Page 2921 of 4323
D13884
A750E:
A750F:AT133±01
D13885
A750E:
A750F:
± AUTOMATIC TRANSMISSION (A750E, A750F)SPEED SENSOR
AT±5
2913 Author: Date:
2005 SEQUOIA (RM1146U)
SPEED SENSOR
ON±VEHICLE REPAIR
1. DISCONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
2. REMOVE NO. 1 VEHICLE SPEED SENSOR
Remove the bolt and No.1 vehicle speed sensor.
3. DISASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Remove the O±ring from the speedometer driven gear
assembly.
(b) Remove the clip and speedometer driven gear from the
speedometer driven gear sleeve.
4. ASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Install the speedometer driven gear and clip to the
speedometer driven gear sleeve.
(b) Coat a new O±ring with ATF.
(c) Install the O±ring to the speedometer driven gear assem-
bly.
5. INSTALL NO. 1 VEHICLE SPEED SENSOR
Install the No.1 vehicle speed sensor with the bolt.
Torque:
A750E: 9.8 N´m (100 kgf´cm, 86 in.´lbf)
A750F: 11.5 N´m (117 kgf´cm, 8 ft´lbf)
6. CONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
Page 2922 of 4323
D14124
Speed Sensor NT
Speed Sensor SP2
D02395
D14124
Speed Sensor NT
Speed Sensor SP2 AT±6
± AUTOMATIC TRANSMISSION (A750E, A750F)SPEED SENSOR
2914 Author: Date:
2005 SEQUOIA (RM1146U)
7. DISCONNECT SPEED SENSOR NT AND SP2 CON-
NECTOR
8. REMOVE SPEED SENSOR NT AND SP2
(a) Remove the 2 bolts, speed sensors NT and SP2.
(b) Remove 2 O±rings from the speed sensors NT and SP2.
9. INSTALL SPEED SENSOR NT AND SP2
(a) Coat 2 new O±rings with ATF and install them to the
speed sensors NT and SP2.
(b) Install the speed sensors NT and SP2 with the 2 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
10. CONNECT SPEED SENSOR NT AND SP2 CONNEC-
TOR
Page 2923 of 4323

D13867
AT134±01
D12704
Orange
Blue
Clamp
ClampBolt
Bolt
D12739
D12704
Orange
Blue
Clamp
Clamp
A B
± AUTOMATIC TRANSMISSION (A750E, A750F)ATF TEMPERATURE SENSOR
AT±7
2915 Author: Date:
2005 SEQUOIA (RM1146U)
ATF TEMPERATURE SENSOR
ON±VEHICLE REPAIR
1. DRAIN AUTOMATIC TRANSMISSION FLUID
(a) Remove the drain plug and gasket, and drain the ATF.
(b) Install a new gasket and the drain plug.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
2. REMOVE OIL PAN (See page AT±10)
3. REMOVE OIL STRAINER (See page AT±10)
4. REMOVE ATF TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid valve connectors.
(b) Remove the 2 bolts, clamps and ATF temperature sen-
sors.
(c) Disconnect the transmission wire connector.
(d) Remove the bolt and the transmission wire harness.
5. INSTALL ATF TEMPERATURE SENSOR
(a) Install the transmission wire harness.
(b) Install the bolt.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(c) Connect the transmission wire connector.
(d) Connect the 7 solenoid valve connectors.
(e) Install the 2 ATF temperature sensors and clamps to the
valve body with the 2 bolts.
HINT:
In order to install the ATF temperature sensors properly, check
the wire harness color prior to installation.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp. warning lampBlue
6. INSTALL OIL STRAINER (See page AT±10)
Page 2924 of 4323
D13866
AT±8
± AUTOMATIC TRANSMISSION (A750E, A750F)ATF TEMPERATURE SENSOR
2916 Author: Date:
2005 SEQUOIA (RM1146U)
7. INSTALL OIL PAN
HINT:
Remove any packing material, and be careful not to spill oil on
the contacting surfaces of the transmission case and the oil
pan.
Using a new gasket, install the oil pan with the 20 bolts.
Torque: 4.4 N´m (45 kgf´cm, 39 in´lbf)
8. FILL WITH ATF AND CHECK ATF LEVEL
(a) Remove the refill plug (See page DI±524).
(b) Fill with new fluid through the refill hole.
Fluid type: Toyota genuine ATF WS
Page 2925 of 4323
AT135±01
D12667
Lock Washer
± AUTOMATIC TRANSMISSION (A750E, A750F)PARK/NEUTRAL POSITION (PNP) SWITCH
AT±9
2917 Author: Date:
2005 SEQUOIA (RM1146U)
PARK/NEUTRAL POSITION (PNP)
SWITCH
ON±VEHICLE REPAIR
1. DISCONNECT PARK/NEUTRAL POSITION SWITCH
CONNECTOR
2. REMOVE PARK/NEUTRAL POSITION SWITCH
(a) Pry off the lock washer and remove the nut.
(b) Remove the bolt and park/neutral position switch.
3. INSTALL PARK/NEUTRAL POSITION SWITCH
(a) Install the park/neutral position switch with the bolt.
Torque: 13 N´m (130 kgf´cm, 10 ft´lbf)
(b) Install a new lock washer and the nut.
Torque: 6.9 N´m (70 kgf´cm, 61 in.´lbf)
(c) Bend the claws on the lock washer to stake the nut.
(d) Adjust the park/neutral position switch
(See page DI±524).
4. CONNECT PARK/NEUTRAL POSITION SWITCH CON-
NECTOR
Page 2926 of 4323

