Page 4065 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
206
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
If you need accelerationÐfor example,
when passingÐdepress the accelerator
pedal enough for the vehicle to exceed
the set sp

05_SEQUOIA_U (L/O 0408)
206
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
If you need accelerationÐfor example,
when passingÐdepress the accelerator
pedal enough for the vehicle to exceed
the set speed. When you release it, the
vehicle will return to the speed set prior
to the acceleration.
CANCELLING THE PRESET SPEED
You can cancel the preset speed by:
a. Pulling the lever in the ªCANCELº di-
rection and releasing it.
b. Depressing the brake pedal.
c. Pushing ªON±OFFº button.
If the vehicle speed falls below about 40
km/h (25 mph), the preset speed will auto-
matically cancel out.
If the vehicle speed drops 16 km/h (10
mph) below the preset speed, the preset
speed will also automatically cancel out.
If the preset speed automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.RESETTING TO A FASTER SPEED
Push the lever up in the ª+ RESº direction
and hold it. Release the lever when the
desired speed is attained. While the lever
is held up, the vehicle will gradually gain
speed.
However, a faster way to reset is to ac-
celerate the vehicle and then push the
lever down in the ª± SETº direction.
RESETTING TO A SLOWER SPEED
Push the lever down in the ª± SETº direc-
tion and hold it. Release the lever when
the desired speed is attained. While the
lever is held down, the vehicle speed will
gradually decrease.
However, a faster way to reset is to de-
press the brake pedal and then push the
lever down in the ª± SETº direction.
Even if you turn off the overdrive switch,
with the cruise control on, engine braking
will not be applied because the cruise
control is not cancelled. To decrease the
vehicle speed, reset to a slower speed
with the cruise control lever or depress
the brake pedal. If you use the brake
pedal, cruise control is cancelled.RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal, pushing the lever up in the
ª+ RESº direction will restore the speed
set prior to cancellation.
CRUISE CONTROL FAILURE WARNING
If the ªCRUISEº indicator light in the
instrument cluster flashes when using the
cruise control, press the ªON±OFFº button
to turn the system off and then press it
again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.

Page 4066 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
207
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio/video system
Reference208 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Page 4067 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
208
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Type 1: AM´FM radio/cassette player/com-
pact disc player (with compact disc
changer controller)Type 2: AM´FM radio/cassette p

Page 4068 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
209
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
TONE AND BALANCE
For details about your systems tone and
balance controls, see the description of
your own system.
Tone
How go

Page 4069 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
210
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
YOUR COMPACT DISC PLAYER WITH
CHANGER (type 2)
When you insert a disc, push the ªLOADº
button and gently push the disc in with

Page 4070 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
211
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Details of specific buttons, controls, and
features are described in the alphabetical
list that follows.
ÐControls and features

Page 4071 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
212
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune

05_SEQUOIA_U (L/O 0408)
212
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in
the desired station. (See ªTUNEº or
ªSEEK/TRACKº.) Push and hold down the
button until you hear a beepÐthis will set
the station to the button. The button num-
ber will appear on the display.
To recall a preset station: Push the button
for the station you want. The button num-
ber and station frequency will appear on
the display.
These systems can store one AM and two
FM stations for each button. (The display
will show ªAMº, ªFM1º or ªFM2º when you
push ªAMº or ªFMº button.)
(Eject button)
Push the cassette tape eject button to
eject a cassette. Push the compact disc
eject button to eject a compact disc.
(Program)
Push ª
º (preset button 4) to select
the other side of a cassette tape. The
display indicates which side is currently
selected (ª
º indicates the top side, ªº
indicates the bottom side).
Auto±reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
(Reverse/Fast forward button)
Cassette player
Push ª
º (preset button 6) to fast for-
ward a cassette tape. ªFFº will appear on
the display. Push ª
º (preset button 5)
to rewind a tape. ªREWº will appear on
the display.
To stop the tape while it is fast forward-
ing, push ª
º or ªTAPEº button. To stop
the tape while it is rewinding, push ª
º
or ªTAPEº button.
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast forwards completely,
the cassette will play the other side of the
tape using the auto±reverse feature.Compact disc player
Push and hold ª
º (preset button 6) or
ª
º (preset button 5) to fast forward or
reverse within a compact disc. When you
release the button, the compact disc play-
er will resume playing.
AM
Push the ªAMº button to turn on the radio
and select the AM band. ªAMº will appear
on the display.
AUDIO CONTROL (Tone and sound bal-
ance adjustment function)
Each time you push the ªAUDIO
CONTROLº knob, the mode changes. To
adjust the tone and balance, turn the
knob.
BAS: Adjusts low±pitched tones. The dis-
play ranges from ±5 to 5.
MID (on some models): Adjusts mid±
pitched tones. The display ranges from ±5
to 5.
TRE: Adjusts high±pitched tones. The dis-
play ranges from ±5 to 5.
FAD: Adjusts the sound balance between
the front and rear speakers. The display
ranges from F7 to R7.

Page 4072 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
213
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push

05_SEQUOIA_U (L/O 0408)
213
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push the ªDISCº button to play a compact
disc.
When the audio system is set into com-
pact disc operation, the display shows the
track, or track and disc number currently
being played.
Vehicles with rear seat entertainment sys-
temÐ
The ªDISCº button may also be used to
operate a DVD player when a disc is
loaded in the DVD player. Pressing the
ªDISCº button changes between the CD
player and DVD player. When the DVD
player is in operation, ªAUXº appears on
the display.
Error messages
If the player malfunctions, your audio sys-
tem will display one of the four following
error messages.
ªWAITº: The compact disc player unit
may be too hot. Allow the player to cool
down.
ªERROR 1º: The disc may be dirty, dam-
aged or inserted incorrectly (up±side
down). Clean the disc and re±insert it.ªERROR 3º: There is a problem inside
the system. Eject the disc or magazine.
Set the disc or magazine again.
ªERROR 4º: Over±current. Ask your
Toyota dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
Dolby
B NR*
If you are listening to a tape that was
recorded with Dolby B Noise Reduction,
push ª
º (preset button 3). ªº will
appear on the display. Push the button
again to turn off Dolby B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used to re-
cord the tape.
*: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. ªDOLBYº and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
FM
Push the ªFMº button to turn on the radio
and select the FM band. ªFM1º or ªFM2º
will appear on the display. This system
allows you to set twelve FM stations, two
for each of the preset button.PWR´VOL (Power and Volume)
Push ªPWR´VOLº to turn the audio system
on and off. Turn ªPWR´VOLº to adjust the
volume.
RAND (Random)
Push ª
º to listen the tracks on the
disc in random order. ª
º will ap-
pear on the display. The disc you are
listening to will play in random order. To
turn off the random feature, push this but-
ton again.
RPT (Repeat)
Cassette player
Push ªRPTº (preset button 2) while the
track is playing. ª
º will appear on
the display. When the track ends, it will
automatically rewind and replay. To turn
off the repeat feature, push this button
again.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.
