IN0253
WRONG CORRECT
IN0252
WRONG CORRECT IN±6
± INTRODUCTIONREPAIR INSTRUCTIONS
6 Author: Date:
2005 SEQUOIA (RM1146U)
(k) Care must be taken when jacking up and supporting the
vehicle. Be sure to lift and support the vehicle at the prop-
er locations (See page IN±8).
Cancel the parking brake on the level place and
shift the transmission in N position.
When jacking up the front wheels of the vehicle, first
place stoppers behind the rear wheels.
When jacking up the rear wheels of the vehicle, first
place stoppers before the front wheels.
When either the front or rear wheels only should be
jacked up, set rigid racks and place stoppers in front
and behind of the other wheels on the ground.
After the vehicle is jacked up, be sure to support it
on rigid racks. It is extremely dangerous to do any
work on a vehicle raised on a jack, even for a job that
can be finished quickly.
(l) Observe the following precautions to avoid damage to the
following parts:
(1) Do not open the cover or case of the ECU unless
absolutely necessary. (If the IC terminals are
touched, the IC may be destroyed by static electric-
ity.)
(2) To disconnect vacuum hoses, pull off the end, not
the middle of the hose.
(3) To pull apart electrical connectors, pull on the con-
nector itself, not the wires.
(4) Be careful not to drop electrical components, such
as sensors or relays. If they are dropped on a hard
floor, they should be replaced and not reused.
(5) When steam cleaning an engine, protect the elec-
tronic components, air filter and emission±related
components from water.
(6) Never use an impact wrench to remove or install
temperature switches or temperature sensors.

Trouble Code (Example Code 42, 44)
ON
OFF
0.5 sec.0.5 sec.
1.5 sec.2.5 sec.
4 sec.
Repeat
42
44
D05981
Hand±held
Tester
DLC3
DI±912
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1106 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:

If no code appears, inspect the diagnostic circuit, and
BRAKE warning light circuit.
Trouble AreaSee page
Tc terminal circuitDI±1055
BRAKE warning light circuitDI±1033 or
DI±1038

When the parking brake is applied or the level of the brake
fluid is low, the BRAKE warning light comes on.

If all sensors are normal, a normal system code is output.
(A cycle of 0.25 sec. ON and 0.25 sec. OFF is repeated.)

If 2 or more trouble codes are identified at the same time,
the codes will be displayed in ascending order.
USING HAND±HELD TESTER:
3. CHECK DTC
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch to the ON position.
(c) Read the DTC by following the prompts on the tester
screen.
HINT:
Refer to the hand±held tester operator's manual for further de-
tails.

DID99±01
DI±1694
± DIAGNOSTICSBODY CONTROL SYSTEM
1888 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
1. DATA LIST
HINT:
According to the DATA LIST displayed by the hand±held tester, you can read the values of the switches,
sensors, actuators and so on without parts removal. Reading the DATA LIST as a first step of troubleshooting
is one of the methods to shorten labor time.
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
(c) According to the display on the tester, read the ºDATA LISTº.
BODY ECU:
ItemMeasurement Item/Display
(Range)Normal ConditionDiagnostic Note
KEY UNLK WRN SWKey unlock warning switch/ON or
OFFON: Key is in ignition key cylinder
OFF: No key is in ignition key cyl-
inder
±
ACC SWACC switch/ON or OFFON: Ignition switch ACC
OFF: Ignition switch OFF±
IG SWIG switch/ON or OFFON: Ignition switch ON
OFF: Ignition switch OFF±
PARKING BRAKE SWParking brake switch/ON or OFF
ON:
Parking brake pedal depressed
(ON)
OFF:
Parking brake released (OFF)
±
HOOD COURTSY SWHood courtesy switch/ON or OFF
ON: Engine hood OPEN
(Hood courtesy switch ON)
OFF: Engine hood CLOSED
(Hood courtesy switch OFF)
±
D DOR CTY SWDriver door courtesy light switch/
ON or OFFON: Driver door is opened
OFF: Driver door is closed±
P DOR CTY SWFront passenger door courtesy
light switch/ON or OFF
ON: Front passenger door is
opened
OFF: Front passenger door is
closed
±
Rr DOR CTY SWRear passenger door courtesy
light switch/ON or OFF
ON: Rear passenger door is
opened
OFF: Rear passenger door is
closed
±
MIRR SEL SW RRemote control mirror switch pas-
senger side/ON or OFF
ON: Remote control mirror switch
passenger side is selected
OFF: Remote control mirror switch
passenger side is not selected
±
MIRR SEL SW LRemote control mirror switch driv-
er side/ON or OFF
ON: Remote control mirror switch
driver side is selected
OFF: Remote control mirror switch
driver side is not selected
±
MIRR POS SW RRemote control mirror switch R
position/ON or OFF
ON: Remote control mirror switch
R position is selected
OFF: Remote control mirror switch
R position is not selected
±
