Page 3241 of 4323

F13254
INOUTAttachment
Pressure Feed Tube
SST
Z15498
Oil
Reservoir
PS Vane
Pump PS Gear
SST Closed
Z15499
Oil
Reservoir
PS Vane
Pump PS Gear
SST Open SR±6
± STEERINGPOWER STEERING FLUID
3233 Author: Date:
2005 SEQUOIA (RM1146U)
2. CHECK STEERING FLUID PRESSURE
(a) Remove the air cleaner assembly with the air cleaner
hose connected (See page SR±26).
(b) Disconnect the pressure feed tube from the PS vane
pump (See page SR±26).
(c) Connect SST, as shown in the illustration.
SST 09640±10010 (09641±01010, 09641±01030,
09641±01060)
NOTICE:
Check that the valve of the SST is in the open position.
(d) Bleed the power steering system (See page SR±4).
(e) Start the engine and run at idle.
(f) Turn the steering wheel from the lock position to the other
side of lock position several times to boost fluid tempera-
ture.
Fluid temperature: 80 °C (176 °F)
(g) With the engine idling, close the valve of the SST and ob-
serve the reading on the SST.
Minimum fluid pressure:
8,336 kPa (85 kgf/cm
2, 1,209 psi)
NOTICE:
Do not keep the valve closed for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(h) With the engine idling, open the valve fully.
(i) Measure the fluid pressure at engine speeds of 1,000 rpm
and 3,000 rpm.
Difference in fluid pressure:
490 kPa (5 kgf/cm
2, 71 psi) or less
NOTICE:
Do not turn the steering wheel.
Page 3242 of 4323
Z15500
Oil
Reservoir
PS Vane
Pump PS Gear
SST Open Lock Position
± STEERINGPOWER STEERING FLUID
SR±7
3234 Author: Date:
2005 SEQUOIA (RM1146U)
(j) With the engine idling and the valve fully opened, turn the
steering wheel left or right to the full lock position.
Minimum fluid pressure:
8,336 kPa (85 kgf/cm
2, 1,209 psi)
NOTICE:
Do not maintain the lock position for more than 10 se-
conds.
Do not let the fluid temperature become too high.
(k) Disconnect the SST.
SST 09640±10010 (09641±01010, 09641±01030,
09641±01060)
(l) Connect the pressure feed tube (See page SR±36).
(m) Install the air cleaner assembly with air cleaner hose (See
page SR±36).
(n) Bleed air from the power steering system
(See page SR±4).
Page 3243 of 4323
F06726Vacuum Hose
SR01X±08
SR±8
± STEERINGAIR CONTROL VALVE
3235 Author: Date:
2005 SEQUOIA (RM1146U)
AIR CONTROL VALVE
INSPECTION
1. TURN AIR CONDITIONING SWITCH OFF
2. CHECK IDLE±UP
(a) Start the engine and run it at idle.
(b) Fully turn the steering wheel.
(c) Check that the engine speed decrease when the vacuum
hose of the air control valve is pinched.
(d) Check that the engine speed increase when the hose is
released.
Page 3244 of 4323
R07653
SR01Y±11
R09732
± STEERINGSTEERING WHEEL
SR±9
3236 Author: Date:
2005 SEQUOIA (RM1146U)
STEERING WHEEL
INSPECTION
1. CHECK STEERING WHEEL FREE PLAY
(a) Stop the vehicle and face the tires straight ahead.
(b) Gently rock the steering wheel up and down with a finger,
and check the steering wheel free play.
Maximum free play: 30 mm (1.18 in.)
2. CHECK STEERING EFFORT
(a) Center the steering wheel.
(b) Remove the steering wheel pad (See page SR±12).
(c) Start the engine and run at idle.
(d) Measure the steering effort in both directions.
Steering effort (Reference):
4.9 N´m (50 kgf´cm, 43 in.´lbf)
HINT:
Check tire type, pressure and contact surface before making
your diagnosis.
(e) Tighten the steering wheel set nut.
Torque: 50 N´m (510 kgf´cm, 37 ft´lbf)
(f) Install the steering wheel pad (See page SR±23).
Page 3245 of 4323
SR1HO±08
F16015
Steering Wheel
Masking Tape
Steering Column
Upper Cover
F16016
Steering Column
Upper Cover
Marked Line
Steering
Wheel
Masking
Tape
SR±10
± STEERINGSTEERING WHEEL
3237 Author: Date:
2005 SEQUOIA (RM1146U)
REPAIR PROCEDURES
HINT:
This is the repair procedure for steering off center.
