FRONT LOWER BALL JOINT
ON±VEHICLE INSPECTION
INSPECT LOWER BALL JOINT EXCESSIVE PLAY ON±VE-
HICLE
(a) Remove the front wheel and install the hub nuts to the
disc.
(b) Using a dial indicator, check the lower ball joint for exces-
sive play when you push the hub nuts up and down with
a force of 294 N (30 kgf, 66 lbf).
Maximum: 0.5 mm (0.020 in.)
Page 3090 of 4323
SA244±06
F07280
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
Tie Rod End
Cotter Pin Lower Suspension ArmLower Ball Joint Cotter Pin
91 (930, 67)
65 (663, 48)
159 (1,621, 117)
SA±86
± SUSPENSION AND AXLEFRONT LOWER BALL JOINT
3082 Author: Date:
2005 SEQUOIA (RM1146U)
COMPONENTS
Page 3091 of 4323
SA245±05
R13300
R13425
SST
R12863
SST
± SUSPENSION AND AXLEFRONT LOWER BALL JOINT
SA±87
3083 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE FRONT WHEEL
2. LOOSEN 4 LOWER BALL JOINT SET BOLTS
HINT:
Do not remove the bolts.
3. DISCONNECT TIE ROD END
(a) Remove the cotter pin and nut from the tie rod end.
(b) Using SST, disconnect the tie rod end from the lower ball
joint.
SST 09610±20012
4. REMOVE LOWER BALL JOINT
(a) Remove the cotter pin and nut from the lower ball joint.
(b) Using SST, disconnect the lower ball joint from the lower
suspension arm.
SST 09628±62011
(c) Remove the 4 lower ball joint set bolts.
(d) While lifting the upper suspension arm and steering
knuckle, remove the lower ball joint.
(e) Support the upper suspension arm and steering knuckle
securely.
Page 3092 of 4323
SA246±04
R12777
SA±88
± SUSPENSION AND AXLEFRONT LOWER BALL JOINT
3084 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. INSPECT LOWER BALL JOINT BOOT FOR DAMAGE
2. INSPECT LOWER BALL JOINT FOR ROTATION
CONDITION
(a) As shown in the illustration, flip the ball joint stud back and
forth 5 times before installing the nut.
(b) Using a torque wrench, turn the nut continuously 1 turn
per 3 to 5 seconds and take the torque reading on the 5th
turn.
Turning torque:
1.0 ± 6.5 N´m (10 ± 66 kgf´cm, 9 ± 56 in.´lbf)
Page 3093 of 4323

SA247±07
± SUSPENSION AND AXLEFRONT LOWER BALL JOINT
SA±89
3085 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL LOWER BALL JOINT
(a) While lifting the upper suspension arm and steering knuckle, install the lower ball joint.
(b) Temporarily install the 4 bolts to the lower ball joint.
(c) Install the set nut to hold the lower ball joint to the lower suspension arm and a new cotter pin.
Torque: 159 N´m (1,621 kgf´cm, 117 ft´lbf)
If the holes for the cotter pin are not aligned, tighten the nut further up to 60°.
2. CONNECT TIE ROD END
Connect the tie rod end to the lower ball joint with the nut and a new cotter pin.
Torque: 91 N´m (930 kgf´cm, 67 ft´lbf)
If the holes for the cotter pin are not aligned, tighten the nut further up to 60°.
3. TIGHTEN LOWER BALL JOINT SET 4 BOLTS
Torque: 65 N´m (663 kgf´cm, 48 ft´lbf)
4. INSTALL FRONT WHEEL
Torque: 110 N´m (1,150 kgf´cm, 83 ft´lbf)
5. CHECK FRONT WHEEL ALIGNMENT (See page SA±4)
6. PERFORM ZERO POINT CALIBRATION OF STEERING ANGLE, MASTER CYLINDER PRES-
SURE, YAW RATE AND DECELERATION SENSORS (See page DI±897)
Page 3094 of 4323
SA188±04
W01737
Stabilizer Bar
Retainer
N´m (kgf´cm, ft´lbf)Retainer
Stabilizer Bar Link
: Specified torqueStabilizer Bar
Bracket
Bushing
Non±reusable part
19 (190, 14)
37 (377, 27)
69 (700, 51)
69 (700, 51)
19 (190, 14)
Bushing
37 (377, 27)
SA±90
± SUSPENSION AND AXLEFRONT STABILIZER BAR
3086 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT STABILIZER BAR
