± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
DI±1903
2097 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSIS SYSTEM
1. DIAGNOSIS SYSTEM
(a) Inspect the battery voltage.
Battery voltage: 11 to 14 V
If voltage is below 11 V, recharge the battery before proceeding.
(b) Check the DLC3.
The body ECU uses ISO 9141±2 for communication. The
terminal arrangement of the DLC3 complies with SAE
J1962 and matches the ISO 9141±2 format.
Verify the conditions listed in the table below:
Symbols (Terminals No.)Terminal DescriptionConditionSpecified Condition
SIL(7) ± SG(5)Bus º+º lineDuring communicationPulse generation
SG(5) ± Body groundSignal groundAlwaysBelow 1 W
BAT(16) ± Body groundBattery positiveAlways11 to 14 V
HINT:
If the hand±held tester display shows UNABLE TO CONNECT
TO VEHICLE when the cable of the hand±held tester is con-
nected to the DLC3, the ignition switch is turned to the ON posi-
tion and the tester is operated, there is a problem on either the
vehicle side or the tester side.
If communication is normal when the tester is connected
to another vehicle, inspect the DLC3 on the original ve-
hicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tester itself, so consult the Service Department listed in
the tester's instruction manual.
Page 2106 of 4323
DIDF9±01
D05981DLC3
Hand±held
Tester
DI±1904
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
2098 Author: Date:
2005 SEQUOIA (RM1146U)
DTC CHECK / CLEAR
1. DTC CHECK
(a) Checking DTCs using the hand±held tester.
(1) Connect the hand±held tester to the DLC3.
(2) Turn the ignition switch ON.
(3) Read DTCs by following the prompts on the tester
screen.
HINT:
Refer to the hand±held tester operator's manual for further de-
tails.
2. DTC CLEARANCE
A multiplex DTC indicates that a problem has been detected in
the multiplex communication system. Once the problem is
solved and the system begins to operate as designed, the DTC
will be cleared automatically. There is no need to manually clear
a multiplex DTC using the hand±held tester.
Page 2107 of 4323

DI3IR±10
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
DI±1905
2099 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
If a trouble code is indicated during the DTC check, check the components listed for that code in the table
below (proceed to the page given for that code).
DTC No.
(See Page)Detection ItemTrouble Area
B1211
(DI±1908)Driver door ECU communication stop
Driver door ECU
Wire harness
Body ECU
B1212
(DI±1911)Front passenger door ECU communication stop
Passenger door ECU
Wire harness
Body ECU
B1214
B1215
(DI±1914)Communication bus malfunction (Short to B+)
Communication bus malfunction (Short to ground)
Driver door ECU
Passenger door ECU
Back door ECU
A/C ECU (Integration control panel)
Combination meter
Memory seat ECU & switch
Wire harness
Body ECU
B1221
(DI±1924)Power window switch circuit on driver door
Power window master switch (Built in driver door ECU)
Wire harness
Body ECU
B1222
(DI±1925)Door lock switch circuit on driver door
Door lock control switch front LH (Built in driver door ECU)
Door unlock detection switch front LH
Wire harness
Body ECU
B1223
(DI±1926)Power window switch circuit on passenger door
Power window switch (Built in passenger door ECU)
Wire harness
Body ECU
B1224
(DI±1927)Door lock switch circuit on passenger door
Door lock control switch front RH (Built in passenger door
ECU)
Door unlock detection switch front RH
Wire harness
Body ECU
B1231
(DI±1928)Jam protection limit switch circuit on driver door
Limit switch (Built in power window motor)
Driver door ECU
Wire harness
Body ECU
B1232
(DI±1929)Jam protection pulse switch circuit on driver door
Pulse switch (Built in power window motor)
Driver door ECU
Wire harness
Body ECU
B1233
(DI±1930)Jam protection limit switch circuit on passenger door
Limit switch (Built in power window motor)
Passenger door ECU
Wire harness
Body ECU
B1234
(DI±1931)Jam protection pulse switch circuit on passenger door
Pulse switch (Built in power window motor)
Passenger door ECU
Wire harness
Body ECU
B1241
(DI±1932)Body ECU switch circuit diagnosis
Back door power window switch
Rear wiper and washer switch
Wire harness
Body ECU
Page 2108 of 4323