1. INSPECT STEERING WHEEL OFF CENTER
(a) Apply masking tape on the top center of the steering
wheel and steering column upper cover.
(b) Drive the vehicle in a straight line for 100 meters at a
constant speed of 35 mph (56 km/h), and hold the steer-
ing wheel to maintain the course.
(c) Draw a line on the masking tape as shown in the illustra-
tion.
Page 3246 of 4323

F16017
Steering Column
Upper Cover
New Marked
Line
Steering Wheel
R00429
Marked Line
F16018
± STEERINGSTEERING WHEEL
SR±11
3238 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Turn the steering wheel to its straight position.
HINT:
Refer to the upper surface of the steering wheel, steering spoke
and SRS airbag line for the straight position.
(e) Draw a new line on the masking tape of the steering wheel
as shown in the illustration.
(f) Measure the distance between the 2 lines on the masking
tape of the steering wheel.
(g) Convert the measured distance to steering angle.
Measured distance 1 mm (0.04 in.) = Steering angle
approximately 1 deg.
HINT:
Make a note of the steering angle.
2. ADJUST STEERING ANGLE
(a) Draw a line on the RH and LH tie rod and rack ends where
it can easily be seen.
(b) Using a paper gauge, measure the distance from RH and
LH tie rod ends to the rack end screws.
HINT:
Measure the RH side and LH side.
Make a note of the measured values.
(c) Remove the RH and LH boot clips from the rack boots.
(d) Loosen the RH and LH lock nuts.
(e) Turn the RH and LH rack end by the same amount (but
in different directions) according to the steering angle.
1 turn 360 deg. of rack end (1.5 mm (0.059 in.) horizon-
tal movement) = 12 deg. of steering angle
(f) Tighten the RH and LH lock nuts.
Torque: 55 N´m (560 kgf´cm, 41 ft´lbf)
NOTICE:
Make sure that the difference in length between RH and LH
tie rod ends and rack end screws are within 1.5 mm (0.059
in.).
(g) Install the RH and LH boot clips.
Page 3247 of 4323
SR1F3±03
F17895
Steering Wheel Pad
Steering
Wheel
Column Lower
CoverCombination
SwitchSteering Column Assembly
Transmission Control
Cable Assembly
Lower LH Finish PanelColumn Hole
Cover No. 2
No. 2 Universal
Joint Assembly
No. 2 Heater to Register Dust Torx® Screw
35 (360, 26)
35 (360, 26)
8.0 (82, 71 in.´lbf)
26 (260, 19)
26 (260, 19)
8.8 (90, 78 in.´lbf)
50 (510, 37)
8.8 (90, 78 in.´lbf)
Front Door Scuff PlateCowl Side Trim
Hood Lock
Release Lever
8.0 (82, 71 in.´lbf)
Side Panel
No. 2 Intermediate
Shaft AssemblyBrake Pedal
Return Spring
Column Upper Cover
N´m (kgf´cm, ft´lbf): Specified torque
Steering Wheel Lower
No. 3 Cover
Steering Wheel Lower
No. 2 Cover
35 (360, 26)
Sliding Yoke
Torx® Screw SR±12
± STEERINGTILT STEERING COLUMN
3239 Author: Date:
2005 SEQUOIA (RM1146U)
TILT STEERING COLUMN
COMPONENTS
Page 3248 of 4323
F13256
Non±reusable part
Molybdenum disulfide lithium base grease
: Specified torqueN´m (kgf´cm, ft´lbf)Column Upper
Bracket
Key Cylinder Key Unlock
Warning Switch
Ignition Switch
10.5 (110, 8)Column Tube
Assembly
2.2 (23, 19 in.´lbf)
Spring Guide
Tilt Spring Main Shaft Assembly Steering Column Housing
Tilt Lever Release Lever SpringTurn Signal Bracket
Compression
SpringSpring
Retainer Upper Bearing Inner Race Seat
Inner Race
12 (120, 9)
Pivot Pin
Spring
Park Lock Cable
Assembly
Shaft Bearing
Main Shaft Stopper
Pivot Pin Shift Lever
Housing
18 (180, 13)
Shift Lever
No. 2 Steering Column Ring
Tilt Lever Lock Shaft9.0 (90, 78 in.´lbf)
7.5 (75, 65 in.´lbf)
2.9 (29, 25 in.´lbf)
Transponder Key Coil
Key Cylinder
Lamp Assembly
Screw
Transponder Key Amplifier
Tilt No. 1
Stopper
± STEERINGTILT STEERING COLUMN
SR±13
3240 Author: Date:
2005 SEQUOIA (RM1146U)
