DIDEU±01
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
DI±1823
2017 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
1. DATA LIST
HINT:
According to the DATA LIST displayed by the hand±held tester, you can read the value of the switch, sensor,
actuator and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one
of the methods to shorten labor time.
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
(c) According to the display on the tester, read the DATA LIST.
P±DOOR:
ItemMeasurement Item/Dis-
play (Range)Normal conditionDiagnostic Note
P P/W AUTO SW
Front passenger power
window auto SW signal/
ON or OFFON: Front passenger power window auto UP/DOWN SW
is ON
OFF: Front passenger power window auto UP/DOWN SW
is OFF
±
LIMIT SWJam protection limit SW/
ON or OFFON: Window is almost fully open
OFF: Window is open*1
LOCK POS SWLock position SW signal/
ON or OFFON: Door lock is in unlock position
OFF: Door lock is in lock position±
*1: If the jam protection limit switch is turned ON, the jam protection function will stop.
Even if the switch is not turned ON when the windows are almost fully open, the window will not fully close
as jam protection operates at upper window positions during automatic±up operation.
HINT:
The following data list can be used when the power window is operated through manual±up operation during
the ACTIVE TEST.
ItemMeasurement Item/Display (Range)Normal conditionDiagnostic Note
GRASS POS±1/4
Detects things caught in the P/W / OK or
CAUTION
(Displayed during the active test)OK: Nothing caught in the range between
closed and 1/4 open*2
GRASS POS±1/2
Detects things caught in the P/W / OK or
CAUTION
(Displayed during the active test)OK: Nothing caught in the range between
1/4 open and 1/2 open*2
GRASS POS±3/4
Detects things caught in the P/W / OK or
CAUTION
(Displayed during the active test)OK: Nothing caught in the range between
1/2 open and 3/4 open*2
GRASS POS±OPEN
Detects things caught in the P/W / OK or
CAUTION
(Displayed during the active test)OK: Nothing caught in the range between
3/4 open and fully open*2
HINT:
*2: If the CAUTION is displayed without applying any resistance in each range, there must be something
caught somewhere in that range.
ItemMeasurement Item/Display (Range)Normal conditionDiagnostic Note
MIR POS SEN VVertical mirror position/Min.: 0, Max.: 5Within range from 0 to 5 V±
MIR POS SEN HVertical mirror position/Min.: 0, Max.: 5Within range from 0 to 5 V±
Page 2026 of 4323
DI±1824
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
2018 Author: Date:
2005 SEQUOIA (RM1146U)
2. ACTIVE TEST
HINT:
Performing the ACTIVE TEST using the hand±held tester allows the relay, VSV, actuator and so on to oper-
ate without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one of the
methods to shorten labor time.
It is possible to display the DATA LIST during the ACTIVE TEST.
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
(c) According to the display on the tester, perform the ACTIVE TEST.
P±DOOR:
ItemTest DetailsDiagnostic Note
P/W UP/DOWNDrive the P/W Motor UP/DOWN
During this ACTIVE TEST, jam protection,
caught detection can be monitored.
(Refer to the DATA LIST for details)
MIRR UP/DOWNMirror motor vertical operation UP/OFF/DOWN±
MIRR RIGHT/LEFTMirror motor horizontal operation RIGHT/OFF/
LEFT±
Page 2027 of 4323
DI1PS±08
I28391
Power Window Motor
Pulse Sensor
Limit Switch
Door Courtesy Light Switch Power Window Switch Assembly
Passenger Door ECU
Door Lock Control Switch
Power Window Switch
Door Courtesy Light Passenger door ECU is the same with Power Window Switch
Door Lock Assembly
Door Lock Motor
Door Unlock Detection
Switch Remote Control Mirror
(w/ Driving Position Memory)
Door Key Lock and
Unlock Switch
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
DI±1825
2019 Author: Date:
2005 SEQUOIA (RM1146U)
PARTS LOCATION
Page 2028 of 4323
DI1PQ±11
I28436
Instrument Panel J/B
BDR
CPUB
GND W±R
W±B
AW±R Engine Room J/B F10
Fusible Link BlockI18
Ignition SW
IF Battery BB 4 5ALT
8
W1L1AM1
121C6
17
1FW±L1 2 B±YIG1 AM1
1C4 ECU±IG
4
1F B±R AAJ/C
B±R
II27
B±R19
L±Y20
II23
L±Y
1
2D 2C8 SHORT PIN
ECU±B
Sub J/B No. 3
3D
3ASIG
PWR No. 2
Instrument Panel J/B
3
1J2
1E
11
II2
W±B J12
J/C12
8 6
II2 W±RFront Passenger Door ECU
W±R 11F18 J37
B±R
Sub J/B No. 3
3A 3C88J38 F18
F18 F18
F18 F18
F18 F1821
25
23
13 (*1) (*2)
(*1) (*2)
(*1) (*2)
(*1) (*2)
*1: w/ Driving Position Memory
*2: w/o Driving Position Memory DI±1826
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
2020 Author: Date:
2005 SEQUOIA (RM1146U)
CIRCUIT INSPECTION
Power source circuit
CIRCUIT DESCRIPTION
This circuit provides power to operate the passenger door ECU.
