HOW TO TROUBLESHOOT ECU CONTROLLED SYSTEMS
GENERAL INFORMATION
A large number of ECU controlled systems are used in the SEQUOIA. In general, the ECU controlled system
is considered to be a very intricate system requiring a high level of technical knowledge and expert skill to
troubleshoot. However, the fact is that if you proceed to inspect the circuits one by one, troubleshooting of
these systems is not complex. If you have adequate understanding of the system and a basic knowledge
of electricity, accurate diagnosis and necessary repair can be performed to locate and fix the problem. This
manual is designed through emphasis of the above standpoint to help service technicians perform accurate
and effective troubleshooting, and is compiled for the following major ECU controlled systems:
The troubleshooting procedure and how to make use of it are described on the following pages.
SystemPage
1. EngineDI±1
2. Automatic TransmissionDI±515
3. Air Suspension Control SystemDI±695
4. Tire Pressure Warning SystemDI±796
5. ABS with EBD & BA & TRAC & VSC SystemDI±891
6. Can Communication SystemDI±1060
7. Supplemental Restraint SystemDI±1118
8. Power Seat Control System w/ Driving Position MemoryDI±1501
9. Cruise Control SystemDI±1536
10.Engine Immobilizer SystemDI±1570
11. Combination Meter SystemDI±1601
12.Sliding Roof SystemDI±1661
13.Body Control SystemDI±1678
14.Driver Door Control SystemDI±1778
15.Passenger Door Control SystemDI±1814
16.Back Door Control SystemDI±1850
17.Multiplex Communication SystemDI±1887
18.Audio SystemDI±1955
19.Rear Seat Audio SystemDI±2044
20.Rear Seat Entertainment SystemDI±2078
21.Navigation SystemDI±2159
22.Air Conditioning SystemDI±2297
FOR USING OBD II SCAN TOOL OR TOYOTA HAND±HELD TESTER

Before using the scan tool or tester, the scan tool's instruction book or tester's operator manual should
be read thoroughly.

If the scan tool or tester cannot communicate with ECU controlled systems when you have connected
the cable of the scan tool or tester to DLC3, turned the ignition switch ON and operated the scan tool,
there is a problem on the vehicle side or tool side.
(1) If communication is normal when the tool is connected to another vehicle, inspect the diagnosis
data link line (Bus
line) or ECU power circuit of the vehicle.
(2) If communication is still not possible when the tool is connected to another vehicle, the problem
is probably in the tool itself, so perform the Self Test procedures outline in the Tester Operator's
Manual.

IN±26± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMS
26 Author: Date:
2005 SEQUOIA (RM1146U)
2. SYMPTOM CONFIRMATION AND DIAGNOSTIC TROUBLE CODE CHECK
The diagnostic system in the SEQUOIA fulfills various functions. The first function is the Diagnostic Trouble
Code Check in which a malfunction in the signal circuits to the ECU is stored in code in the ECU memory
at the time of occurrence, to be output by the technician during troubleshooting. Another function is the Input
Signal Check which checks if the signals from various switches are sent to the ECU correctly.
By using these check functions, the problem areas can be narrowed down quickly and troubleshooting can
be performed effectively. Diagnostic functions are incorporated in the following systems in the SEQUOIA.
SystemDiagnostic Trouble
Code CheckInput Signal Check
(Sensor Check)Diagnostic Test
Mode (Active Test)
1. Engine(with Check
Mode)
2. Automatic Transmission(with Check
Mode)
3. Air Suspension Control System(with Check
Mode)
4. Tire Pressure Warning System
5. ABS with EBD & BA & TRAC & VSC System
6. Can Communication System
7. Supplemental Restraint System(with Check
Mode)
8. Power Seat Control System w/ Driving Position Memory
9. Cruise Control System
10.Engine Immobilizer System
11. Combination Meter System
12.Sliding Roof System
13.Body Control System
14.Driver Door Control System
15.Passenger Door Control System
16.Back Door Control System
17.Multiplex Communication System
18.Audio System
19.Rear Seat Audio System
20.Rear Seat Entertainment System
21.Air Conditioning System
In diagnostic trouble code check, it is very important to determine whether the problem indicated by the diag-
nostic trouble code is still occurring or occurred in the past but returned to normal at present. In addition,
it must be checked in the problem symptom check whether the malfunction indicated by the diagnostic
trouble code is directly related to the problem symptom or not. For this reason, the diagnostic trouble codes
should be checked before and after the symptom confirmation to determine the current conditions, as shown
in the table on the next page. If this is not done, it may, depending on the case, result in unnecessary trouble-
shooting for normally operating systems, thus making it more difficult to locate the problem, or in repairs not
pertinent to the problem. Therefore, always follow the procedure in correct order and perform the diagnostic
trouble code check.

