Page 3473 of 4323

BE2MQ±01
Press E/M and Mode Switches
at the same time.
On Duration
Normal Mode
Pressed for 5 sec.
6. Zone Setting ModeIgnition switch ON.
Pressed for 10 sec.
Zone area +1 E/M Switch ON
7. Calibration Mode
Leaving it untouched
for a while
Normal Mode
± BODY ELECTRICALCOMPASS
BE±61
3465 Author: Date:
2005 SEQUOIA (RM1146U)
CALIBRATION
1. SELECTING COMPASS DISPLAY MODE
The mode select switch allows you to select a Display or Non±display mode of the compass.
2. SETTING ZONE
Deviation between the magnetic north and ºactual northº differs depending on the terrestrial location, there-
fore, an adjustment in magnetism is required. Since the magnetic condition differs according to the area
where the vehicle will be used, it is necessary for each user to set the zone. (Refer to ºCompass Zone Mapº).
The zone setting can be changed using the E/M switch of the display.
3. PERFORMING CALIBRATION
Because each vehicle has its own magnetic field, calibration should be performed for each vehicle. This com-
pass function is used when storing the record of the vehicle's magnetic field.
4. WHEN COMPASS MAGNETIZED:
A compass could be magnetized during shipping by vessels or freight cars. Before delivery, therefore, make
sure to perform calibration and ensure that calibration can be done. If it cannot be done (cannot complete
in spite of driving round several times), it may be caused by magnetization. Demagnetize the vehicle using
a demagnetizer and perform calibration again.
5. SETTING COMPASS
Page 3474 of 4323
I28770
BE±62
± BODY ELECTRICALCOMPASS
3466 Author: Date:
2005 SEQUOIA (RM1146U)
6. ZONE SETTING MODE
(a) Turn the ignition switch ON.
(b) Keep pressing the E/M switch and MODE switch for 5 sec. when outer temperature is displayed, will
activate zone setting mode, showing a number (1±15) on the compass display.
Page 3475 of 4323

± BODY ELECTRICALCOMPASS
BE±63
3467 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:
In the initial status, º8º is displayed.
(c) The displayed number increases +1 every time the E/M switch is pressed. Referring to the map, check
the number for the area where the vehicle will be used and set the zone number.
(d) Leave it untouched for several seconds after setting and check that the compass display shows an
azimuthal direction (N, NE, E, SE, S, SW, W, or NW) or ºVARº.
7. CALIBRATION SETTING MODE
(a) After the set zone is displayed, if the E/M switch and MODE switch remains pressed for another 5 se-
conds, calibration setting mode will be activated.
(b) Keep pressing the E/M switch and MODE switch for 10 sec. when outer temperature is displayed will
also activate this mode.
(c) Drive the vehicle at a speed of 5 MPH (8 km/h) or less in a circle.
(d) Driving in a circle 1 to 3 times will display the azimuthal direction on the display, completing the calibra-
tion.
HINT:
Once calibration is completed, it is not necessary to perform the above procedures unless the magnetic field
strength is drastically changed. If this happens, the azimuthal display will be changed to ºCALº.
Page 3476 of 4323
BE0TC±09
I28412
Mirror Assembly
Mirror Heater
Rear Window Defogger
Instrument Panel J/B
MIRROR HEATER Relay
Ignition Switch Rear Defogger SwitchEngine Room J/B
DEFOG Relay
MIR HTR Fuse
BE±64
± BODY ELECTRICALDEFOGGER SYSTEM
3468 Author: Date:
2005 SEQUOIA (RM1146U)
DEFOGGER SYSTEM
LOCATION
Page 3477 of 4323

I28731
101 27
BE2MP±01
I18596
I18689
Wire Harness Side:
I18559
1
4
5
2 3
± BODY ELECTRICALDEFOGGER SYSTEM
BE±65
3469 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. Connecter connected:
INSPECT DEFOGGER TIMER OPERATION
(a) Connect the positive (+) lead from the voltmeter to termi-
nals 1, 2 and 7 of the panel switch connector and the neg-
ative (±) lead to terminal 10.
(b) When the switch is OFF, the voltage should be approx.
12 V.
(c) Turn the defogger switch ON and check that the indicator
comes on and that the voltage is less than 1 V.
(d) After 15 minutes, check that the switch is OFF and the
voltage is approx. 12 V.
If operation is not as specified, replace the switch.
2. Connector disconnected:
INSPECT DEFOGGER SWITCH (in INTEGRATION
CONTROL PANEL SWITCH) CIRCUIT
Disconnect the connector from the panel switch and inspect the
connector on the wire harness side, as shown in the chart be-
low.
Tester connectionConditionSpecified condition
10 ± GroundAlwaysContinuity
1 ± GroundAlwaysBattery voltage
2 ± GroundIgnition switch OFF or ACCNo voltage
2 ± GroundIgnition switch ONBattery voltage
7 ± GroundIgnition switch OFFNo voltage
7 ± GroundIgnition switch ACC or ONBattery voltage
If the circuit is not as specified, inspect the circuit connected to
other parts.
3. INSPECT DEFOGGER RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant1 ± 2, 3 ± 4Continuity
Apply B+ between
terminals 1 and 2.3 ± 5Continuity
If continuity is not as specified, replace the relay.
Page 3478 of 4323

