Page 4233 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
374
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
4±pin connector
7±pin connector
TRAILER LIGHTS
Your vehicle is equipped with a wire
harness stored in the rear end under
bod

Page 4234 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
375
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
MAINTENANCE
If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. For this info

05_SEQUOIA_U (L/O 0408)
375
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
MAINTENANCE
If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. For this informa-
tion, please refer to the scheduled
maintenance information in the ªSched-
uled Maintenance Guideº or ªOwner 's
Manual Supplementº.
Retighten all fixing bolts of the towing
ball and bracket after approximately
1000 km (600 miles) of trailer driving.
CONNECTING A TRAILER (models with
rear height control air suspension)
Stop your vehicle and a trailer in line and
perform the following:
1. Set the vehicle height to ªNº (normal)
in automatic control mode. Turn the
ignition switch off or select manual
control mode by pushing the mode se-
lect switch to turn off the automatic
leveling function.
2. Connect a trailer.
3. Turn the ignition switch on or select
automatic control mode by pushing the
mode select switch to turn on the auto-
matic leveling function.DISCONNECTING A TRAILER (models
with rear height control air suspension)
Stop your vehicle and a trailer in line and
perform the following:
1. Set the vehicle height to ªLOº in auto-
matic control mode. (Make sure the
ªLOº indicator comes on.)
2. Turn the ignition switch off or select
manual control mode by pushing the
mode select switch to turn off the auto-
matic leveling function.
3. Set the supporting leg of a trailer on
the ground and raise the hitch by 100
mm (4 in.).
4. Turn the ignition switch on or select
automatic control mode by pushing the
mode select switch to turn on the auto-
matic leveling function.
5. Wait for about 20 seconds until the
rear vehicle height is lowered by the
automatic leveling function.
6. Make sure the hitch is disconnected. If
not, raise the hitch higher and repeat
steps 2 through 5.
7. Move the vehicle forward in ªLOº mode
where the hitch does not touch any-
thing in ªNº mode.
8. Set the vehicle height to ªNº in auto-
matic control mode.PRE±TOWING SAFETY CHECK
Check that your vehicle remains level
when a loaded or unloaded trailer is
hitched. Do not drive if the vehicle has
an abnormal nose±up or nose±down
condition, and check for improper
tongue load, overload, worn suspension
or other possible causes.
Make sure the trailer cargo is securely
loaded so that it cannot shift.
Check that your rear view mirrors con-
form to any applicable federal, state/
provincial or local regulations. If not,
install the rear view mirrors required
for towing purpose.

Page 4235 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
376
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
TRAILER TOWING TIPS
When towing a trailer, your vehicle will
handle differently than when not tow-
ing. The three main causes of

05_SEQUOIA_U (L/O 0408)
376
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
TRAILER TOWING TIPS
When towing a trailer, your vehicle will
handle differently than when not tow-
ing. The three main causes of vehicle±
trailer accidents are driver error, exces-
sive speed and improper trailer loading.
Keep these in mind when towing:
Before starting out, check operation of
the lights and all vehicle±trailer connec-
tions. After driving a short distance,
stop and recheck the lights and con-
nections. Before actually towing a trail-
er, practice turning, stopping and back-
ing with a trailer in an area away from
traffic until you learn the feel.
Backing with a trailer is difficult and
requires practice. Grip the bottom of
the steering wheel and move your hand
to the left to move the trailer to the
left. Move your hand to the right to
move the trailer to the right. (This pro-
cedure is generally opposite to that
when backing without a trailer.) Also,
just turn the steering wheel a little at
a time, avoiding sharp or prolonged
turning. Have someone guide you when
backing to reduce the risk of an acci-
dent.
Because stopping distance may be in-
creased, vehicle±to±vehicle distance
should be increased when towing a
trailer. For each 16 km/h (10 mph) of
speed, allow at least one vehicle and
trailer length between you and the ve-
hicle ahead. Avoid sudden braking as
you may skid, resulting in jackknifing
and loss of control. This is especially
true on wet or slippery surfaces.
Avoid jerky starts or sudden accelera-
tion.
Avoid jerky steering and sharp turns.
The trailer could hit your vehicle in a
tight turn. Slow down before making a
turn to avoid the necessity of sudden
braking.
Remember that when making a turn,
the trailer wheels will be closer than
the vehicle wheels to the inside of the
turn. Therefore, compensate for this by
making a larger than normal turning
radius with your vehicle.
Crosswinds and rough roads will ad-
versely affect handling of your vehicle
and trailer, causing sway. Pay attention
to the rear from time to time to pre-
pare yourself for being passed by large
trucks or buses, which may cause your
vehicle and trailer to sway. If swaying
happens, firmly grip the steering wheel
and reduce speed immediately but
gradually. Never increase speed. Steer
straight ahead. If you make no extreme
correction with the steering or brakes,
the vehicle and trailer will stabilize.
Be careful when passing other ve-
hicles. Passing requires considerable
distance. After passing a vehicle, do
not forget the length of your trailer and
be sure you have plenty of room befo-
re changing lanes.
In order to maintain engine braking effi-
ciency, do not use overdrive.

