2001 TOYOTA SEQUOIA Service Repair Manual

relay fuel reserve radio antenna high beam sunroof android auto

Page 1 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IN01O±10
N17080
Filler Cap
Float
Reservoir Tank
Grommet
Clip
Slotted Spring Pin
: Specified torque
Non±reusable partCylinder
Piston
Push Rod
Washer
Snap Ring
Boot
Gasket
Lock Nut
Clevis Pin
Cl

Page 2 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual Illustration:
what to do and where to do
21. CHECK PISTON STROKE OF OVERDRIVE BRAKE
(a)
Task heading : what to do
SST 09350±30020 (09350±06120)
Set part No. Component part No.
Detailed text : how

Illustration:
what to do and where to do
21. CHECK PISTON STROKE OF OVERDRIVE BRAKE
(a)
Task heading : what to do
SST 09350±30020 (09350±06120)
Set part No. Component part No.
Detailed text : how to do task
(b)
Piston stroke: 1.40 1.70 mm (0.0551 0.0669 in.)
Specification
Place SST and a dial indicator onto the overdrive brake pis-
ton as shown in the illustration.
Measure the stroke applying and releasing the compressed
air (392 785 kPa, 4 8 kgf/cm
2 or 57 114 psi) as shown
in the illustration. IN±2
± INTRODUCTIONHOW TO USE THIS MANUAL
2 Author: Date:
2005 SEQUOIA (RM1146U)
The procedures are presented in a step±by±step format:
The illustration shows what to do and where to do.
The task heading tells what to do.
The detailed text tells how to perform the task and gives other information such as specifications
and warnings.
Example:
This format provides the experienced technician with a FAST TRACK to the information needed. The upper
case task heading can be read at a glance when necessary, and the text below it provides detailed informa-
tion. Important specifications and warnings always stand out in bold type.
6. REFERENCES
References have been kept to a minimum. However, when they are required, you are given the page to refer
to.
7. SPECIFICATIONS
Specifications are presented in bold type throughout the text where needed. You never have to leave the
procedure to look up your specifications. They are also found in Service Specifications section for quick ref-
erence.
8. CAUTIONS, NOTICES, HINTS:
CAUTIONS are presented in bold type, and indicate there is a possibility of injury to you or other
people.
NOTICES are also presented in bold type, and indicate the possibility of damage to the components
being repaired.
HINTS are separated from the text but do not appear in bold. They provide additional information to
help you perform the repair efficiently.
9. SI UNIT
The UNITS given in this manual are primarily expressed according to the SI UNIT (International System of
Unit), and alternately expressed in the metric system and in the English System.
Example:
Torque: 30 N´m (310 kgf´cm, 22 ft´lbf)

Page 3 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IN0IF±02
B04769
A
B
B04198
2UZ±FE Engine:
± INTRODUCTIONIDENTIFICATION INFORMATION
IN±3
3 Author: Date:
2005 SEQUOIA (RM1146U)
IDENTIFICATION INFORMATION
VEHICLE IDENTIFICATION AND
ENGINE SERI

Page 4 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual FI1066
IN0D9±03
Z11554
Seal Lock Adhesive IN±4
± INTRODUCTIONREPAIR INSTRUCTIONS
4 Author: Date:
2005 SEQUOIA (RM1146U)
REPAIR INSTRUCTIONS
GENERAL INFORMATION
BASIC REPAIR HINT
(a) Prevent da

Page 5 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BE1367
Medium Current Fuse and High Current Fuse
Equal Amperage Rating
V00076
Abbreviation Part Name Symbol Illustration
FUSE
MEDIUM CURRENT FUSE
HIGH CURRENT FUSE
FUSIBLE LINK
CIRCUIT BREAKERFUSE
M±

Page 6 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IN0253
WRONG CORRECT
IN0252
WRONG CORRECT IN±6
± INTRODUCTIONREPAIR INSTRUCTIONS
6 Author: Date:
2005 SEQUOIA (RM1146U)
(k) Care must be taken when jacking up and supporting the
vehicle. Be sure

Page 7 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IN0002
Example
± INTRODUCTIONREPAIR INSTRUCTIONS
IN±7
7 Author: Date:
2005 SEQUOIA (RM1146U)
(7) When checking continuity at the wire connector, in-
sert the tester probe carefully to prevent te

Page 8 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IN0DY±04
B04771
JACK POSITION
Center of rear axle housing
SUPPORT POSITION
Safety stand Front
Center of cross member Front
Rear CAUTION: Do not use the swing arm type lift and plate type lift.
CAUTIO