D13867
AT136±01
D13866
AT0103
D12703
D12704
Orange
Blue
Clamp
ClampBolt
Bolt AT±10
± AUTOMATIC TRANSMISSION (A750E, A750F)VALVE BODY ASSEMBLY
2918 Author: Date:
2005 SEQUOIA (RM1146U)
VALVE BODY ASSEMBLY
ON±VEHICLE REPAIR
1. DRAIN AUTOMATIC TRANSMISSION FLUID
(a) Remove the drain plug and gasket, and drain the ATF.
(b) Install a new gasket and the drain plug.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
2. REMOVE OIL PAN
NOTICE:
Some fluid will remain in the oil pan.
(a) Remove the 20 bolts.
(b) Remove the oil pan gasket.
3. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect any steel par-
ticles. Carefully look at the foreign matter and particles in the
pan and on the magnets to anticipate the type of wear you will
find in the transmission.
Steel (magnetic) ... bearing, gear and clutch plate wear
Brass (non±magnetic) ... bushing wear
4. REMOVE OIL STRAINER
Remove the 4 bolts, the oil strainer and the O±ring.
NOTICE:
Be careful as some fluid will come out with the oil strainer.
5. REMOVE ATF TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid valve connectors.
(b) Remove the 2 bolts, clamps and ATF temperature sen-
sors.
Page 2927 of 4323

D12705
D14229
Shift
Solenoid
Valve SL2Shift
Solenoid
Valve SLUShift
Solenoid
Valve SR
Shift
Solenoid
Valve S2 Shift
Solenoid
Valve S1 Shift
Solenoid
Valve SL1 Shift
Solenoid
Valve SLT
D12707
Pin
± AUTOMATIC TRANSMISSION (A750E, A750F)VALVE BODY ASSEMBLY
AT±11
2919 Author: Date:
2005 SEQUOIA (RM1146U)
6. REMOVE VALVE BODY
(a) Remove the 19 bolts and the valve body.
(b) Remove the 3 drum seal gaskets.
7. REMOVE SOLENOID VALVE
(a) Remove the 2 bolts and the shift solenoid valve SR.
(b) Remove the 3 bolts and the shift solenoid valves S1 and
S2.
(c) Remove the 2 bolts, 2 solenoid lock plates and the 4
straight pins.
(d) Remove the shift solenoid valves SL2 and SLU.
(e) Remove the shift solenoid valves SL1 and SLT.
(f) Remove the O±ring from the solenoid valve S2.
8. INSTALL SOLENOID VALVE
(a) Install a new O±ring to the shift solenoid valve S2.
(b) Install the shift solenoid valves SL1 and SLT.
(c) Install the shift solenoid valves SL2 and SLU.
(d) Install the 4 straight pins and the 2 solenoid lock plates
with the 2 bolts.
Torque: 6.4 N´m (65 kgf´cm, 57 in´lbf)
(e) Install the shift solenoid valve S1 with the bolt.
Torque: 6.4 N´m (65 kgf´cm, 57 in´lbf)
(f) Install the shift solenoid valve S2 with the bolt.
Torque: 10 N´m (102 kgf´cm, 7 ft´lbf)
(g) Install the shift solenoid valve SR with the 2 bolts.
Torque: 6.4 N´m (65 kgf´cm, 57 in´lbf)
9. INSTALL VALVE BODY
HINT:
Align the groove of the manual valve with the pin of the lever.
(a) Install 3 new drum seal gaskets to the transmission case.
Page 2928 of 4323

D12705
D12704
Orange
Blue
Clamp
Clamp
A B
D12703
D13866
AT±12
± AUTOMATIC TRANSMISSION (A750E, A750F)VALVE BODY ASSEMBLY
2920 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Install the 19 bolts and the valve body.
Torque: 11 N´m (112 kgf´cm, 8 ft´lbf)
Bolt length:
Bolt A: 25 mm (0.98 in.)
Bolt B: 36 mm (1.42 in.)
10. INSTALL TEMPERATURE SENSOR
(a) Connect the 7 solenoid valve connectors.
(b) Install the 2 temperature sensors and clamps to the valve
body with the 2 bolts.
HINT:
In order to install the ATF temperature sensors properly, check
the wire harness color prior to installation.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp. warning lampBlue
11. INSTALL OIL STRAINER
(a) Install a new O±ring.
(b) Install the oil strainer with the 4 bolts.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
12. INSTALL OIL PAN
HINT:
Remove any packing material, and be careful not to spill oil on
the contacting surfaces of the transmission case and the oil
pan.
Using a new gasket, install the oil pan with the 20 bolts.
Torque: 4.4 N´m (45 kgf´cm, 39 in´lbf)