Page 4236 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
377
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Because of the added load of the trail-
er, your vehicles engine may overheat
on hot days (at temperatures over
30C [85F]) w

Page 4237 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
378
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Improving fuel economy is easyÐjust take
it easy. It will help make your vehicle last
longer, too. Here are some specific tips

05_SEQUOIA_U (L/O 0408)
378
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Improving fuel economy is easyÐjust take
it easy. It will help make your vehicle last
longer, too. Here are some specific tips
on how to save money on both fuel and
repairs:
Keep your tires inflated at the cor-
rect pressure. Underinflation causes
tire wear and wastes fuel. See page
429 in Section 7±2 for instructions.
Do not carry unneeded weight in
your vehicle. Excess weight puts a
heavier load on the engine, causing
greater fuel consumption.
Avoid lengthy warm±up idling. Once
the engine is running smoothly, begin
drivingÐbut gently. Remember, howev-
er, that on cold winter days this may
take a little longer.
Keep the automatic transmission
overdrive turned on when engine
braking is not required. Driving with
the overdrive off will reduce the fuel
economy. (For details, see ªAutomatic
transmissionº on page 173 in Section
1±7.)
Accelerate slowly and smoothly.
Avoid jackrabbit starts. Get into high
gear as quickly as possible.
Avoid long engine idling. If you have
a long wait and you are not in traffic,
it is better to turn off the engine and
start again later.
Avoid engine lugging or over±rev-
ving. Use a gear position suitable for
the road on which you are travelling.
Avoid continuous speeding up and
slowing down. Stop±and±go driving
wastes fuel.
Avoid unnecessary stopping and
braking. Maintain a steady pace. Try
to time the traffic signals so you only
need to stop as little as possible or
take advantage of through streets to
avoid traffic lights. Keep a proper dis-
tance from other vehicles to avoid sud-
den braking. This will also reduce wear
on your brakes.
Avoid heavy traffic or traffic jams
whenever possible.
Do not rest your foot on the brake
pedal. This causes premature wear,
overheating and poor fuel economy.
Maintain a moderate speed on high-
ways. The faster you drive, the greater
the fuel consumption. By reducing your
speed, you will cut down on fuel con-
sumption.
Keep the front wheels in proper
alignment. Avoid hitting the curb and
slow down on rough roads. Improper
alignment not only causes faster tire
wear but also puts an extra load on
the engine, which, in turn, wastes fuel.
Keep the bottom of your vehicle free
from mud, etc. This not only lessens
weight but also helps prevent corro-
sion.
Keep your vehicle tuned±up and in
top shape. A dirty air cleaner, improp-
er valve clearance, dirty plugs, dirty oil
and grease, brakes not adjusted, etc.
all lower engine performance and con-
tribute to poor fuel economy. For longer
life of all parts and lower operating
costs, keep all maintenance work on
schedule, and if you often drive under
severe conditions, see that your vehicle
receives more frequent maintenance.
(For scheduled maintenance informa-
tion, please refer to the ªScheduled
Maintenance Guideº or ªOwner 's Manu-
al Supplementº.)
How to save fuel and make
your vehicle last longer

Page 4238 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
379
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
CAUTION
Never turn off the engine to coast
down hills. Your power steering and
brake booster will not function with-
out the en

Page 4239 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
380
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)

Page 4240 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
381
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
IN CASE OF AN EMERGENCY
In case of an emergency
If your vehicle will not start382 . . . . . . . . . . . . . . . . . . . . . . .
