Page 2905 of 4323
CH073±08
B16569
Generator Connector
Generator Wire
N´m (kgf´cm, ft´lbf): Specified torque
39 (400, 29)
Engine Under Cover
x 5 Drive BeltWire ClampPS Vane Pump
39 (400, 29)
Terminal Cap
Intake Air ConnectorThrottle Body Cover
39 (400, 29)
39 (400, 29)
15.5 (158, 11)
Generator
9.8 (100, 87 in.´lbf)
± CHARGINGGENERATOR
CH±5
2897 Author: Date:
2005 SEQUOIA (RM1146U)
GENERATOR
COMPONENTS
Page 2906 of 4323
B16695
Pulley
Front Bearing Bearing Retainer
Rear Bearing
Drive End Frame (Stator)Rotor
Generator Washer
Bearing Cover
Rectifier End Frame
Terminal Insulator
Brush Holder
Non±reusable partRear End Cover
N´m (kgf´cm, ft´lbf): Specified torque
110.3 (1,125, 81)
2.6 (27, 23 in.´lbf)
2.6 (27, 23 in.´lbf)
5.8 (59, 51 in.´lbf)
5.8 (59, 51 in.´lbf)
1.8 (18, 16 in.´lbf)
4.6 (47, 41 in.´lbf)
CH±6
± CHARGINGGENERATOR
2898 Author: Date:
2005 SEQUOIA (RM1146U)
Page 2907 of 4323
CH0LY±02
B00809
± CHARGINGGENERATOR
CH±7
2899 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE ENGINE UNDER COVER
2. REMOVE THROTTLE BODY COVER
3. DISCONNECT CABLE FROM NEGATIVE (±) BATTERY
TERMINAL
4. DISCONNECT INTAKE AIR CONNECTOR FROM
THROTTLE BODY
5. REMOVE DRIVE BELT
Loosen the belt tension by turning the belt tensioner counter-
clockwise, and remove the drive belt.
HINT:
The pulley bolt for the belt tensioner has a left hand thread.
6. REMOVE PS VANE PUMP FROM ENGINE
(See page SR±28)
7. REMOVE GENERATOR
(a) Disconnect the generator connector.
(b) Remove the terminal cap and nut, and disconnect the
generator wire.
(c) Disconnect the wire clamp from the cord clip on the gener-
ator.
(d) Remove the bolt, the 2 nuts and the generator.
Page 2908 of 4323

CH0LZ±02
B16358
B16369SST (B)
SST (A)
Turn
B16371
SST (C)
SST (B)
Insert
B16372
SST (C)
SST (A)
Turn
B16370
Turn
SST (A)
SST (B)
CH±8
± CHARGINGGENERATOR
2900 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE REAR END COVER
(a) Remove the 3 nuts the and end cover.
(b) Remove the terminal insulator.
2. REMOVE BRUSH HOLDER
(a) Remove the 2 screws and brush holder.
3. REMOVE PULLEY
(a) Hold SST (A) with a torque wrench, and tighten SST (B)
clockwise to the specified torque.
SST 09820±63011
Torque: 39 N´m (400 kgf´cm, 29 ft´lbf)
(b) Check that SST (A) is secured to the rotor shaft.
(c) Mount SST (C) in a vise.
(d) Insert SST (B) into SST (C), and attach the pulley nut to
SST (C).
(e) To loosen the pulley nut, turn SST (A) in the direction
shown in the illustration.
NOTICE:
To prevent damage to the rotor shaft, do not
loosen the pulley nut more than one±half of a turn.
(f) Remove the generator from SST (C).
(g) Turn SST (B), and remove SST (A and B).
(h) Remove the pulley nut and pulley.
Page 2909 of 4323
B16364
B16366
SST
± CHARGINGGENERATOR
CH±9
2901 Author: Date:
2005 SEQUOIA (RM1146U)
4. REMOVE COIL ASSEMBLY
(a) Remove the 4 bolts.
(b) Using SST, remove the coil assembly.
SST 09950±40011 (09951±04020, 09952±04010
09953±04020, 09954±04010, 09955±04071,
09958±04011)
(c) Remove the generator washer.
5. REMOVE ROTOR FROM DRIVE END FRAME
Page 2910 of 4323

CH0M0±02
B12264
Ohmmeter
Continuity
B12265
Ohmmeter
No Continuity
B12266
B16374
Length CH±10
± CHARGINGGENERATOR
2902 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. INSPECT ROTOR
(a) Check the rotor for open circuit.
Using an ohmmeter, check that there is continuity be-
tween the slip rings.
Standard resistance: 1.5 to 1.9 W at 20°C (68°F)
If there is no continuity, replace the rotor.
(b) Check the rotor for ground.
Using an ohmmeter, check that there is no continuity be-
tween the slip ring and rotor.
If there is continuity, replace the rotor.
(c) Check that the slip rings are not rough or scored.
If rough or scored, replace the rotor.
(d) Using vernier calipers, measure the slip ring diameter.
Standard diameter: 14.2 to 14.4 mm (0.559 to 0.567 in.)
Minimum diameter: 14.0 mm (0.551 in.)
If the diameter is less than the minimum, replace the rotor.
2. INSPECT BRUSHES
Using vernier caliper, measure the exposed brush length.
Standard exposed length: 10.5 mm (0.413 in.)
Minimum exposed length: 4.5 mm (0.177 in.)
If the exposed length is less than the minimum, replace the
brushes and the brush holder assembly.
3. INSPECT BEARING
Check the bearing is not rough or worn.
If necessary, replace the bearing (See page CH±11).
Page 2911 of 4323
CH0M1±02
B16375
B16387
Socket Wrench
SST
B16386
SST
B12270
SST
B12272
SST
± CHARGINGGENERATOR
CH±11
2903 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
1. REPLACE FRONT BEARING
(a) Remove the 4 screws, the bearing retainer and the bear-
ing.
(b) Using SST and a hammer, tap out the bearing.
SST 09950±60010 (09951±00250), 09950±70010
(09951±07100)
(c) Using SST and a press, press in a new bearing.
SST 09950±60010 (09951±00470), 09950±70010
(09951±07100)
(d) Install the bearing retainer with the 4 screws.
Torque: 2.6 N´m (27 kgf´cm, 23 in.´lbf)
2. REPLACE REAR BEARING
(a) Using SST, remove the bearing cover (outside) and the
bearing.
SST 09820±00021
NOTICE:
Be careful not to damage the fan.
(b) Using SST and a press, press in a new bearing.
SST 09820±00031
Page 2912 of 4323
B12273
SST
CH±12
± CHARGINGGENERATOR
2904 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Using SST, push in the bearing cover (outside).
SST 09285±76010