I05027
2
13 5
2 5
135
I01291
Tester Probe
Tin FoilHeat Wire
I01292
At Center
I01293
0 Volts
Broken
WireSeveral
Volts
Battery
Side Ground SideFoil Strip
BE±66
± BODY ELECTRICALDEFOGGER SYSTEM
3470 Author: Date:
2005 SEQUOIA (RM1146U)
4. INSPECT MIRROR HEATER RELAY CONTINUITY
ConditionTester connectionSpecified condition
Always1 ± 2Continuity
Always3 ± 5No continuity
Apply B+ between
terminals 1 and 2.3 ± 5Continuity
If continuity is not as specified, replace the relay.
5. INSPECT DEFOGGER WIRE
NOTICE:
When cleaning the glass, use a soft, dry cloth, and
wipe the glass in the direction of the wire. Take care
not to damage the wires.
Do not use detergents or glass cleaners with abrasive
ingredients.
When measuring voltage, wrap a piece of tin foil
around the tip of the negative probe and press the foil
against the wire with your finger, as shown in the il-
lustration.
(a) Turn the ignition switch ON.
(b) Turn the defogger switch ON.
(c) Inspect the voltage at the center of each heat wire, as
shown.
VoltageCriteria
Approx. 5 VOkay (No break in wire)
Approx. 10 V or 0 VBroken wire
HINT:
If there is approximately 10 V, the wire is broken between the
center of the wire and the positive (+) end. If there is no voltage,
the wire is broken between the center of the wire and ground.
(d) Place the voltmeter positive (+) lead against the defogger
wire on the battery side.
(e) Place the voltmeter negative (±) lead with the foil strip
against the wire on the ground side.
(f) Slide the positive (+) lead from the battery to the ground
side.
(g) The point where the voltmeter deflects from several V to
zero V is the place where the defogger wire is broken.
HINT:
If the heat wire is not broken, the voltmeter indicates 0 V at the
positive (+) end of the heat wire but gradually increases to about
12 V as the meter probe moves to the other end.
Page 3479 of 4323

I01294
Repair Point
Broken
Wire
Masking Tape
I01295
I18583
6 4
I24872
78
I28509
5
12
± BODY ELECTRICALDEFOGGER SYSTEM
BE±67
3471 Author: Date:
2005 SEQUOIA (RM1146U)
6. IF NECESSARY, REPAIR DEFOGGER WIRE
(a) Clean the broken wire tips with grease, wax and silicon re-
mover.
(b) Place the masking tape along both sides of the wire for
repair.
(c) Thoroughly mix the repair agent (Dupont paste No.
4817).
(d) Using a fine tip brush, apply a small amount of the agent
to the wire.
(e) After a few minutes, remove the masking tape.
(f) Do not repair the defogger wire for at least 24 hours.
7. w/o Retract Mirror and Driving Position Memory:
INSPECT MIRROR HEATER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
6 and the negative (±) lead to terminal 4.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If operation is not as specified, replace the mirror.
8. w/ Retract Mirror only:
INSPECT MIRROR HEATER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
7 and the negative (±) lead to terminal 8.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If operation is not as specified, replace the mirror.
9. w/ Retract Mirror and Driving Position Memory:
INSPECT MIRROR HEATER OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (±) lead to terminal 12.
(b) Check that the mirror becomes warm.
HINT:
It will take a short time for the mirror to become warm.
If operation is not as specified, replace the mirror.
Page 3480 of 4323
BE03O±08
I28410
Power Window Regulator Assembly
Power Window Motor
Power Window Switch
Power Window
Regulator Assembly
Power Window MotorPower Window Master Switch
Driver Door ECU
Ignition Switch
Instrument Panel J/BPower Window Switch
Front Passenger Door ECU
Body ECU
(Located behind the Instrument Panel)
BE±68
± BODY ELECTRICALPOWER WINDOW CONTROL SYSTEM
3472 Author: Date:
2005 SEQUOIA (RM1146U)
POWER WINDOW CONTROL SYSTEM
LOCATION
