TOYOTA SEQUOIA 2001 Service Repair Manual BO45S±01 BO±24 ± BODYREAR DOOR 3577 Author: Date: 2005 SEQUOIA (RM1146U) REASSEMBLY Reassembly is in the reverse order of disassembly (See page BO±24).

Page 3586 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO45T±01 H16689 Back Door Side Garnish Back Door Center Garnishw/o Rear spoiler: High Mount Stop Light Outside MouldingBack Door Hingew/ Rear spoiler: Rear Spoiler Back Door Hinge Rear Wiper Arm Wipe

Page 3587 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16671 BO45U±01 H16672 H16673 H16674 5 Clips H16675 3 Clips BO±26 ± BODYBACK DOOR 3579 Author: Date: 2005 SEQUOIA (RM1146U) DISASSEMBLY 1. REMOVE REAR WIPER ARM (a) Open the cover. (b) Remove t

Page 3588 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16676 10 Clips H02440 ± BODYBACK DOOR BO±27 3580 Author: Date: 2005 SEQUOIA (RM1146U) 7. REMOVE BACK DOOR TRIM BOARD (a) Insert a screwdriver between the back door and back door trim board to p

Page 3589 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H02441 H02442 H16677 H16678 H16679 BO±28 ± BODYBACK DOOR 3581 Author: Date: 2005 SEQUOIA (RM1146U) Do not tilt the riveter disconnect the rivet from the ma- terial while handling a riveter, as

Page 3590 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16680 H16681 H16682 ± BODYBACK DOOR BO±29 3582 Author: Date: 2005 SEQUOIA (RM1146U) (c) Employ the same manner described above to the other side. 16. REMOVE POWER WINDOW REGULATOR (a) Disconnec

Page 3591 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16683 H16684 5 Clips BO±30 ± BODYBACK DOOR 3583 Author: Date: 2005 SEQUOIA (RM1146U) (c) Using a screwdriver, remove the back door lock protector. HINT: Tape the screwdriver tip before use. (d)

Page 3592 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO45V±01 H16685 H16686 H16687 H16688 ± BODYBACK DOOR BO±31 3584 Author: Date: 2005 SEQUOIA (RM1146U) ADJUSTMENT 1. ADJUST DOOR IN LEFT/RIGHT AND VERTICAL DIRECTIONS Loosen the door side hinge
