TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
174
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
(c) Overdrive switch
You can select either fourth gear (with
overdrive off) or fifth gear (with overdrive
on) by pushing this sw

05_SEQUOIA_U (L/O 0408)
174
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
(c) Overdrive switch
You can select either fourth gear (with
overdrive off) or fifth gear (with overdrive
on) by pushing this switch.
To turn the overdrive off, push the switch.
The ªO/D OFFº indicator light should come
on. To turn the overdrive on again, push
the switch again. The ªO/D OFFº indicator
light should go off.
Always drive your vehicle with the over-
drive on for better fuel economy and
quieter driving.
If the engine is turned off when the over-
drive is off and restarted, the overdrive
will be on automatically.When the cruise control is being used,
even if you downshift the transmission by
pushing and releasing the overdrive
switch, engine braking will not be enabled
because the cruise control is not can-
celled.
For ways to decrease the vehicle speed,
see ªCruise controlº on page 205 in this
Section.
(d) Normal driving
1. Start the engine as instructed in ªHow
to start the engineº on page 362 in
Section 3. The transmission must be in
ªPº or ªNº.
When the front drive control is in ª4LOº
mode (low speed, four±wheel drive), the
driving pattern selector setting has no ef-
fect on gear shift timing. (See ªFour±wheel
drive systemº on page 177 in this Section
for information on the front drive control.)
2. With your foot holding down the brake
pedal, shift the selector lever to ªDº.
When the lever is in the ªDº position, the
automatic transmission system will select
the most suitable gear for running condi-
tions such as normal cruising, hill climb-
ing, hard towing, etc.If the engine coolant temperature is low
or when the front drive control is in ª4LOº
mode (low speed, four±wheel drive), the
transmission will not shift into the over-
drive gear even with the overdrive on.
(See ªFour±wheel drive systemº on page
177 in this Section for information of the
front drive control.)
CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake
pedal. Depress the accelerator pedal
slowly for smooth starting.
If the automatic locking operation linked to
shift lever position is set, all doors are
automatically locked when the shift lever
is moved out of ªPº position after the
ignition switch is turned to the ªONº posi-
tion and all the doors are closed. For
details, see ªÐAutomatic door locking and
unlocking functionsº on page 27 in Section
1±2.

Page 4034 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
175
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
(e) Using engine braking
To use engine braking, you can downshift
the transmission as follows:
Push the overdrive switch. Th

Page 4035 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
176
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
(f) Using the ª3º, ª2º and ªLº, posi-
tions
The ª3º, ª2º and ªLº positions are used for
strong engine braking as de

05_SEQUOIA_U (L/O 0408)
176
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
(f) Using the ª3º, ª2º and ªLº, posi-
tions
The ª3º, ª2º and ªLº positions are used for
strong engine braking as described pre-
viously.
With the selector lever in ª3º, ª2º or
ªSHIFT Lº switch depressed, the vehicle
can start just as if the lever was in ªDº.
With the selector lever in ª3º or ª2º, the
vehicle will start in first gear and automat-
ically shift to second gear.
With the ªSHIFT Lº switch depressed, the
transmission is engaged in first gear.NOTICE
Be careful not to over±rev the en-
gine. Watch the tachometer to keep
engine rpm from going into the red
zone. The approximate maximum al-
lowable speed for each position is
given above for your reference:
Two±wheel drive models
ª3º 135 km/h (84 mph). . . . . . .
ª2º 90 km/h (56 mph). . . . . . . .
ªLº 50 km/h (31 mph). . . . . . . .
Four±wheel drive models
ª2WDº or ª4HIº mode
ª3º 135 km/h (84 mph). . . . . . .
ª2º 90 km/h (56 mph). . . . . . . .
ªLº 50 km/h (31 mph). . . . . . . .
ª4LOº mode
ª3º 50 km/h (31 mph). . . . . . . .
ª2º 35 km/h (21 mph). . . . . . . .
ªLº 20 km/h (12 mph). . . . . . . .
Do not continue hill climbing or
hard towing for a long time in the
ª3º, ª2º or ªLº position. This may
cause severe automatic transmis-
sion damage from overheating. To
prevent such damage, ªDº position
should be used in hill climbing or
hard towing.
(g) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with
your foot, shift the selector lever to the
ªRº position.
NOTICE
Never shift into reverse while the ve-
hicle is moving.
(h) Parking
1. Bring the vehicle to a complete stop.
2. With the brake pedal pressed down,
fully depress the parking brake pedal
to apply the parking brake securely.
3. With the brake pedal pressed down,
shift the selector lever to the ªPº posi-
tion.
CAUTION
Never attempt to move the selector
lever into ªPº position under any cir-
cumstances while the vehicle is mov-
ing. Serious mechanical damage and
loss of vehicle control may result.

Page 4036 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
177
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
If the automatic unlocking operation linked
to shift lever position is set, all doors are
automatically unlocked when the select

Page 4037 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
178
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Use the front drive control switches
and center differential lock switch to
select the transfer and center differen-
tial modes.