A23510
Vehicle Speed
(64 km/h and 113 km/h)Between
40 mph and 70 mph
Idling
Ignition Switch OFF
10 minutes
Time Warm up
(Note: Even when vehicle stops during driving pattern, test can be resumed)NOTICE:
This test will not be completed
if the vehicle is driven under
absolute constant speed
condition such as with cruise
control activated. (6)
(5) DI±28
± DIAGNOSTICSENGINE
222 Author: Date:
2005 SEQUOIA (RM1146U)
2. CATALYST MONITOR (ACTIVE AIR±FUEL RATIO CONTROL TYPE)
(a) Preconditions
The monitor will not run unless:

The MIL is OFF
(b) Drive Pattern
(1) Connect a hand±held tester or OBD II scan tool to the DLC3.
(2) Turn the ignition switch to ON.
(3) Turn the tester or scan tool ON.
(4) Clear DTCs (where set) (see page DI±43).
(5) Start the engine and warm it up.
(6) Drive the vehicle at between 40 mph and 70 mph (64 km/h and 113 km/h) for at least 10 minutes.
(c) Monitor Status
(1) Check the Readiness Monitor status displayed on the tester or scan tool.
(2) If the status does not switch to COMPL (complete), extend the driving time.

A23661
Vehicle Speed
(64 km/h and 113 km/h)Between
40 mph and 70 mph
Idling
Ignition Switch OFF
10 minutes
Time Warm up
(Note: Even if vehicle stops during driving pattern, test can be resumed)NOTICE:
This test will not be completed
if the vehicle is driven under
absolutely constant speed
conditions such as with cruise
control activated. (h)
(g)
MISFIRE MON ..................... AVAILREADINESS TESTS
CAT EVAL ......................... INCMPL
HTD CAT EVAL ...................... N/A
EVAP EVAL ....................... INCMPL
2nd AIR EVAL .......................... N/A
A/C EVAL ................................ N/A
O2S EVAL ........................ INCMPL
O2S HTR EVAL .................. INCMPL
EGR EVAL ...............................N/A COMP MON ........................ AVAIL FUEL SYS MON ................... AVAIL
A76855
A23660
DI±154
± DIAGNOSTICSENGINE
348 Author: Date:
2005 SEQUOIA (RM1146U)
CONFIRMATION DRIVING PATTER
HINT:

This confirmation driving pattern is used in steps 5, 8 and 11 of the following diagnostic troubleshooting
procedure when using either a hand±held tester.

Performing this confirmation pattern will activate the Heated Oxygen (HO2) sensor monitor. (The cata-
lyst monitor is performed simultaneously.) This is very useful for verifying the completion of a repair.
(a) Connect a hand±held tester to the DLC3.
(b) Turn the ignition switch to ON.
(c) Turn the tester or scan tool ON.
(d) Clear DTCs (where set) (see page DI±43).
(e) If using a hand±held tester, select the following menu
items: DIAGNOSIS / CARB OBD II / READINESS
TESTS.
(f) Check that O2S EVAL is INCMPL (incomplete).
(g) Start the engine and warm it up.
(h) Drive the vehicle at between 40 mph and 70 mph (64 km/h
and 113 km/h) for at least 10 minutes.
(i) Note the state of the Readiness Tests items. Those items
will change to COMPL (complete) as O2S EVAL monitor
operates.
(j) On the tester, select the following menu items: DIAGNO-
SIS / ENHANCED OBD II / DTC INFO / PENDING
CODES and check if any DTCs (any pending DTCs) are
set.
HINT:
If O2S EVAL does not change to COMPL, and any pending
DTCs fail to set, extend the driving time.

