RS11Z±01
H23940Claw RS±118
± SUPPLEMENTAL RESTRAINT SYSTEMRSCA OFF SWITCH
3401 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL SWITCH BASE
(a) Connect the connectors.
(b) Engage the 3 claws to install the switch base.
2. INSTALL LOWER FINISH PANEL (SEE PAGE BO±97)
3. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
4. PERFORM INITIALIZATION (SEE PAGE BE±77)
Some system need initialization when disconnecting the cable
from the negative battery terminal.
5. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)
Page 3410 of 4323
RS0BU±10
H23906
Front Airbag Sensor (LH)Front Airbag
Sensor (RH)Front Passenger
Airbag Assembly (RH)
Seat Belt
Pretensioner (RH)
Airbag Sensor Assembly Seat Belt Pretensioner (LH) Spiral CableCurtain Shield
Airbag Assembly (RH)
Side Airbag
Assembly (RH) (*1)
Side Airbag Sensor
Assembly (RH) (*1)
Side Airbag Assembly (LH) (*1) Side Airbag Sensor
Assembly (LH) (*1)
Curtain Shield Airbag
Assembly (LH) (*1)
Combination Meter
(Warning Light)
Steering Wheel Pad
(With Airbag)
Curtain Shield Airbag
Sensor Assembly (LH) (*1)
Curtain Shield Airbag
Sensor Assembly
(RH) (*1)RSCA OFF
Switch (*1)
Occupant Classification
ECU (*1)
(*1) w/ Side Airbag and Curtain Shield Airbag
± SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS±119
3402 Author: Date:
2005 SEQUOIA (RM1146U)
WIRE HARNESS AND CONNECTOR
LOCATION
Page 3411 of 4323
RS0BV±08
RS±120
± SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
3403 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
HINT:
The SRS wire harness is integrated with the cowl wire harness assembly. The wires for the SRS wire harness
are encased in a yellow corrugated tube and all the connectors in the system except the seat position airbag
sensor connector and occupant classification ECU connectors, colored are yellow.
1. VEHICLE NOT INVOLVED IN COLLISION
Perform a diagnostic system check (see page DI±1147).
2. VEHICLE INVOLVED IN COLLISION
(a) Perform a diagnostic system check (see page DI±1147).
(b) Check breaks in all wires of the SRS wire harness, and exposed conductors.
(c) Check if the SRS wire harness connectors are cracked or chipped.
Page 3412 of 4323
RS0BW±07
± SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
RS±121
3404 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the wire harness or connector with a new one.
Any part of the SRS wire harness or any connector has been found to be faulty in troubleshoot-
ing.
Any part of the SRS wire harness or any connector has been found to be faulty while checking
items (see page RS±120).
CAUTION:
If the wire harness used in the SRS is damaged, replace the whole SRS wire harness assembly.
Page 3413 of 4323

BE01E±12
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE±1
3405 Author: Date:
2005 SEQUOIA (RM1146U)
BODY ELECTRICAL SYSTEM
PRECAUTION
NOTICE:
When disconnecting the battery terminal, initialize the following system after the terminal is recon-
nected.
System NameSee Page
Back Door Power Window Control SystemBE±77
Take care to observe the following precautions when performing inspections or removal and replacement
of body electrical related parts.
1. LIGHTING SYSTEM
Halogen bulbs have pressurized gas inside and require special handling.
They may burst or shatter if scratched or the bulb is dropped. Hold a bulb only by its plastic or metal case.
Don't touch the glass part of a bulb with bare hands.
2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
The SEQUOIA is equipped with an SRS (Supplemental Restraint System) such as the driver airbag. Failure
to carry out service operations in the correct sequence could cause the SRS to unexpectedly deploy during
servicing, possibly leading to a serious accident. Before servicing (including removal and installation of parts,
inspection or replacement), be sure to read the precautions in the RS section (See page xx±xxx).
3. AUDIO SYSTEM
If the battery negative (±) terminal is disconnected, the preset AM, FM 1 and FM 2 stations stored in the
memory are erased, so be sure to make a memo of the stations and reset them after the battery terminal
is reconnected.
4. MOBILE COMMUNICATION SYSTEM
If the vehicle is equipped with a mobile communication system, refer to precautions in the IN section.
Page 3414 of 4323

