Page 3137 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA2CY±01 F16840 Rolling Diaphragm Dust Cover ± SUSPENSION AND AXLEREAR PNEUMATIC CYLINDER SA±133 3129 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION 1. INSPECT ROLLING DIAPHRAGM (a) Lift up th

Page 3138 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA0KM±05 SA±134 ± SUSPENSION AND AXLEREAR PNEUMATIC CYLINDER 3130 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION Installation is in the reverse order of removal (See page SA±131).

Page 3139 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA2BG±02 F14308 58 (591, 43) Cushion Retainer Insulator Hollow Spring Shock Absorber  Bushing N´m (kgf´cm, ft´lbf) : Specified torque  Non±reusable part Coil Spring   140 (1,428, 103)  Ret

Page 3140 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F16917 58 (591, 43) Cushion Insulator Hollow Spring Shock Absorber N´m (kgf´cm, ft´lbf) : Specified torque  Non±reusable part Coil Spring   140 (1,428, 103)  Retainer Lateral Control Rod  S

Page 3141 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA2BH±02 F14305 F14306 F16918 ± SUSPENSION AND AXLECOIL SPRING AND REAR SHOCK ABSORBER SA±137 3133 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE REAR WHEELS Torque: 110 N´m (1,150 kgf

Page 3142 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F16919 F16920 F14307 F04396 SA±138 ± SUSPENSION AND AXLECOIL SPRING AND REAR SHOCK ABSORBER 3134 Author: Date: 2005 SEQUOIA (RM1146U) (c) While holding the piston rod, remove the nut, retainer,

Page 3143 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA174±05 SA0627 ± SUSPENSION AND AXLECOIL SPRING AND REAR SHOCK ABSORBER SA±139 3135 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION Normal Type: INSPECT SHOCK ABSORBER Compress and extend the

Page 3144 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA2BI±02 W03120F07370 50 mm (1.97 in.)30 mm (1.18 in.) F17130 50 mm (1.97 in.) High Pressure Chamber Side:130 mm (5.12 in.) F17131 Low Pressure Chamber Side:50 mm (1.97 in.) 40 mm (1.57 in.) SA±140
