Page 3185 of 4323
BR10A±04
F13306
No. 2 Heater to Register DuctLower Finish Panel
Hood Lock
Release Lever Parking Brake Wire
Clip
Pedal Pad Parking Brake
Pedal Assembly
: Specified torque
N´m (kgf´cm, ft´lbf)
Cowl Side Trim BoardFront Door Scuff Plate
13 (130, 9)
Adjusting Nut
Lock Nut Clip
Return Spring
Return Spring Damper
32 (320, 23)
Parking Brake Switch Cushion
5.4 (55, 48 in.´lbf)
Pedal Assembly
Lithium soap base glycol grease
Non±reusable part Bushing Bushing
Pedal Bracket
Parking Brake Switch
Connector
Side Panel BR±10
± BRAKEPARKING BRAKE PEDAL
3177 Author: Date:
2005 SEQUOIA (RM1146U)
COMPONENTS
Page 3186 of 4323
BR10B±04
± BRAKEPARKING BRAKE PEDAL
BR±11
3178 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE FRONT DOOR SCUFF PLATE, COWL SIDE TRIM BOARD, SIDE PANEL, LOWER FIN-
ISH PANEL AND NO. 2 HEATER TO REGISTER DUCT (See page BO±89)
2. REMOVE PARKING BRAKE PEDAL ASSEMBLY
(a) Disconnect the parking brake switch connector.
(b) Remove the lock nut and adjusting nut from the parking brake wire.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(c) Remove the clip and disconnect the parking brake wire from the parking brake pedal assembly.
(d) Remove the 4 bolts and parking brake pedal assembly.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
Page 3187 of 4323
BR1NB±02
BR±12
± BRAKEPARKING BRAKE PEDAL
3179 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE RETURN SPRING AND RETURN SPRING DAMPER
2. REMOVE CUSHION
3. REMOVE PEDAL ASSEMBLY
(a) Remove the nut, bolt and pedal assembly.
Torque: 32 N´m (320 kgf´cm, 23 ft´lbf)
(b) Remove the 2 bushings from the pedal assembly.
(c) Remove the pedal pad.
4. REMOVE PARKING BRAKE SWITCH
Remove the screw and parking brake switch.
Page 3188 of 4323
BR1NC±02
± BRAKEPARKING BRAKE PEDAL
BR±13
3180 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BR±12).
NOTICE:
Apply lithium soap base glycol grease to the parts indicated by the arrows (See page BR±10).
Page 3189 of 4323
BR10C±03
BR±14
± BRAKEPARKING BRAKE PEDAL
3181 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±11).
HINT:
After the installation, check and adjust parking brake pedal travel (See page BR±9).
Page 3190 of 4323
BR10E±04
F16310
Master Cylinder
Level Warning
Switch ConnectorBrake Booster
Cap
Strainer
Reservoir Set Screw
Grommet
Cylinder Body
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
Lithium soap base glycol greaseWire Harness
BracketMaster Cylinder
Pressure Sensor
Connector
Master Cylinder Pressure Sensor Seal
25 (250, 18)
25 (250, 18)
19.5 (195, 14)
Wire Harness
1.5 (15, 13 in.´lbf)
Grommet
± BRAKEBRAKE MASTER CYLINDER
BR±15
3182 Author: Date:
2005 SEQUOIA (RM1146U)
BRAKE MASTER CYLINDER
COMPONENTS
Page 3191 of 4323
BR08U±05
F16312
F16313
BR±16
± BRAKEBRAKE MASTER CYLINDER
3183 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. DRAW OUT FLUID WITH SYRINGE
NOTICE:
Wash the brake fluid off immediately if it comes into con-
tact with any painted surface.
2. DISCONNECT LEVEL WARNING SWITCH CONNEC-
TOR
3. DISCONNECT 2 MASTER CYLINDER PRESSURE
SENSOR CONNECTORS
4. DISCONNECT WIRE HARNESS
Using a clip remover, disconnect the wire harness from the wire
harness bracket.
5. DISCONNECT BRAKE LINES
Using SST, disconnect the 2 brake lines from the master cylin-
der.
SST 09023±38201
Torque: 19.5 N´m (195 kgf´cm, 14 ft´lbf)
6. REMOVE MASTER CYLINDER
(a) Remove the 2 nuts and wire harness bracket.
Torque: 25 N´m (250 kgf´cm, 18 ft´lbf)
(b) Pull out the master cylinder from the brake booster.
Page 3192 of 4323
BR1ND±02
± BRAKEBRAKE MASTER CYLINDER
BR±17
3184 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE RESERVOIR
(a) Remove the set screw and pull out the reservoir.
Torque: 1.5 N´m (15 kgf´cm, 13 in.´lbf)
(b) Remove the cap and strainer from the reservoir.
2. REMOVE 2 GROMMETS
3. REMOVE SEAL
4. REMOVE 2 MASTER CYLINDER PRESSURE SENSORS
Torque: 25 N´m (250 kgf´cm, 18 ft´lbf)
