Page 3881 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
22
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
To open the back window, push the
back window open switch of the trans-
mitter for about 1 second. The window
will fully open.
At

Page 3882 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
23
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
For replacement, use a CR2016 lithium
battery or equivalent.
CAUTION
Special care should be taken to pre-
vent small children fro

Page 3883 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
24
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
3. Put in a new transmitter battery with
positive (+) side up.
Close the transmitter case securely.
NOTICE
Make sure the positi

Page 3884 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
25
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
This double key turning operation to un-
lock all the side doors and back door can
be changed to a single key turning opera-
ti

Page 3885 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
26
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Drivers side
Passengers side
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch down o

Page 3886 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
27
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along

05_SEQUOIA_U (L/O 0408)
27
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also helps
prevent the doors from being opened
unintentionally.
You can set the following auto door
locking and unlocking functions.
(a) Locking linked with the shift posi-
tion
All the side doors and back door are
locked automatically when the selector le-
ver is moved out of the ªPº position with
the ignition switch in the ªONº position.
This function is the default setting for new
vehicles.
(b) Unlocking linked with the shift posi-
tion
All the side doors and back door are un-
locked automatically when the selector le-
ver is moved to the ªPº position with the
ignition switch in the ªONº position.
(c) Locking linked with the vehicle
speed
All the side doors and back door are
locked automatically when the vehicle
speed reaches 20 km/h (12 mph) or high-
er. However, if any door is unlocked dur-
ing driving, this auto locking function will
not operate until the unlocked door is
opened once.(d) Unlocking linked with opening the
driver 's door
All the side doors and back door are un-
locked automatically when the driver's
door is opened within 10 seconds after
the ignition switch is turned from ªONº to
the ªACCº or ªLOCKº position.
Setting the functions
1. Close all the side doors and back door.
2. Turn the ignition switch to the ªONº
position.
3. Within 10 seconds after the ignition
switch is turned to the ªONº position;
To set function (a)
Push and hold the front of the driver's
side power door lock switch for 5 sec-
onds with the selector lever in the ªPº
position.
To set function (b)
Push and hold the rear of the driver's
side power door lock switch for 5 sec-
onds with the selector lever in the ªPº
position.
To set function (c)
Push and hold the front of the driver's
side power door lock switch for 5 sec-
onds with the selector lever in any
position except ªPº.
ÐAutomatic door locking and
unlocking functions

Page 3887 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
28
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
To set function (d)
Push and hold the rear of the drivers
side power door lock switch for 5 sec-
onds with the selector lever

Page 3888 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual 05_SEQUOIA_U (L/O 0408)
29
2005 SEQUOIA from Aug. 04 Prod. (OM34424U)
Drivers door switches
Front passengers door switch
Automatic operation: Push the switch
completely down or pull it completely u