BE19B±08
BE±2
± BODY ELECTRICALTROUBLESHOOTING
3406 Author: Date:
2005 SEQUOIA (RM1146U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
POWER OUTLET
SymptomSuspect AreaSee page
Electric power source cannot be out of the power outlet.
1. PWR OUTLET Fuse
2. INVERTER Relay
3. Main Switch
4. Voltage Inverter
5. Wire HarnessBE±14
BE±20
BE±20
BE±20
±
IPO system does not operate.
Power source cannot be supplied from the power outlet socket
when the ignition switch is off.1. PWR OUTLET Fuse
2. INVERTER Relay
3. Instrument panel J/B (IPO) circuit
4. Wire HarnessBE±14
BE±20
BE±20
±
IGNITION SWITCH
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Ignition switch is not set to each position.
1. Ignition Switch
2. Power Source Circuit (Body ECU)
3. Power Source Circuit (Driver door ECU)
4. Power Source Circuit (Passenger door ECU)BE±24
DI±1700
BE±34
DI±1849
KEY UNLOCK WARNING SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Key unlock warning system does not operate.
(The buzzer does not sound when the driver's door is opened with
the ignition OFF and key inserted)1. Key Unlock Warning Switch
2. Driver Door Courtesy Light Switch
3. Wire Harness
4. Combination MeterBE±24
BE±40
±
±
Key unlock warning system does not operate.
(The buzzer sounds when the ignition key is ACC or ON)1. Ignition Switch
2. Wire Harness
3. Combination MeterBE±24
±
±
w/o Daytime Running Light:
HEADLIGHT AND TAILLIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Only one headlight comes on.1. Bulb
2. Wire Harness±
±
ºLO±Beamº does not light (All).
1. HEAD Relay
2. Headlight Dimmer Switch
3. Wire Harness
4. Body ECUBE±27
BE±27
±
±
ºLO±Beamº does not light (One side).
1. Bulb
2. H±LP LH Fuse
3. H±LP RH Fuse
4. Wire Harness±
BE±14
BE±14
±
Page 3415 of 4323

± BODY ELECTRICALTROUBLESHOOTING
BE±3
3407 Author: Date:
2005 SEQUOIA (RM1146U) ºHI±Beamº does not light (All).
1. HEAD Relay
2. Headlight Dimmer Switch
3. Wire Harness
4. Body ECUBE±27
BE±27
±
±
ºHI±Beamº does not light (One side).
1. Bulb
2. H±LP LH Fuse
3. H±LP RH Fuse
4. Wire Harness±
BE±14
BE±14
±
ºFlashº does not light.
1. H±LP LH Fuse
2. H±LP RH Fuse
3. Bulb
4. Headlight Dimmer Switch
5. Wire Harness
6. Body ECUBE±14
BE±14
±
BE±27
±
±
Headlight does not come on.
1. Bulb
2. HEAD Relay
3. Light Control Switch
4. Wire Harness
5. Body ECU±
BE±27
DI±1750
±
±
Headlight flickers.
1. Bulb
2. Wire Harness
3. Body ECU±
±
±
Headlight is dark.
1. Bulb
2. Body ECU
3. Wire Harness±
±
±
Only one taillight comes on.1. Bulb
2. Wire Harness±
±
Taillight does not come on.
(Headlight is normal)
1. TAIL Fuse
2. TAILLIGHT Relay
3. Light Control Switch
4. Wire Harness
5. Body ECUBE±14
BE±27
BE±27
±
±
Taillight does not come on.
(Headlight does not come on)
1. TAIL Fuse
2. TAILLIGHT Relay
3. Light Control Switch
4. Wire Harness
5. Body ECUBE±14
BE±27
BE±27
±
±
Rear combination light does not come on.
1. Bulb
2. TAIL Fuse
3. TAILLIGHT Relay
4. Wire Harness
5. Body ECU±
BE±14
BE±27
±
±
w/ Daytime Running Light:
HEADLIGHT AND TAILLIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Only one headlight comes on.1. Bulb
2. Wire Harness±
±
Page 3416 of 4323

BE±4
± BODY ELECTRICALTROUBLESHOOTING
3408 Author: Date:
2005 SEQUOIA (RM1146U) ºLO±Beamº does not light (All).
1. HEAD Relay
2. DRL Fuse
3. DIMMER Relay
4. DRL No. 4 Relay
5. Wire Harness
6. Body ECUBE±27
BE±14
BE±27
BE±27
±
±
ºLO±Beamº does not light (One side).
1. Bulb
2. H±LP LL Fuse
3. H±LP LP Fuse
4. Wire Harness±
BE±14
BE±14
±
ºHI±Beamº does not light (All).
1. HEAD Relay
2. Headlight Dimmer Switch
3. DRL Fuse
4. DIMMER Relay
5. DRL No. 4 Relay
6. Wire Harness
7. Body ECUBE±27
BE±27
BE±14
BE±27
BE±27
±
±
ºHI±Beamº does not light (One side).
1. Bulb
2. H±LP LL Fuse
3. H±LP LP Fuse
4. Wire Harness±
BE±14
BE±14
±
ºFlashº does not light.
1. Headlight Dimmer Switch
2. Wire Harness
3. Body ECUBE±27
±
±
Headlight does not come on.
1. Bulb
2. HEAD Relay
3. DIMMER Relay
4. DRL No. 4 Relay
5. Headlight Dimmer Switch
6. Light Control Switch
7. Wire Harness
8. Body ECU±
BE±27
BE±27
BE±27
BE±27
BE±27
±
±
Headlight does not go off when light control switch is in OFF posi-
tion.
1. Power Source Circuit (Body ECU)
2. HEAD Relay
3. DIMMER Relay
4. Light Control Switch
5. Wire Harness
6. Body ECUDI±1700
BE±27
BE±27
BE±27
±
±
Headlight flickers.
1. Bulb
2. Wire Harness
3. Body ECU±
±
±
Headlight is dark.
1. Bulb
2. Wire Harness
3. Body ECU±
±
±
Taillight does not come on when light control switch is in TAIL
position.
1. TAIL Fuse
2. TAILLIGHT Relay
3. Light Control Switch
4. Wire Harness
5. Body ECUBE±14
BE±27
BE±27
±
±
