Page 1769 of 4323
I28464
ECM
Sub J/B No.4
23
E4
1328
T5
15
A205
4E
TC
TC5
4B
5
4C 5
4D
5
4A 15
1F 9
1A
J43
J/C12
T17 P±B P±B Translate ECU
TCP±B
P±B
O
O 4 TC
CG D6
DLC3 Airbag Sensor
Assembly
Instrument Panel J/BTire Pressure
ECU
P±B
G
A A
IGTC
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1567
1761 Author: Date:
2005 SEQUOIA (RM1146U)
Diagnosis circuit
CIRCUIT DESCRIPTION
Making a short circuit between terminals TC and CG of the DLC3 will output DTCs from the DLC3.
WIRING DIAGRAM
HINT:
When a particular warning light stays blinking, a ground short in the wiring of terminal TC of the DLC3 or an
internal ground short in the relevant ECU is suspected.
DIDF5±01
Page 1770 of 4323
I28460
E4
TC
ECM Wire Harness View:
C00083
TCD6DLC3:
DI±1568
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1762 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check harness and connector (TC of DLC3 ± ECM).
PREPARATION:
Disconnect the E4 connector from the ECM.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Symbol
(Tester connection)ConditionSpecified condition
TC (E4±23) ± TC (D6±13)AlwaysBelow 1 W
NG Repair or replace harness or connector.
OK
Page 1771 of 4323
C00083CG
D6DLC3:
C00083
TCDLC3:
D6
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1569
1763 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check harness and connector (CG of DLC3 ± Body ground).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Symbol
(Tester connection)ConditionSpecified condition
CG (D6±4) ± Body groundAlwaysBelow 1 W
NG Repair or replace harness or connector.
OK
3 Check harness and connector (TC of DLC3 ± Body ground).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Symbol
(Tester connection)ConditionSpecified condition
TC (D6±13) ± Body
groundAlways10 kW or higher
NG Repair or replace harness, connector or each
ECU.
OK
Replace ECM (See page IN±35).
Page 1772 of 4323
DID65±01
DI±1570
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1764 Author: Date:
2005 SEQUOIA (RM1146U)
ENGINE IMMOBILISER SYSTEM
PRECAUTION
NOTICE:
When disconnecting the battery terminal, initialize the following system after the terminal is recon-
nected.
System NameSee Page
Back Door Power Window Control SystemBE±77
Page 1773 of 4323

DI1AJ±49
Vehicle Brought to Workshop
Customer Problem Analysis
Check and Clear DTCItems inside
are titles of pages in this manual,
with the page number in the bottom portion. See
the pages for detailed explanations.
Problem Symptom ConfirmationSymptom Simulation Symptom
does not occur
Symptom
occurs
DTC Check
Circuit Inspection and Part Inspection
DTC ChartProblem Symptoms Table
Identification of Problem
Repair
Confirmation Test
End
1
2
3
4
6
77
8
9
10
P. DI±1572
P. DI±1576
P. IN±24
P. DI±1573 P. DI±1576
P. DI±1578
P. DI±1580 ± DI±1599
Multiplex Communication System Inspection * 5
P. DI±1904
*: Confirm that there is no trouble by DTC check.
Normal system code
Trouble code
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI±1571
1765 Author: Date:
2005 SEQUOIA (RM1146U)
HOW TO PROCEED WITH TROUBLESHOOTING
HINT:
The ECU of this system is connected to the multiplex communication system. Therefore, before starting trou-
bleshooting, make sure to check that there is no trouble in the multiplex communication system.
Troubleshoot in accordance with the following procedures:
Page 1774 of 4323

DI1AK±28
ENGINE IMMOBILISER Check SheetInspector 's
Name:
Customer 's Name
Date Vehicle
Brought InLicence Plate No. VIN
Production Date
Odometer Reading/ /
/ /
Date Problem First Occurred
Frequency Problem Occurs/ /
ContinuousIntermittent ( times a day)
DTC Check1st Time
2nd TimeNormal System Code
Trouble Code (Code )
Normal SystemCodeTrouble Code (Code )
Symptomskm
miles
Engine does not start.
Check ItemMalfunction
Indicator LampNormal
Remains ON Does not Light Up
Immobiliser is not set.
(Engine starts with key codes other than the registered key code.)
Security indicator is always ON.
Security indicator is always ON. (Although code has been registered in the
automatic registration mode, indicator is not OFF.)
Security indicator is OFF.
(When DTC of immobiliser is output)
Security indicator is OFF.
(When DTC of immobiliser is not output)
Security indicator is abnormally blinking.
No code is output. DI±1572
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1766 Author: Date:
2005 SEQUOIA (RM1146U)
CUSTOMER PROBLEM ANALYSIS CHECK
Page 1775 of 4323

