2001 TOYOTA SEQUOIA Service Repair Manual

check oil service indicator isofix snow chains ABS transmission oil

Load previous 8 pages

Page 2401 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDC6±01
I28208Logical AddressDiagnostic Code
I28209
Logical AddressDiagnostic Code
± DIAGNOSTICSNAVIGATION SYSTEM
DI±2199
2393 Author: Date:
2005 SEQUOIA (RM1146U)
CHECK MODE PROCEDURE
1. SYST

Page 2402 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I28210
I28211
Sub±Code Diagnostic Code
Logical Address
DI±2200
± DIAGNOSTICSNAVIGATION SYSTEM
2394 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Read the communication diagnostic check result.
(1) R

Page 2403 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I28212
I28213
I28214
± DIAGNOSTICSNAVIGATION SYSTEM
DI±2201
2395 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:
If check results of other devices are ºCHEK,º press the ºServiceº
switch to return

Page 2404 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I28215
I28216
I28217
DI±2202
± DIAGNOSTICSNAVIGATION SYSTEM
2396 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Confirm that all diagnostic codes are ºOKº when the
check results are displayed.
If a

Page 2405 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDC7±01
± DIAGNOSTICSNAVIGATION SYSTEM
DI±2203
2397 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
TermsDescription
Physical address
3±digit, hexadecimal code assigned to

DIDC7±01
± DIAGNOSTICSNAVIGATION SYSTEM
DI±2203
2397 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
TermsDescription
Physical address
3±digit, hexadecimal code assigned to all components connected to the AVC±LAN.
Individual symbols are specified based on function. Units whose names are un-
known or relevant units are displayed with physical addresses.
Logical address2±digit, hexadecimal code assigned to all the functions in the AVC±LAN system.
HINT:
Titles for each unit are stated in the following order: parts name (physical address) [Name indicated by DTC]
1. Radio and navigation assy (physical address: 140) [AVN]
(a) Logical address: 01 (Communication control)
HINT:
Methods used to verify the cause of the problem are listed in order of probability in the verification column.
DTCNameDiagnosisVerificationSee page
D5
*1
*5Absence of registration unit
A device that the sub code shows is (was) dis-
connected from the system when turning the igni-
tion switch to the ACC or ON position.
The communication condition with the device that
the code shows cannot be obtained when the en-
gine starts.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy). *7
4. AVC±LAN circuit (Radio and
navigation assy ± Stereo compo-
nent amplifier assy).
5. AVC±LAN (Radio and navigation
assy ± Rear seat audio control-
ler). *6
6. AVC±LAN (Radio and navigation
assy ± Multi±display controller
sub±assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±2258
DI±2058
DI±2110
DI±2268
DI±2061
DI±2139
±
±
±
D8
*2
*5No response to connection
checkThe device indicated by the sub code is (was)
disconnected from the system after engine start.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy). *7
4. AVC±LAN circuit (Radio and
navigation assy ± Stereo compo-
nent amplifier assy).
5. AVC±LAN (Radio and navigation
assy ± Rear seat audio control-
ler). *6
6. AVC±LAN (Radio and navigation
assy ± Multi±display controller
sub±assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±2258
DI±2058
DI±2110
DI±2268
DI±2061
DI±2139
±
±
±

Page 2406 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±2204
± DIAGNOSTICSNAVIGATION SYSTEM
2398 Author: Date:
2005 SEQUOIA (RM1146U) D9
*1
*5
Last mode error
The device (for audio visual system) that had
functioned before the engine stopped is (w

Page 2407 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSNAVIGATION SYSTEM
DI±2205
2399 Author: Date:
2005 SEQUOIA (RM1146U) DA
*5
No response against ON/OFF
command
No response is identified when changing mode
(audio and visual mode chan

Page 2408 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±2206
± DIAGNOSTICSNAVIGATION SYSTEM
2400 Author: Date:
2005 SEQUOIA (RM1146U) DC
*3
*5
Failure in transmission
This code indicates a transmission failure to the
device indicated by the sub co

DI±2206
± DIAGNOSTICSNAVIGATION SYSTEM
2400 Author: Date:
2005 SEQUOIA (RM1146U) DC
*3
*5
Failure in transmission
This code indicates a transmission failure to the
device indicated by the sub code.
NOTE: This DTC may have no direct relationship
with the malfunction.
1. Power source circuit (Rear seat
audio controller). *6
2. Power source circuit (Multi±dis-
play controller sub±assy). *7
3. AVC±LAN circuit (Radio and
navigation assy ± Stereo compo-
nent amplifier assy).
4. AVC±LAN (Radio and navigation
assy ± Rear seat audio control-
ler). *6
5. AVC±LAN (Radio and navigation
assy ± Multi±display controller
sub±assy). *7
6. Replace stereo component am-
plifier assy.
7. Replace rear seat audio control-
ler. *6
8. Replace multi±display controller
sub±assy. *7DI±2058
DI±2110
DI±2268
DI±2061
DI±2139
±
±
±
DE
*4
*5
Slave resetThis code is stored when a slave device has been
disconnected after engine start.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy). *7
4. AVC±LAN circuit (Radio and
navigation assy ± Stereo compo-
nent amplifier assy).
5. AVC±LAN (Radio and navigation
assy ± Rear seat audio control-
ler). *6
6. AVC±LAN (Radio and navigation
assy ± Multi±display controller
sub±assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±2258
DI±2058
DI±2110
DI±2268
DI±2061
DI±2139
±
±
±
21ROM errorThis code is output when a malfunction exists in
ROM.Replace radio and navigation assy.±
22RAM errorThis code is output when a malfunction exists in
RAM.Replace radio and navigation assy.±
HINT:
*1: This code may be recorded depending on the battery condition or engine start voltage even if no
failure is detected.
*2: If the power connector is disconnected after the engine starts, this code is recorded after 180 se-
conds.
*3: This code may be stored if the ignition key is turned to the START position again with the engine
running.
*4: This code may be stored if the ignition key is held in the START position for 1 minute or more before
returning to the ON position.
*5: If the device is reported as not existing during verification, check the power source circuit and AVC±
LAN circuit for the device.
*6: w/ Rear seat audio system only.