WIRING DIAGRAM
Page 2029 of 4323
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
DI±1827
2021 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check ECU±IG, AM1, PWR No. 5 and ECU±B fuse.
CHECK:
Check continuity of the ECU±IG, AM1, PWR No. 5 and ECU±B fuse.
OK:
Continuity
NG Replace the faulty fuse.
OK
2 Check voltage between terminals BDR, CPUB, SIG and GND of passenger door
ECU connector.
PREPARATION:
Turn the ignition switch ON.
CHECK:
Measure the voltage between terminals SIG and GND of the passenger door ECU of the wire harness side
connector.
OK:
Voltage: 10 to 14 V
PREPARATION:
(a) Turn the ignition switch OFF.
(b) Disconnect the passenger door ECU connector.
CHECK:
Measure the voltage between terminals BDR, CPUB and GND of the passenger door ECU of the wire har-
ness side connector.
OK:
Voltage: 10 to 14 V
OK Proceed to next circuit inspection shown in
problem symptoms table (See page DI±1818).
NG
Page 2030 of 4323
DI±1828
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
2022 Author: Date:
2005 SEQUOIA (RM1146U)
3 Check wire harness and connector between passenger door ECU and battery
(See page IN±35).
NG Repair or replace wire harness or connector.
OK
4 Check wire harness and connector between passenger door ECU and body
ground (See page IN±35).
NG Repair or replace wire harness or connector.
OK
Proceed to next circuit inspection shown in
problem symptoms table
(See page DI±1782).
Page 2031 of 4323
I28437
D21
Door Unlock Detection
SW Front RH
3 R±Y4
LSWP
LSWE W±B 4Front Passenger
Door ECU
13 24
9 F18 F18
F18 F18
*1: w/ Driving Position Memory
*2: w/o Driving Position Memory(*1) (*2)
(*1) (*2)
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
DI±1829
2023 Author: Date:
2005 SEQUOIA (RM1146U)
Door unlock detection switch circuit
CIRCUIT DESCRIPTION
The door unlock detection switch is built in the door lock motor. This switch is ON when the door lock knob
is in the unlock position and OFF when the lock knob is in the lock position. The ECU detects the door lock
knob conditions in this circuit. It is used as one of the operating conditions for the key confinement prevention
function.
WIRING DIAGRAM
DI1Q8±09
Page 2032 of 4323
DI±1830
± DIAGNOSTICSPASSENGER DOOR CONTROL SYSTEM
2024 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
HINT:
When using the hand±held tester, start the inspection from step 1 and when not using the hand±held tester,
start from step 2.
1 Check door unlock detection switch using hand±held tester.
PREPARATION:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
CHECK:
According to the display on the tester, read the DATA LIST.
P±DOOR:
ItemMeasurement Item/Dis-
play (Range)Normal conditionDiagnostic Note
LOCK POS SWLock position SW signal/
ON or OFFON: Door lock is in unlock position
OFF: Door lock is in lock position±
OK:
Indication on the tester switches between ON and OFF in accordance with the door unlock
detection switch status.
OK Proceed to next circuit inspection shown in
problem symptoms table (See page DI±1818).
NG
2 Check door unlock detection switch (See page BE±79).
NG Replace the door lock assembly.
OK
