Page 4041 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
182
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
The traction control system automatical-
ly helps prevent the spinning of rear
wheels when the vehicle is started or
accelerated

Page 4042 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
183
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
TRACTION CONTROL OFF MODE
If your wheels get stuck in a ditch
when you are driving on a severe off
road and sand, turn off the t

Page 4043 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
184
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
The brake pad or actuator temperature
increases during continuous operation of
the traction control system or vehicle sta-
bilit

05_SEQUOIA_U (L/O 0408)
184
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
The brake pad or actuator temperature
increases during continuous operation of
the traction control system or vehicle sta-
bility control system such as on slippery
roads. If the brake pad or actuator tem-
perature becomes too high while the trac-
tion control system or vehicle stability
control system is operating, a buzzer will
start to sound intermittently to indicate
that the traction control system can no
longer operate. In this case, stop your
vehicle immediately at a safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At the time the ªVSC TRACº warning light
will come on and the traction control sys-
tem temporarily stops operating in order to
protect the brake pad. (Although the trac-
tion control system does not operate,
there is no problem to continue your driv-
ing.) The system will be automatically re-
stored after a short time and the warning
light goes out.
If the light comes on while driving, the
traction control system does not work.
However, as conventional braking operates
when applied, there is no problem to con-
tinue your driving.In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition key is turned to ªONº.
The warning light remains on after the
ignition key is turned to ªONº.
The warning light comes on while driv-
ing.
The ªTRAC OFFº indicator light will come
on when the ªVSC TRACº warning light
comes on even if the ªTRAC OFFº switch
is not pushed.The active traction control system auto-
matically helps prevent the spinning of
4 wheels (4WD mode) or rear wheels
(2WD mode) when the vehicle is started
or accelerated on slippery road sur-
faces.
When the ignition key is turned to ªONº,
the system automatically turns on.
CAUTION
Under certain slippery road condi-
tions, full traction of the vehicle and
power against 4 wheels (4WD mode)
or rear wheels (2WD mode) cannot be
maintained, even though the active
traction control system is in opera-
tion. Do not drive the vehicle under
any speed or maneuvering conditions
which may cause the vehicle to lose
traction control. In situations where
the road surface is covered with ice
or snow, your vehicle should be fitted
with snow tires or tire chains. Always
drive at an appropriate and cautious
speed for the present road condi-
tions.
Active traction control system
(four±wheel drive models)

Page 4044 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
185
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Leave the system on during the ordi-
nary driving so that it can operate
when needed.
You may hear a sound in the engine
compart

Page 4045 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
186
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
The brake pad or actuator temperature
increases during continuous operation of
the active traction control system or ve-
hicle s

05_SEQUOIA_U (L/O 0408)
186
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
The brake pad or actuator temperature
increases during continuous operation of
the active traction control system or ve-
hicle stability control system such as on
slippery roads. If the brake pad or actua-
tor temperature becomes too high while
the active traction control system or ve-
hicle stability control system is operating,
a buzzer will start to sound intermittently
to indicate that the active traction control
system can no longer operate. In this
case, stop your vehicle immediately at a
safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At the time, the ªVSC TRACº warning light
will come on and the active traction con-
trol system temporarily stops operating in
order to protect the brake pad. (Although
the active traction control system does not
operate, there is no problem to continue
your driving.) The system will be automati-
cally restored after a short time and the
warning light goes out.
If the light comes on while driving, the
active traction control system does not
work. However, as conventional braking
operates when applied, there is no prob-
lem to continue your driving.In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition key is turned to ªONº.
The warning light remains on after the
ignition key is turned to ªONº.
The warning light comes on while driv-
ing.
The ªVSC OFFº indicator light will come
on when the ªVSC TRACº warning light
comes on even if the center differential
lock switch is not pushed.The vehicle stability control system
helps provide integrated control of the
systems such as anti±lock brake sys-
tem, traction control, engine control,
etc. This system automatically controls
the brakes and engine to help prevent
the vehicle from skidding when corner-
ing on a slippery road surface or oper-
ating steering wheel abruptly.
This vehicle stability control activates
when the vehicle speed is more than the
following speed.
Two±wheel drive models:
15 km/h (9 mph)
Four±wheel drive models:
ª2WDº or ª4HIº mode
15 km/h (9 mph)
ª4LOº mode 30 km/h (18 mph)
You may hear a sound in the engine
compartment for a few seconds when the
engine is started or just after the vehicle
begins to move. This means that the sys-
tem is in the self±check mode but does
not indicate a malfunction.
Vehicle stability control system

Page 4046 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
187
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
CAUTION
Do not rely excessively on the ve-
hicle stability control system. Even
if the vehicle stability control sys-
tem is o

Page 4047 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
188
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
In the following cases, contact your Toyota
dealer:
The indicator light does not come on
when the ignition key is turned ªONº

Page 4048 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
189
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
1: Mode select switch
2: Height select switch
This rear height control air suspension
controls the vehicle height depending
on v