05_SEQUOIA_U (L/O 0408)
178
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Use the front drive control switches
and center differential lock switch to
select the transfer and center differen-
tial modes.
In the ª4HIº and ª4LOº mode, you can
choose to lock or unlock the center differ-
ential.
Use the center differential lock system if
your wheels get stuck in a ditch, or when
you are driving on a slippery or bumpy
surface. When the center differential is
locked, the vehicle stability control system
is automatically turned off and the center
differential lock and ªVSC OFFº indicator
lights come on because the function that
controls engine performance interferes
with the process of freeing your wheels.
NOTICE
As soon as the center differential lock
switch is turned on, the ªVSC OFFº
indicator light comes on. After the
wheels are out of the ditch or off the
slippery or bumpy surface, turn the
center differential lock switch off.
Make sure that the center differential
lock indicator light and ªVSC OFFº
indicator light turn off.
ª2WDº mode (high speed, two±wheel
drive)
This mode is the normal driving mode. In
this mode, the ª4HIº and ª4LOº indicator
lights are turned off.
Use this for normal driving on dry hard±
surfaced roads. This position gives greater
economy, quietest ride, least wear and
better vehicle control.
ª4HIº mode (high speed, four±wheel
drive, center differential unlocked)
To select this mode, press the ª2WD/4HIº
switch only. The ª4HIº indicator light
comes on.
Use this for normal driving on all types of
roads, from dry hard±surfaced roads to
wet, icy or snow±covered roads. This
position provides greater traction than
two±wheel drive.ª4HIº mode (high speed, four±wheel
drive, center differential locked)
To select this mode, press the ª2DW/4HIº
switch, and then the center differential
lock switch. The ª4HIº and the center dif-
ferential lock indicator lights come on.
Use this for greater traction when you
experience a loss of power, such as
wheel slipping, in the center differential
unlock mode.
ª4LOº mode (low speed, four±wheel
drive, center differential unlocked)
To select this mode, press the ª4LOº
switch only. The ª4LOº indicator light
comes on.
Use this for maximum power and traction.
Use this for climbing steep hills, off±road
driving, and hard pulling in sand or mud.
In this mode, the braking feeling that oc-
curs when the wheels are negotiating a
sharp corner is further reduced than in the
ª4LOº (low speed, four±wheel drive, center
differential locked) mode.

Page 4038 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
179
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
ª4LOº mode (low speed, four±wheel
drive, center differential locked)
To select this mode, press the ª4LOº
switch, and then

05_SEQUOIA_U (L/O 0408)
179
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
ª4LOº mode (low speed, four±wheel
drive, center differential locked)
To select this mode, press the ª4LOº
switch, and then press the center differen-
tial lock switch. The ª4LOº and the center
differential lock indicator lights come on.
Use this for maximum power and traction.
Use this for hard pulling in situations the
vehicle cannot negotiate even in ª4LOº
(low speed, four±wheel drive, center differ-
ential unlocked) mode. Also, using this
mode when driving down steep off±road
inclines will help contribute to increased
vehicle stability.
The indicator light tells when the differen-
tial lock is engaged. Note that the differ-
ential is not still locked as long as the
indicator light remains off.
When the operation is not completed, the
indicator blinks. If the indicator light does
not go off when you push out the center
differential lock switch, drive straight
ahead while accelerating or decelerating,
or drive in reverse.
If the center differential lock system op-
eration is not completed within 5 seconds
while the cruise control system is set,
cancel the cruise control system. To can-
cel the cruise control system, see ªCruise
controlº on page 205 in Section 1±7.If the indicator blinks even if doing so,
contact your Toyota dealer as soon as
possible. There may be a trouble in the
center differential lock system.
See ª(c) Shifting procedureº for further in-
structions.
Advice for driving on slippery roads in
ª4LOº (low speed, four±wheel drive)
mode
If you press the ª4LOº switch and shift
the automatic transmission lever to ª2º
when you drive in steep off±road areas,
the output of the brake can be controlled
effectively by the active traction control
system, which assists the driver to control
the driving power of 4 wheels.
Use the ªLº position of the automatic
transmission for maximum power and trac-
tion when your wheels get stuck or when
you drive down a steep incline. The output
of the brake can be controlled by the
active traction control system if the engine
speed is under 3000 rpm (normally engine
speed is under 3000 rpm when the wheels
get unstuck), in the following cases:
The front drive control in ª4LOº mode
and the automatic transmission in ªLº
or the automatic transmission in ªDº,
ª3º or ª2º with the transmission down-
shifting to the first gear
The front drive control in ª4LOº mode
and the automatic transmission in ªRº
(As for the automatic transmission shift
positions, see ªAutomatic transmissionº on
page 173 in this Section.)

Page 4039 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
180
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
The A.D.D. can be engaged or disen-
gaged by the shifting operations des-
cribed in ª(c) Shifting procedureº.
You should drive

Page 4040 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
181
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
NOTICE
Do not drive on a dry paved surface
in ª4HIº (LOCKED) mode. This may
damage the locking mechanism and
the drive system.

Load next 8 pages

Page: < prev 1-10 ... 4001-4008 4009-4016 4017-4024 4025-4032 4033-4040 4041-4048 4049-4056 4057-4064 4065-4072 ... 4328 next >

mileage belt fuses wiper fluid steering wheel adjustment child seat
