± BODY ELECTRICALPOWER MIRROR CONTROL SYSTEM
BE±117
3521 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Reverse the polarity and check that the mirror turns right-
ward.
(c) Connect the positive (+) lead from the battery to terminal
6 and the negative (±) lead to terminal 5. Check that the
mirror turns upward.
(d) Reverse the polarity and check that the mirror turns down-
ward.
If operation is not as specified, replace the mirror assembly.
5. w/o Retract Mirror and Driving Position Memory:
INSPECT MIRROR MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (±) lead to terminal 1. Check that the
mirror turns leftward.
(b) Reverse the polarity and check that the mirror turns right-
ward.
Page 3530 of 4323
I24875
1
2
I24876
1
2
I28510
7
8
I28511
7
8
I28512
8
9
BE±118
± BODY ELECTRICALPOWER MIRROR CONTROL SYSTEM
3522 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Connect the positive (+) lead from the battery to terminal
2 and the negative (±) lead to terminal 1. Check that the
mirror turns upward.
(d) Reverse the polarity and check that the mirror turns down-
ward.
If operation is not as specified, replace the mirror assembly.
6. w/ Retract Mirror and Driving Position Memory:
INSPECT MIRROR MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
7 and the negative (±) lead to terminal 8. Check that the
mirror turns upward.
(b) Reverse the polarity and check that the mirror turns down-
ward.
(c) Connect the positive (+) lead from the battery to terminal
8 and the negative (±) lead to terminal 9. Check that the
mirror turns leftward.
Page 3531 of 4323

I28513
8
9
I18582
Retract
PositionDrive
Position
(a)
(b)
(c)
I24381
Connector Front View:
I18582
Retract
PositionDrive
Position
(a)
(b)
(c)
± BODY ELECTRICALPOWER MIRROR CONTROL SYSTEM
BE±119
3523 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Reverse the polarity and check that the mirror turns right-
ward.
7. w/o Driving Position Memory:
INSPECT ELECTRICAL RETRACT MOTOR OPERA-
TION
(a) Driving position:
(1) Connect the positive (+) lead from the battery to ter-
minal 1 and the negative (±) lead to terminal 2.
Check that the mirror moves to the retract position.
(2) Reverse the polarity and check that the mirror does
not operate.
If operation is not as specified, replace the mirror assembly.
(b) Between driving position and retract position:
(1) Connect the positive (+) lead from the battery to ter-
minal 1 and the negative (±) lead to terminal 2.
Check that the mirror moves to the retract position.
(2) Reverse the polarity and check that the mirror
moves to the return position (Stops at the driving
position).
If operation is not as specified, replace the mirror assembly.
(c) Retract position:
(1) Connect the positive (+) lead from the battery to ter-
minal 1 and the negative (±) lead to terminal 2.
Check that the mirror does not operate.
(2) Reverse the polarity and check that the mirror
moves to the return position (Stops at the driving
position).
If operation is not as specified, replace the mirror assembly.
8. w/ Driving Position Memory:
INSPECT ELECTRICAL RETRACT MOTOR OPERA-
TION
(a) Driving position:
(1) Connect the positive (+) lead from the battery to ter-
minal 13 and the negative (±) lead to terminal 14.
Check that the mirror moves to the retract position.
(2) Reverse the polarity and check that the mirror does
not operate.
If operation is not as specified, replace the mirror assembly.
Page 3532 of 4323
I28520
Connector Front View: BE±120
± BODY ELECTRICALPOWER MIRROR CONTROL SYSTEM
3524 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Between driving position and retract position:
(1) Connect the positive (+) lead from the battery to ter-
minal 13 and the negative (±) lead to terminal 14.
Check that the mirror moves to the retract position.
(2) Reverse the polarity and check that the mirror
moves to the return position (Stops at the driving
position).
If operation is not as specified, replace the mirror assembly.
(c) Retract position:
(1) Connect the positive (+) lead from the battery to ter-
minal 13 and the negative (±) lead to terminal 14.
Check that the mirror does not operate.
(2) Reverse the polarity and check that the mirror
moves to the return position (Stops at the driving
position).
If operation is not as specified, replace the mirror assembly.
Page 3533 of 4323
BE2D8±03
I28420
Electro Chromic Inner Mirror
Instrument Panel J/B
ECU±IG Fuse
± BODY ELECTRICALELECTRO CHROMIC MIRROR SYSTEM
BE±121
3525 Author: Date:
2005 SEQUOIA (RM1146U)
ELECTRO CHROMIC MIRROR SYSTEM
LOCATION
Page 3534 of 4323
BE2D9±02
I24349
A
76
BE±122
± BODY ELECTRICALELECTRO CHROMIC MIRROR SYSTEM
3526 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
INSPECT ELECTRO CHROMIC INNER MIRROR OPERA-
TION
(a) Cover the sensor A so that the sensor does not receive
any light.
(b) Connect the positive (+) lead the battery to terminal 7 and
the negative (±) lead to terminal 6.
(c) Shine an electric light on the mirror, and check that there
is battery positive voltage and mirror surface becomes
bright to dark.
If operation is not as specified, replace the inner mirror.
Page 3535 of 4323
BE0GH±22
I28421
Ignition SwitchSeat Heater Switch
Instrument Panel J/B
SEAT HEATER Relay
SEAT HTR Fuse
Seat Heater CushionSeat Heater Back
± BODY ELECTRICALSEAT HEATER SYSTEM
BE±123
3527 Author: Date:
2005 SEQUOIA (RM1146U)
SEAT HEATER SYSTEM
LOCATION
Page 3536 of 4323
BE2D7±03
I18566
Left Side Heater Switch
Right Side Heater Switch
I18567
6
4
6
4
BE±124
± BODY ELECTRICALSEAT HEATER SYSTEM
3528 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. INSPECT SEAT HEATER SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Right side3 ± 4 ± 6Continuity
OFF±No continuity
Left side3 ± 4 ± 6Continuity
Illumination circuit1 ± 2Continuity
If continuity is not as specified, replace the switch.
2. INSPECT SEAT HEATER INDICATOR LIGHT OPERA-
TION
(a) Connect the positive (+) lead from the battery to terminal
4 and the negative (±) lead to terminal 6.
(b) Push the seat heater switch (right or left side) and check
that the indicator light comes on.
If operation is not as specified, replace the switch.
