Page 3801 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC1L6±06 I21368 Discharge Hose Condenser Liquid Tube O±Ring Condenser Fan N´m (kgf´cm, in´lbf) : Specified torque  Non±reusable part  O±Ring Bracket Wire Harness Bracket Receiver Liquid Tube

Page 3802 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC3HJ±02 I21365 I21366 ± AIR CONDITIONINGCONDENSER AC±67 3794 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of installation,

Page 3803 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I21367 AC±68 ± AIR CONDITIONINGCONDENSER 3795 Author: Date: 2005 SEQUOIA (RM1146U) 9. REMOVE CONDENSER (a) Remove the 2 bolts. (b) Pull the condenser forward and then upward. HINT: At the time o

Page 3804 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC1L8±02 ± AIR CONDITIONINGCONDENSER AC±69 3796 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION Installation is in the reverse order of removal (See page AC±67).

Page 3805 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC3I8±02 AC±70 ± AIR CONDITIONINGREAR A/C EVAPORATOR 3797 Author: Date: 2005 SEQUOIA (RM1146U) REAR A/C EVAPORATOR ON±VEHICLE INSPECTION 1. CHECK QUANTITY OF GAS DURING REFRIGERATION CYCLE 2.

Page 3806 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC3I9±02 I21380 I21383 ± AIR CONDITIONINGREAR A/C EVAPORATOR AC±71 3798 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM HINT: At the time of ins

Page 3807 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I21799 I21384 I21800 AC±72 ± AIR CONDITIONINGREAR A/C EVAPORATOR 3799 Author: Date: 2005 SEQUOIA (RM1146U) 12. REMOVE EXPANSION VALVE (a) Remove the 4 screws and 2 brackets. (b) Pry out the pac

Page 3808 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual AC3IA±01 ± AIR CONDITIONINGREAR A/C EVAPORATOR AC±73 3800 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION Installations is in the reverse order of removal (See page AC±71).