DIDEX±01
DI±1536
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1730 Author: Date:
2005 SEQUOIA (RM1146U)
CRUISE CONTROL SYSTEM
PRECAUTION
NOTICE:
When disconnecting the battery terminal, initialize the following system after the terminal is recon-
nected.
System NameSee Page
Back Door Power Window Control SystemBE±77

DI26R±41
Customer Problem Analysis
Check and Clear DTC
Vehicle Brought to Workshop
Problem Symptom ConfirmationSymptom Simulation Symptom does not occur
DTC CheckNormal system code
DTC Chart
Problem Symptoms Table
Circuit InspectionInput Signal Check
Parts Inspection
Identification of Problem
Repair
Confirmation Test
EndItems inside
are titles of pages in this
manual with the page number indicated in the
bottom portion. See the indicated pages for
detailed explanations. 1
2
34
5
6
7
89
10
Step 2, 5, 8, 10: Diagnostic steps permitting use of
the hand±held tester. P. DI±1538
P. DI±1545
P. DI±1545
P. DI±1549
P. IN±24
P. DI±1541
P. DI±1551 ± DI±1567
OKNG
Symptom occurs
Trouble code
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1537
1731 Author: Date:
2005 SEQUOIA (RM1146U)
HOW TO PROCEED WITH TROUBLESHOOTING
Troubleshoot in accordance with the following procedures:

DI26S±26
CRUISE CONTROL SYSTEM Check Sheet
Inspector 's name:
Customer 's Name
Date Vehicle
Odometer Reading / /
Condition of
Problem Occurrence
Date Problem
Frequency
Occurred
Problem Occurs
Vehicle Speed when
Problem Occurred / /
Continuous Intermittent ( Times a day)
km
mile Brought in
Auto cancel
occurs
Driving condition
 City driving  Freeway  Uphill  Downhill

After cancel occurred, did the driver activate cruise control
again?
 Yes  No
 Cancel does not
occur With brake ON
 Shifting into any position except D
 When control SW is pulled to CANCEL position
 Cruise control
malfunction Slip to acceleration side
 Slip to deceleration side
 Hunting occurs
 O/D cut±off does not occur
 O/D does not return
 Switch
malfunction SET  ACCEL  COAST  RESUME  CANCEL
 Remains ON  Does not light up  Blinks Symptoms
DTC Check1st Time2nd Time
 Normal System Code  Trouble Code (Code )
 Normal System Code  Trouble Code (Code )  CRUISE main
indicator lightVIN
Production Date
Licence Plate No.
km
mile DI±1538
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1732 Author: Date:
2005 SEQUOIA (RM1146U)
CUSTOMER PROBLEM ANALYSIS CHECK

DIDEY±01
I24838
(1)
(3)
I24838
(4)
(1)
(3)
I24838
(1)
(3)
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1539
1733 Author: Date:
2005 SEQUOIA (RM1146U)
ROAD TEST
1. PROBLEM SYMPTOM CONFIRMATION
(a) Inspect the SET function.
(1) Push the ON±OFF button on.
(2) Drive at the required speed (40 km/h (25 mph) or
higher).
(3) Push the cruise control main switch to ±/SET.
(4) Check that the vehicle cruises at the set speed.
(b) Inspect the ACC function.
(1) Push the ON±OFF button on.
(2) Drive at the required speed (40 km/h (25 mph) or
higher).
(3) Push the cruise control main switch to ±/SET.
(4) Check that vehicle speed increases while the cruise
control main switch is pushed to +/RES, and that the
vehicle cruises at the newly set speed when the
switch is released.
(5) Momentarily push the cruise control main switch to
+/RES and then immediately release it. Check that
vehicle speed increases by approximately 1.6 km/h
(1.0 mph) (Tap±up function).
(c) Inspect the COAST function.
(1) Push the ON±OFF button on.
(2) Drive at the required speed (40 km/h (25 mph) or
higher).
(3) Push the cruise control main switch to ±/SET.
(4) Check that vehicle speed decreases while the
cruise control main switch is pushed to ±/SET, and
that the vehicle cruises at the newly set speed when
the switch is released.
(5) Momentarily push the cruise control main switch to
±/SET, and then immediately release it. Check that
vehicle speed decreases by approximately 1.6
km/h (1.0 mph) (Tap±down function).
