Page 1177 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±975 1169 Author: Date: 2005 SEQUOIA (RM1146U) DTC C1337 / 37 Some Tire Are Different in Size From the Other Tires CIRCUIT DESCRIPTION Skid c

Page 1178 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±976 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1170 Author: Date: 2005 SEQUOIA (RM1146U) 4 Check harness and connector between speed sensor and skid control ECU (See page IN±35). NG

Page 1179 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±977 1171 Author: Date: 2005 SEQUOIA (RM1146U) DTC C1340 / 47 Center DIFF. Lock Circuit Malfunction CIRCUIT DESCRIPTION This circuit sends th

Page 1180 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19774 Translate Shift ActuatorABS & VSC Actuator (Skid Control ECU) VSC± CD EXI2 CSW VSC+7 T5 11 T5 29 T5 31 T5 26 T5LL W BR±Y (4WD)W 7 IL2 6 IL26 S1 2 S1CANH CANL Sub J/B No.3 Y±G (4WD) BR±Y9 3

Page 1181 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19775 TL1 TL2 TL325 F22 24 F22 23 F22B±W B B±RB±W B B±R W±B 6 IG1 9 IG1 2 IG1TL1 TL2 TL3 GND T4 Transfer Shift Actuator12 3 4 W±BW±B W±R W W±R W A J18 J/C 5 6 F10 Fusible Link Block ALT 5

Page 1182 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±980 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1174 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION PROCEDURE 1 Check center differential lock operation (See page TR±39). OK: Center

Page 1183 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±981 1175 Author: Date: 2005 SEQUOIA (RM1146U) 4 Check for open and short circuit in harnesses and connectors between termi- nals CD of the t

Page 1184 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±982 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1176 Author: Date: 2005 SEQUOIA (RM1146U) 6 Replace skid control ECU and check if the trouble occurs again (See page BR±52 and DI±911)
