Page 233 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A23656
0.2 V/DIV
200 msec./DIV
Ground
A2365710 msec./DIV 5 V/DIV
Ground
± DIAGNOSTICSENGINE
DI±39
233 Author: Date:
2005 SEQUOIA (RM1146U)
WAVEFORM 10
Heated oxygen sensor
ECM Terminal NamesBetw

Page 234 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DID7X±01
FI0534
D13872
Hand±Held Tester
DLC3
DI±40
± DIAGNOSTICSENGINE
234 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSIS SYSTEM
1. Description
When troubleshooting On±Board Diagnostic (OBD

DID7X±01
FI0534
D13872
Hand±Held Tester
DLC3
DI±40
± DIAGNOSTICSENGINE
234 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSIS SYSTEM
1. Description
When troubleshooting On±Board Diagnostic (OBD ll) ve-
hicles, the vehicle must be connected to the hand±held
tester. Various data output from the vehicle's ECM can
then be read.
OBD ll regulations require that the vehicle's on±board
computer illuminates the Malfunction Indicator Light (MIL)
on the instrument panel when the computer detects a
malfunction in: 1) the emission control system/compo-
nents, or 2) the powertrain control components (which af-
fect vehicle emissions), or 3) the computer. In addition,
the applicable Diagnostic Trouble Codes (DTCs) pre-
scribed by SAE J2012 are recorded in the ECM memory
(See page DI±58).
If the malfunction does not reoccur in 3 consecutive trips, the
MIL goes off automatically but the DTCs remain recorded in the
ECM memory.
To check the DTC, connect the hand±held tester or OBD II scan
tool to the Data Link Connector 3 (DLC3) of the vehicle. The
hand±held tester or OBD II scan tool also enables you to erase
the DTC and check the freeze frame data and various forms of
engine data (See the instruction manual for the hand±held tes-
ter). The DTC includes SAE controlled codes and manufacturer
controlled codes. SAE controlled codes must be set according
to the SAE, while manufacturer controlled codes can be set by
a manufacturer with certain restrictions (See the DTC chart on
page DI±58).
2. NORMAL MODE AND CHECK MODE
The diagnosis system operates in ºnormal modeº during normal
vehicle use. In ºnormal modeº, 2 trip detection logic* is used to
ensure accurate detection of malfunctions. A ºcheck modeº is
also available to technicians as an option. In ºcheck modeº, 1
trip detection logic is used for simulating malfunction symptoms
and increasing the system's ability to detect malfunctions, in-
cluding intermittent malfunctions (See page DI±11).
3. 2±TRIP DETECTION LOGIC
When a malfunction is first detected, the malfunction is tempo-
rarily stored in the ECM memory. This is known as 1st trip detec-
tion. If the ignition switch is turned OFF and then ON again, and
the same malfunction is detected again, the MIL will illuminate.
This is known as 2nd trip detection.

Page 235 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A04550
12 345678
11 12 13 14 15 16 910
DLC3
± DIAGNOSTICSENGINE
DI±41
235 Author: Date:
2005 SEQUOIA (RM1146U)
Freeze frame data:
The freeze frame data records the engine conditions (fuel
syste

A04550
12 345678
11 12 13 14 15 16 910
DLC3
± DIAGNOSTICSENGINE
DI±41
235 Author: Date:
2005 SEQUOIA (RM1146U)
Freeze frame data:
The freeze frame data records the engine conditions (fuel
system, calculated load, engine coolant temperature, fuel
trim, engine speed, vehicle speed, etc.) when a malfunc-
tion is detected. When troubleshooting, freeze frame data
can help determine if the vehicle was running or stopped,
if the engine was warmed up or not, if the air±fuel ratio
was lean or rich, as well as other data from the time when
a malfunction occurred.
Priorities for troubleshooting:
When multiple DTCs occur, find out the order in which the DTCs
should be inspected by checking the component's DTC chart.
If no instructions are written in the DTC chart, check DTCs in the
following order of priority:
(a) DTCs other than fuel trim malfunction DTCs (P0171,
P0172, P0174 and P0175) and misfire DTCs (P0300 to
P0308).
(b) Fuel trim malfunction DTCs (P0171, P0172, P0174 and
P0175).
(c) Misfire DTCs (P0300 to P0308).
4. CHECK DLC3
The vehicle's ECM uses the ISO 9141±2 for communica-
tion protocol. The terminal arrangement of the DLC3 com-
plies with SAE J1962 and matches the ISO 9141±2 for-
mat.
SymbolTerminal DescriptionConditionSpecified Condition
SIL (7) ± SG (5)Bus º+º lineDuring transmissionPulse generation
CG (4) ± Body groundChassis groundAlwaysBelow 1 W
SG (5) ± Body groundSignal groundAlwaysBelow 1 W
BAT (16) ± Body groundBattery positiveAlways11 to 14 V
CANH (6) ± CANL (14)HIGH±level CAN bus lineIgnition switch OFF54 to 69 W
CANH (6) ± Battery positiveHIGH±level CAN bus lineIgnition switch OFF1 MW or higher
CANH (6) ± CG (4)HIGH±level CAN bus lineIgnition switch OFF1 kW or higher
CANL (14) ± Battery positiveLOW±level CAN bus lineIgnition switch OFF1 MW or higher
CANL (6) ± CG (4)LOW±level CAN bus lineIgnition switch OFF1 kW or higher
HINT:
Connect the cable of the hand±held tester to the DLC3, turn the
ignition switch ON and attempt to use the hand±held tester. If
the screen displays UNABLE TO CONNECT TO VEHICLE, a
problem exists in the vehicle side or the tester side.
If the communication is normal when the tool is connected
to another vehicle, inspect the DLC3 on the original ve-
hicle.

Page 236 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±42
± DIAGNOSTICSENGINE
236 Author: Date:
2005 SEQUOIA (RM1146U)
If the communication is still impossible when the tool is
connected to another vehicle, the problem is probably in
the tool i

Page 237 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DID7Y±01
D13872
Hand±Held Tester
DLC3CAN VIM
± DIAGNOSTICSENGINE
DI±43
237 Author: Date:
2005 SEQUOIA (RM1146U)
DTC CHECK / CLEAR
1. CHECK DTC
DTCs which are stored in the ECM can be displayed

Page 238 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DID7Z±01
D13872
Hand±Held Tester
DLC3CAN VIM
BR3904
0.13 sec.0.13 sec.
ON
OFF DI±44
± DIAGNOSTICSENGINE
238 Author: Date:
2005 SEQUOIA (RM1146U)
CHECK MODE PROCEDURE
HINT:
Hand±held tester o

Page 239 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSENGINE
DI±45
239 Author: Date:
2005 SEQUOIA (RM1146U)
3. CLEAR DTC (Not using the hand±held tester)
(a) Remove the EFI No. 1 and ETCS fuses from the engine
room J/B for more than 6

Page 240 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DID80±01
DI±46
± DIAGNOSTICSENGINE
240 Author: Date:
2005 SEQUOIA (RM1146U)
FAIL±SAFE CHART
If any of the following code is recorded, the ECM enters fail±safe mode.
DTC No.Fail±Safe Operatio