DI1AP±40
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI±1573
1767 Author: Date:
2005 SEQUOIA (RM1146U)
PROBLEM SYMPTOMS TABLE
SymptomSuspected AreaSee page
Immobiliser is not set.
(Engine starts with key codes other than the registered key code.)1. Door courtesy light switch circuit (DTC12)
2. Transponder key ECUDI±1585
IN±35
Engine does not start.
1. Key
2. Key unlock warning switch circuit (DTC11)
3. Transponder key coil
4. Transponder key ECU
5. ECM*1
DI±1582
BE±143
IN±35
IN±35
Security indicator is always ON.
1. Security indicator
2. Security indicator light circuit
3. Transponder key ECU*2
DI±1597
IN±35
Security indicator is always ON.
(Although code has been registered in the automatic registration
mode, indicator is not OFF.)1. Transponder key coil
2. Transponder key ECUBE±143
IN±35
Security indicator is OFF.
(When DTC of immobiliser is output)1. Transponder key coil
2. Transponder key ECUBE±143
IN±35
Security indicator is OFF.
(When DTC of immobiliser is not output)1. Security indicator light circuit
2. Diagnosis circuit
3. Transponder key ECUDI±1597
DI±1599
IN±35
Security indicator is abnormally blinking.Transponder key ECUIN±35
No code is output.
1. Power source circuit
2. Diagnosis circuit
3. Transponder key ECUDI±1595
DI±1599
IN±35
*1 : Check that the key which did not start the engine has been registered, and that it is possible to start with
any other already registered key.
*2 : Finish the automatic registration mode because the mode might still be set.
Page 1776 of 4323

DIABB±02
I24389
T16 Transponder Key ECU: DI±1574
± DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1768 Author: Date:
2005 SEQUOIA (RM1146U)
TERMINALS OF ECU
Symbols (Terminals No.)Wiring ColorConditionSpecified condition
+B e GND
(T16 ± 1 e T16 ± 14)W±R e OAlways10 to 14 V
IG e GND
(T16 ± 2 e T16 ± 14)B±O e OIgnition switch ON10 to 14 V
D e GNDWLOIgnition switch ON " 10 to 14 V " D e GND
(T16 ± 3 e T16 ± 14)W±L e OIgnition switch ON "
Connect terminals OP3 and CG of DLC310 to 14 V "
Below 2 V
CODE e GND
(T16 ± 4 e T16 ± 14)R±Y e OIgnition switch ON10 to 14 V
RXCK e GND
(T16 ± 5 e T16 ± 14)LG e OIgnition switch ON10 to 14 V
VC12 e AGND
(T16 ± 6 e T16 ± 12)GR±B e GR±LAlways10 to 14 V
IND e GNDLG BO
Security indicator light is on. (It flashes when the immobiliser
ti ti)3 to 6 V " IND e GND
(T16 ± 7 e T16 ± 14)LG±B e Osystem is operating.) "
Security indicator light is off.3 to 6 V "
Below 1 V
CTY e GNDGR LODriver's door closed " 10 to 14 V " CTY e GND
(T16 ± 8 e T16 ± 14)GR±L e ODriver s door closed "
Driver's door open10 to 14 V "
Below 1 V
KSW e GNDYGOKey unlock warning switch ON (Key inserted) " Below 1 V " KSW e GND
(T16 ± 9 e T16 ± 14)Y±G e OKey unlock warning switch ON (Key inserted) "
Key unlock warning switch OFF (Key not inserted)Below 1 V "
10 to 14 V
EFII e GND
(T16 ±10 e T16 ± 14)L±Y e OIgnition switch ON10 to 14 V
EFIO e GND
(T16 ±11 e T16 ± 14)P±G e OIgnition switch ON10 to 14 V
AGND e Body ground
(T16 ±12 e Body
ground)
GR±L e Body groundAlwaysBelow 1 V
TXCT e GND
(T16 ± 13 e T16 ± 14)Y±G e OIgnition switch ON10 to 14 V
GND e Body ground
(T16 ±14 e Body
ground)
O e Body groundAlwaysBelow 1 V
