REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BR±17).
NOTICE:
Apply lithium soap base glycol grease to the rubber parts indicated by the arrows (See page
BR±15).
Page 3194 of 4323
BR08Y±07
± BRAKEBRAKE MASTER CYLINDER
BR±19
3186 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±16).
HINT:
After installation, fill the brake reservoir with brake fluid and bleed brake system (See page BR±4).
Check for leaks.
NOTICE:
In case of replacing the master cylinder assembly or master cylinder pressure sensor, perform the
zero point calibration of the steering angle, master cylinder pressure, yawrate and deceleration sen-
sors (See page DI±897).
Page 3195 of 4323
BR2237
BR0AK±07
BR2238
1st3rd
2nd
GOOD
NO GOOD BR±20
± BRAKEBRAKE BOOSTER ASSEMBLY
3187 Author: Date:
2005 SEQUOIA (RM1146U)
BRAKE BOOSTER ASSEMBLY
ON±VEHICLE INSPECTION
1. OPERATING CHECK
(a) Depress the brake pedal several times with the engine off
and check that there is no change in the pedal reserve
distance.
(b) Depress the brake pedal and start the engine. If the pedal
goes down slightly, operation is normal.
2. AIR TIGHTNESS CHECK
(a) Start the engine and stop it after 1 or 2 minutes. Depress
the brake pedal several times slowly.
If the pedal goes down farthest the 1st time, but gradually rises
after the 2nd or 3rd time, the booster is airtight.
(b) Depress the brake pedal while the engine is running, and
stop the engine with the pedal depressed. If there is no
change in the pedal reserve travel after holding the pedal
for 30 seconds, the booster is airtight.
Page 3196 of 4323
BR10G±04
F16311
Master CylinderVacuum Hose
Level Warning
Switch ConnectorBrake Booster
GasketClevis Pin Brake Booster Bracket Clip
: Specified torque
N´m (kgf´cm, ft´lbf)
Non±reusable partPedal Return Spring
Wire Harness
Bracket
Lower Finish Panel
Food Lock Release Lever No. 2 Heater to Register Duct
Cowl Side Trim Board
Front Door Scuff Plate
GasketClevis
Vacuum Switch Connector
19.5 (195, 14)
25 (250, 18)
25 (250, 18)
ClipCheck Valve
25 (250, 18)
Side Panel
Wire Harness
13 (130, 9)
Clip
Master Cylinder
Presser Sensor Connector
± BRAKEBRAKE BOOSTER ASSEMBLY
BR±21
3188 Author: Date:
2005 SEQUOIA (RM1146U)
COMPONENTS
Page 3197 of 4323
BR10H±05
BR3753
BR±22
± BRAKEBRAKE BOOSTER ASSEMBLY
3189 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE MASTER CYLINDER (See page BR±16)
2. DISCONNECT VACUUM HOSE FROM BRAKE
BOOSTER
3. DISCONNECT 2 VACUUM SWITCH CONNECTORS
FROM BRAKE BOOSTER
4. REMOVE FRONT DOOR SCUFF PLATE, COWL SIDE
TRIM BOARD, SIDE PANEL, LOWER FINISH PANEL
AND NO. 2 HEATER TO REGISTER DUCT (See page
BO±89)
5. REMOVE PEDAL RETURN SPRING
6. REMOVE CLIP AND CLEVIS PIN
7. REMOVE BRAKE BOOSTER
(a) Remove the 4 nuts, pull out the brake booster.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
(b) Remove the gasket from the brake booster bracket.
(c) Loosen the lock nut then remove the clevis.
Torque: 25 N´m (250 kgf´cm, 18 ft´lbf)
(d) Remove the check valve.
(e) Remove the 4 nuts, brake booster bracket and gasket
from the brake booster.
Torque: 25 N´m (250 kgf´cm, 18 ft´lbf)
Page 3198 of 4323
BR1NE±03
± BRAKEBRAKE BOOSTER ASSEMBLY
BR±23
3190 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±22).
HINT:
Fill the brake reservoir with brake fluid and bleed brake system (See page BR±4).
Check the brake pedal hight (See page BR±6).
Do the operational check (See page BR±20).
Page 3199 of 4323
BR10J±04
F07750
Clip
Inner Pad
Anti±rattle
SpringOuter Pad
Anti±squeal Shim
Pin
Inner Anti±squeal
Shim
Disc brake grease BR±24
± BRAKEFRONT BRAKE PAD
3191 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT BRAKE PAD
COMPONENTS
Page 3200 of 4323

BR10K±04
F07748
F07749
R13537
± BRAKEFRONT BRAKE PAD
BR±25
3192 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
1. REMOVE FRONT WHEEL
2. INSPECT PAD LINING THICKNESS
Check the pad thickness and replace pads if not within specifi-
cation.
Minimum thickness: 1.0 mm (0.039 in.)
3. REMOVE CLIP, 2 PINS AND ANTI±RATTLE SPRING
4. REMOVE 2 PADS WITH 4 ANTI±SQUEAL SHIMS
NOTICE:
The anti±rattle spring and clip can be used again provided
that they have sufficient rebound, no deformation, cracks
or wear, and have had all rust, dirt and foreign particles
cleaned off.
5. CHECK DISC THICKNESS AND RUNOUT
(See page BR±30)
6. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti±squeal shims must be
replaced together with the pads.
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the pistons with a monkey wrench handle or
equivalent.
HINT:
Tape the monkey wrench handle before use.
Always change the pad on one wheel at a time as there
is a possibility of the opposite piston flying out.
If the piston is difficult to push in, loosen the bleeder plug
and push in the piston while letting some brake fluid es-
cape.
(c) Install the 4 anti±squeal shims to new pads.