DI±1906
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
2100 Author: Date:
2005 SEQUOIA (RM1146U)B1242
(DI±1933)
Wireless door lock tuner circuit malfunction
Wireless door lock control receiver
Wire harness
Body ECU
B1243
(DI±1935)GSW terminal circuit malfunction
Airbag sensor assembly
Wire harness
Body ECU
B1244
(DI±1937)Light sensor circuit malfunction
Automatic light control sensor
Wire harness
Body ECU
B1262
(DI±1940)A/C ECU communication stop
A/C ECU (Integration control and panel)
Wire harness
Body ECU
B1271
(DI±1943)Combination meter ECU communication stop
Combination meter
Wire harness
Body ECU
B1272
(DI±1946)Memory seat ECU communication stop
(w/ Driving position memory)Memory seat ECU & switch
Wire harness
Body ECU
B1273
(DI±1949)Sliding roof ECU communication stop
(w/ Sliding roof)Sliding roof ECU
Wire harness
Body ECU
B1287
(DI±1952)Back door ECU communication stop
Back door ECU
Wire harness
Body ECU
HINT:
When either DTC B1214 or B1215 is output, a DTC for another ECU communication stop may also
be output. In this case, perform troubleshooting for DTC B1214 or B1215 first. DTC B1214 or B1215
is output when a short to +B or short to ground occurs on a communication bus.
DTCs from B1221 to B1241 do not indicate that the corresponding switch is abnormal. They notify how
the switch is operating.
If the corresponding DTC is not indicated when operating a switch, there is a problem with the switch
contact.
If a DTC is indicated when not operating switches, the corresponding switch is stuck.
Page 2109 of 4323
DI3IS±11
I27730
Instrument Panel J/B
Passenger Door ECU
(Power Window Switch) Combination Meter
Sliding Roof ECUDLC3 Body ECU
(Located behind
the instrument panel)
Driver Door ECU
(Power Window
Master Switch)
Back Door ECU
(Located inside the back door trim board) Automatic Light Control Sensor
Memory Seat ECU
& SwitchAirbag
Sensor
Assy
Power Window
Motor Front RH
Limit Switch
Pulse Switch Power Window
Motor Front LH
Limit Switch
Pulse Switch
A/C ECU
(Integration Control and Panel)
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
DI±1907
2101 Author: Date:
2005 SEQUOIA (RM1146U)
PARTS LOCATION
Page 2110 of 4323
DIDFB±01
DI±1908
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
2102 Author: Date:
2005 SEQUOIA (RM1146U)
CIRCUIT INSPECTION
DTC B1211 Driver door ECU communication stop
CIRCUIT DESCRIPTION
This DTC is indicated when communication fails between the driver door ECU and body ECU.
DTC No.DTC Detecting ConditionTrouble Area
B1211No communication from driver door ECU for more than 10Driver door ECU
Wi hB1211No communication from driver door ECU for more than 10
seconds.Wire harness
Body ECU
Page 2111 of 4323
I28467
F18
Front Passenger Door ECUD22
Driver Door ECU
Body ECU
J/C
I18
Ignition Switch
Instrument Panel J/B
Sub J/B No. 3
F10
FL Block
Sub J/B No. 3Instrument Panel J/B
Engine Room R/B J8
J/C
Battery
IEECU±B
Short Pin
ECU±IG
AM1
PWR No. 1 J/CB7 IB1
II2
J6 J7
J37 J38IB1
IB1
IB1
3C 3A 1F 1C
1L
1E 1J
2D 2C1C
1F
3C 3A ALTIG1 AM1IB1MPX1
MPX2
GND
SIGCPUB
BDR MPX2
MPX1W±L
W±R
L±W G±B
W±B
B±RW±L
G±B
G±B
W±B
B±RW±R
W±L
B±Y
B±RB±R
W±L
L±W
W±RW
W±R
W±R BBD
AF
AA48
9 1122
23
251 3
13 20
13 8
21
88 4 4
1
1 6
12
48 5
11 23
1821
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
DI±1909
2103 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
Page 2112 of 4323

DI±1910
± DIAGNOSTICSMULTIPLEX COMMUNICATION SYSTEM
2104 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check driver door ECU.
CHECK:
Check if the driver door window glass auto up function operates normally through the power window master
switch.
HINT:
With this inspection, the driver door ECU CPU can be diagnosed if it works normally or not.
OK:
Driver door side power window auto up function operates normally.
NG Go to power source circuit (See page DI±1788).
OK
2 Check wire harness and connector (Driver door ECU ± body ECU and driver door
ECU ± passenger door ECU).
PREPARATION:
Disconnect connector ºB7º of the body ECU, ºD22º of the driver door ECU and ºF18º the passenger door
ECU.
CHECK:
Measure the resistance according to the values in the table below.
OK:
Symbols (Tester connection)ConditionSpecified condition
MPX1 (B7±22) ± MPX2 (D22±8)AlwaysBelow 1 W
MPX1 (D22±20) ± MPX2 (F18±11)AlwaysBelow 1 W
MPX1 (B7±22) ± Body groundAlways10 kW or higher
MPX1 (D22±20) ± Body groundAlways10 kW or higher
NG Repair or replace wire harness.
OK
Replace the driver door ECU.
If the problem reoccurs even after replacement, replace the body ECU.
