Page 641 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A23475
Pressure GaugePressure Sensor
± DIAGNOSTICSENGINE
DI±439
633 Author: Date:
2005 SEQUOIA (RM1146U)
12 Check air pump operation.
PREPARATION:
(a) Connect the pressure gauge to the air swit

Page 642 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±440
± DIAGNOSTICSENGINE
634 Author: Date:
2005 SEQUOIA (RM1146U)
13 Check whether DTC output recurs.
PREPARATION:
(a) Start the engine and warm it up.
(b) Turn the ignition switch OFF.
(c) Co

Page 643 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual B17443
Wire Harness Side:
Air Injection Driver Connector
A40
B17438
Wire Harness Side:
Air Pump Connector
A43
± DIAGNOSTICSENGINE
DI±441
635 Author: Date:
2005 SEQUOIA (RM1146U)
14 Check for ope

Page 644 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A23667
Soak Timer Circuit
Ignition Switch
IGSW
Power
ECM
EFI MAIN
MREL+B
15 ASource IC
Soak Timer ICMain Relay
Control IC
Battery DI±442
± DIAGNOSTICSENGINE
636 Author: Date:
2005 SEQUOIA (RM114

Page 645 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSENGINE
DI±443
637 Author: Date:
2005 SEQUOIA (RM1146U)
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page

Page 646 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±444
± DIAGNOSTICSENGINE
638 Author: Date:
2005 SEQUOIA (RM1146U)
DTC U0001 High Speed Can Communication Circuit
CIRCUIT DESCRIPTION
The engine control unit and the transmission control unit a

Page 647 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSENGINE
DI±445
639 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P043E Evaporate Emission System Reference Ori-
fice Clog Up
DTC P043F Evaporate Emission System Reference Ori-
fice High F

Page 648 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A23480
Fuel Tank Canister
Vacuum Pump: OFF Pressure Sensor 0.02 Inch Orifice
Pump Module
Operation A: Atmospheric Pressure Measurement
Vent Valve: OFF (vent)
Operation D: Purge VSV monitor Operation

A23480
Fuel Tank Canister
Vacuum Pump: OFF Pressure Sensor 0.02 Inch Orifice
Pump Module
Operation A: Atmospheric Pressure Measurement
Vent Valve: OFF (vent)
Operation D: Purge VSV monitor Operation B: 0.02 Inch Leak Pressure Measurement
Negative
Pressure Atmospheric
Pressure
Operation C: EVAP Leak Check
Air Filter
Purge VSV: OFFOFF (vent)
ON
OFF
OFF
ON
ON (closed)ON
ON
ON (closed)
DI±446
± DIAGNOSTICSENGINE
640 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR DESCRIPTION
5 hours* after the ignition switch is turned OFF, the electric vacuum pump creates negative pressure (vacu-
um) in the EVAP (Evaporative Emission) system. The ECM monitors for leaks and actuator malfunctions
based on the EVAP pressure.
HINT:
*: If the engine coolant temperature is not below 35C (95F) after 5 hours after the ignition switch is turned
off, the monitor check starts 2 hours later. If it is still not below 35C (95F) 7 hours after the ignition switch
is turned off, the monitor check starts 2.5 hours later.
SequenceOperationsDescriptionsDuration
±ECM activationActivated by soak timer, 5 hours (7 or 9.5 hours) after ignition switch turned to OFF.±
AAtmospheric pressure
measurement
Vent valve turned OFF (vent) and EVAP system pressure measured by ECM in order to
register atmospheric pressure.
If EVAP pressure is not between 70 kPa and 110 kPa (525 mmHg and 825 mmHg), ECM
cancels EVAP system monitor.
10 seconds
B
First 0.02 inch leak
pressure measure-
mentIn order to determine 0.02 inch leak pressure standard, vacuum pump creates negative pres-
sure (vacuum) through 0.02 inch orifice and then ECM checks if vacuum pump and vent
valve operate normally.
60 seconds
CEVAP system pres-
sure measurement
Vent valve turned ON (closed) to shut EVAP system.
Negative pressure (vacuum) created in EVAP system, and EVAP system pressure then
measured.
Write down the measured value as it will be used in the leak check.
If EVAP pressure does not stabilize within 15 minutes, ECM cancels EVAP system monitor.
15 minutes*
DPurge VSV monitorPurge VSV opened and then EVAP system pressure measured by ECM.
Large increase indicates normal.10 seconds
E
Second 0.02 inch leak
pressure measure-
mentLeak check is performed after second 0.02 inch leak pressure standard is measured.
If stabilized system pressure higher than second 0.02 inch leak pressure standard, ECM
determines that EVAP system leaking.
60 seconds
FFinal checkAtmospheric pressure measured and then monitoring result recorded by ECM.±
* If only a small amount of fuel is in the fuel tank, it takes longer for the EVAP pressure to stabilize.
