Page 3561 of 4323

I24379
Wire Harness Side:
I18635
1
2 34
5
I18635
1
2 34
5
± BODY ELECTRICALTRAILER TOWING
BE±149
3553 Author: Date:
2005 SEQUOIA (RM1146U)
2. Trailer Socket 7 Pin Type:
INSPECT BRAKE CONTROLLER CIRCUIT
Remove the brake controller with the connector still connected
and inspect the wire harness side connector from the back side,
as shown in the table below.
Tester connectionConditionSpecified condition
1 ± 3Stop light switch ON (Brake pedal depressed)10 ± 14 V
1 ± 3Stop light switch OFF (Brake pedal released)0 V
2 ± 3Always10 ± 14 V
3 ± 4Stop light switch ON (Brake pedal depressed)10 ± 14 V
3 ± 4Stop light switch OFF (Brake pedal released)0 V
3 ± 5Light control switch TAIL or HEAD10 ± 14 V
3 ± 5Light control switch OFF0 V
If the circuit is not as specified, inspect the circuit connected to
other parts.
3. INSPECT TOWING TAIL RELAY CONTINUITY
ConditionTester connectionSpecified condition
Always1 ± 2Continuity
Always3 ± 5No continuity
Apply B+ between
terminals 1 and 2.3 ± 5Continuity
If continuity is not as specified, replace the relay.
4. INSPECT BATT CHARGE RELAY CIRCUIT
ConditionTester connectionSpecified condition
Always1 ± 2Continuity
Always3 ± 5No continuity
Apply B+ between
terminals 1 and 2.3 ± 5Continuity
If continuity is not as specified, replace the relay.
Page 3562 of 4323
BO4S4±01
± BODYBATTERY
BO±1
3554 Author: Date:
2005 SEQUOIA (RM1146U)
BATTERY
PRECAUTION
NOTICE:
When disconnecting the battery terminal, initialize the following system after the terminal is recon-
nected.
System NameSee Page
Back Door Power Window Control SystemBE±77
Page 3563 of 4323
V00005
Shape (Example) Removal/Installation
Clip RemoverPliers
Screwdriver
Scraper
BO0HX±01
BO±2
± BODYCLIP
3555 Author: Date:
2005 SEQUOIA (RM1146U)
CLIP
REPLACEMENT
The removal and installation methods of typical clips used in body parts are shown in the table below.
HINT:
If the clip is damaged during the operation, always replace it with a new clip.
Page 3564 of 4323
V00012
Removal Installation Shape (Example) Removal/Installation
Removal Installation
± BODYCLIP
BO±3
3556 Author: Date:
2005 SEQUOIA (RM1146U)
Page 3565 of 4323
BO0HY±04
BO±4
± BODYSRS AIRBAG
3557 Author: Date:
2005 SEQUOIA (RM1146U)
SRS AIRBAG
PRECAUTION
The SEQUOIA is equipped with an SRS (Supplemental Restraint System) such as the driver airbag, front
passenger airbag and side airbag. Failure to carry out service operation in the correct sequence could cause
the SRS to unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing
(including removal or installation of parts, inspection or replacement), be sure to read the precautionary no-
tices in the RS section.
Page 3566 of 4323
BO45H±02
H24348
Front Bumper
Reinforcement
Front Bumper
Energy Absorber
Front Bumper Cover
Front Bumper
Hole Cover Front Bumper
Hole Cover
3.0 (30, 27 in.´lbf)
50 (510, 37)
N´m (kgf´cm, ft´lbf)
: Specified torque
3.0 (30, 27 in.´lbf)
7.0 (71, 62 in.´lbf)
50 (510, 37)
7.0 (71, 62 in.´lbf)
Fog Light
Fog Light Side Support
Side Support
w/o Fog light:
w/o Fog light:
w/ Fog light: w/ Fog light:
± BODYFRONT BUMPER
BO±5
3558 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT BUMPER
COMPONENTS
Page 3567 of 4323
BO45I±02
H24349N´m (kgf´cm, ft´lbf)
: Specified torque Rear Bumper
Reinforcement
95 (970, 70)
7.0 (71, 62 in.´lbf)
Quarter Wheel Opening Moulding
Rear Bumper Cover Rear Bumper Side Support
Reflex Reflector Rear Bumper Protection Rear Bumper SealBack Step Reinforcement Rear Mud Guard
Rear Bumper Side Support
19 (195, 14)
19 (195, 14)
19 (195, 14)
19 (195, 14)
7.0 (71, 62 in.´lbf)
5.0 (50, 43 in.´lbf)
95 (970, 70)
5.0 (50, 43 in.´lbf)
7.0 (71, 62 in.´lbf)
7.0 (71, 62 in.´lbf)
Side Support
Rear Bumper Extension
7.0 (71, 62 in.´lbf)
7.0 (71, 62 in.´lbf)
95 (970, 70)
95 (970, 70)
x4x4x4
x4
Rear Mud Guard
BO±6
± BODYREAR BUMPER
3559 Author: Date:
2005 SEQUOIA (RM1146U)
REAR BUMPER
COMPONENTS
Page 3568 of 4323
N03433
Centering Bolt Standard Bolt
BO45J±01
H09455
H09456
H09478
± BODYHOOD
BO±7
3560 Author: Date:
2005 SEQUOIA (RM1146U)
HOOD
ADJUSTMENT
HINT:
Since the centering bolt is used as the hood hinge set bolt, the
hood cannot be adjusted with it on. Substitute the standard bolt
for the centering bolt.
1. ADJUST HOOD IN FORWARD/REARWARD
Adjust the hood by loosening the hood side hinge bolts.
Torque: 13 N´m (133 kgf´cm, 10 ft´lbf)
2. ADJUST HOOD IN VERTICAL DIRECTIONS
(a) Remove the bolts and increase or decrease the number
of washers between the hinge and hood.
(b) Install the bolts again.
Torque: 13 N´m (133 kgf´cm, 10 ft´lbf)
3. ADJUST FRONT EDGE OF HOOD IN VERTICAL
DIRECTION
Adjust the hood by turning the cushions.
4. ADJUST HOOD LOCK
Adjust the lock by loosening the bolts.
Torque: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
