2nd step)
Circuit (to Ground)
DTC B1813/53 Short in D Squib (Dual stage ± 2nd step)
Circuit (to B+)
CIRCUIT DESCRIPTION
The D squib (Dual stage ± 2nd step) circuit consists of the airbag sensor assembly, the spiral cable and the
steering wheel pad.
The circuit instructs the SRS to deploy when deployment conditions are met.
These DTCs are recorded when a malfunction is detected in the D squib (Dual stage ± 2nd step) circuit.
DTC No.DTC Detection ConditionTrouble Area
B1810/53
The airbag sensor assembly receives a line short circuit
signal 5 times in the D squib (Dual stage ± 2nd step) cir-
cuit during primary check.
Spiral cable malfunction
D squib malfunction
Airbag sensor assembly malfunction
Steering wheel pad (D squib, Dual stage ± 2nd step)
Airbag sensor assembly
Spiral cable
Cowl wire
B1811/53
The airbag sensor assembly receives an open circuit sig-
nal in the D squib (Dual stage ± 2nd step) circuit for 2 se-
conds.
Spiral cable malfunction
D squib malfunction
Airbag sensor assembly malfunction
Steering wheel pad (D squib, Dual stage ± 2nd step)
Airbag sensor assembly
Spiral cable
Cowl wire
B1812/53
The airbag sensor assembly receives a short circuit to
ground signal in the D squib (Dual stage ± 2nd step) cir-
cuit for 0.5 seconds.
Spiral cable malfunction
D squib malfunction
Airbag sensor assembly malfunction
Steering wheel pad (D squib, Dual stage ± 2nd step)
Airbag sensor assembly
Spiral cable
Cowl wire
B1813/53
The airbag sensor assembly receives a short to B+ circuit
signal in the D squib (Dual stage ± 2nd step) circuit for 0.5
seconds.
Spiral cable malfunction
D squib malfunction
Airbag sensor assembly malfunction
Steering wheel pad (D squib, Dual stage ± 2nd step)
Airbag sensor assembly
Spiral cable
Cowl wire
DIDHK±01
Page 1587 of 4323
H01451
Airbag Sensor Assembly
A208
D2+ Y±R D Squib
A23
Spiral CableA207
D2± Y±G 4
3
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1385
1579 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
Page 1588 of 4323

DI±1386
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1580 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
Be sure to perform the following procedures before troubleshooting to avoid unexpected airbag de-
ployment.
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the battery, and wait for at least 90 seconds.
(c) Disconnect the connectors from the airbag sensor assembly.
(d) Disconnect the connectors from the steering wheel pad.
(e) Disconnect the connectors from the front passenger airbag assembly.
(f) w/ Side and curtain shield airbag:
Disconnect the connectors from the side airbag assembly LH and RH.
(g) w/ Side and curtain shield airbag:
Disconnect the connectors from the curtain shield airbag assembly LH and RH.
(h) Disconnect the connectors from the front seat outer belt LH and RH.
1 Check DTC.
CHECK:
(a) Proceed to each step according to how to read DTC.
(1) If using the hand±held tester (read the 5±digit of DTC):
Using the hand±held tester, check the DTCs (see page DI±1147).
RESULT:
DTC B1810 is output.A
DTC B1811 is output.B
DTC B1812 is output.C
DTC B1813 is output.D
(2) If not using the hand±held tester (read the 2±digit of DTC):
Check the DTCs (see page DI±1147).
RESULT:
DTC 53 is output.E
HINT:
Codes other than DTC B1810, B1811, B1812, B1813 and DTC 53 may be output at this time, but they are
not related to this check.
B Go to step 4.
C Go to step 5.
D Go to step 6.
E Go to step 7.
A
Page 1589 of 4323
H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1387
1581 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check connector.
CHECK:
Check that the spiral cable connectors (on the steering wheel pad side) are not damaged.
OK:
The lock button is not disengaged, or the claw of the lock is not deformed or damaged.
NG Replace spiral cable (see page RS±21).
OK
3 Check D squib (dual stage ± 2nd step) circuit (short).
PREPARATION:
Release the activation prevention mechanism built into con-
nector ºBº (see page DI±1137).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±Always1 MW or higher
NG Go to step 13.
OK
Go to step 10.
Page 1590 of 4323
H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
DI±1388
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1582 Author: Date:
2005 SEQUOIA (RM1146U)
4 Check D squib (dual stage ± 2nd step) circuit (open).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±AlwaysBelow 1 W
NG Go to step 15.
OK
Go to step 11.
5 Check D squib (dual stage ± 2nd step) circuit (short to ground).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± Body groundAlways1 MW or higher
D2± ± Body groundAlways1 MW or higher
NG Go to step 17.
OK
Go to step 11.
Page 1591 of 4323
H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1389
1583 Author: Date:
2005 SEQUOIA (RM1146U)
6 Check D squib (dual stage ± 2nd step) circuit (short to B+).
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± Body groundIgnition switch ONBelow 1 V
D2± ± Body groundIgnition switch ONBelow 1 V
NG Go to step 19.
OK
Go to step 11.
7 Check connector.
CHECK:
Check that the spiral cable connectors (on the steering wheel pad side) are not damaged.
OK:
The lock button is not disengaged, or the claw of the lock is not deformed or damaged.
NG Replace spiral cable (see page RS±21).
OK
Page 1592 of 4323

H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
DI±1390
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1584 Author: Date:
2005 SEQUOIA (RM1146U)
8 Check D squib (dual stage ± 2nd step) circuit.
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± Body groundIgnition switch ONBelow 1 V
D2± ± Body groundIgnition switch ONBelow 1 V
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±AlwaysBelow 1 W
D2+ ± Body groundAlways1 MW or higher
D2± ± Body groundAlways1 MW or higher
PREPARATION:
Release the activation prevention mechanism built into con-
nector ºBº (see page DI±1137).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±Always1 MW or higher
NG Go to step 21.
OK
