Page 3601 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO464±01 H16671 H16672 H16674 5 Clips H16675 3 Clips H16676 10 Clips BO±40 ± BODYREAR WIPER AND WASHER 3593 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE REAR WIPER ARM (a) Open the co

Page 3602 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16677 H16678 H16680 H16682 ± BODYREAR WIPER AND WASHER BO±41 3594 Author: Date: 2005 SEQUOIA (RM1146U) 7. REMOVE NO. 1 SERVICE HOLE COVER 8. REMOVE NO. 2 SERVICE HOLE COVER 9. REMOVE BACK DOOR

Page 3603 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16694 BO±42 ± BODYREAR WIPER AND WASHER 3595 Author: Date: 2005 SEQUOIA (RM1146U) 12. REMOVE WASHER NOZZLE (a) Using a screwdriver, remove the washer nozzle. HINT: Tape the screwdriver tip befo

Page 3604 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual H16695 BA C D BO465±01 ± BODYREAR WIPER AND WASHER BO±43 3596 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION INSPECT REAR WASHER NOZZLE While operating the washer, check it the point where the

Page 3605 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO466±01 BE3367 2.0 ± 2.5 mm (0.079 ± 0.098 in.) 0.7 ± 0.75 mm (0.028 ± 0.0295 in.) BO±44 ± BODYREAR WIPER AND WASHER 3597 Author: Date: 2005 SEQUOIA (RM1146U) ADJUSTMENT ADJUST WASHER NOZZ

Page 3606 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO467±02 H16696 Mark Mark to Upward H16697 10 mm (0.39 in.) H16698 ± BODYREAR WIPER AND WASHER BO±45 3598 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION 1. INSTALL WASHER NOZZLE 2. INSTALL R

Page 3607 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO468±03 H24888 Quarter Opening Retainer Rear Door Outside Moulding Sub±Assembly Front Fender MouldingRear Bumper Protector Rear Bumper Extension Rear Bumper Seal Quarter Outside Moulding Rear Mudg

Page 3608 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BO469±02 H16699 H16700 Adhesive Tape H16701 Adhesive Tape ± BODYBODY OUTSIDE MOULDING BO±47 3600 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE FRONT FENDER MOULDING (a) Remove the 3 sc
