Wire Harness Side:
Canister Connector
Front View
L5
A23446
L5
± DIAGNOSTICSENGINE
DI±271
465 Author: Date:
2005 SEQUOIA (RM1146U)
4 Measure voltage and resistance of pump module connector.
PREPARATION:
(a) Disconnect the L5 canister connector.
(b) Turn the ignition switch to ON.
CHECK:
Measure the voltage and resistance of the L5 connector.
OK:
Standard:
Tester ConnectionsSpecified Conditions
L5±4 ± Body groundBetween 4.5 V and 5.5 V
L5±3 ± Body groundBetween 4.5 V and 5.5 V
L5±2 ± Body ground100 W or less
RESULT:
Test ResultsSuspected Trouble AreasProceed To
Voltage and resistance within standard rangesOpen in pressure sensor circuitA
Voltage and resistance outside standard rangesOpen in wire harness/connector (ECM ± pressure sensor)B
B Go to step 6.
A
5 Replace charcoal canister assembly.
NEXT Go to step 8.
6 Repair or replace wire harness and connectors.
HINT:
If the exhaust tail pipe has been removed, go to the next step before reinstalling it.
NEXT Go to step 8.
Page 474 of 4323
DI±272
± DIAGNOSTICSENGINE
466 Author: Date:
2005 SEQUOIA (RM1146U)
7 Replace ECM (See page SF±80).
NEXT
8 Check whether DTC output recurs.
PREPARATION:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch to ON and turn the tester ON.
(c) Wait for at least 60 seconds.
CHECK:
(a) On the tester, select the following menu items: DIAGNOSIS/ENHANCED OBD II/DTC INFO/PEND-
ING CODES.
HINT:
If no pending DTC is displayed on the tester, the repair has been successfully completed.
NEXT
Completed
Page 475 of 4323

± DIAGNOSTICSENGINE
DI±273
467 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P0455 Evaporative Emission Control System Leak
Detected (Gross Leak)
DTC P0456 Evaporative Emission Control System Leak
Detected (Very Small Leak)
DTC SUMMARY
DTCMonitoring ItemsMalfunction Detection ConditionsTrouble AreasDetection
TimingsDetection
Logic
P0455EVAP gross leak
Vacuum pump creates negative pressure
(vacuum) in EVAP system and EVAP sys-
tem pressure measured. 0.02 inch leak
pressure standard is measured at the start
and at the end of the leak check.
If stabilized pressure higher than [second
0.02 inch leak pressure standard x 0.2],
ECM determines that EVAP system has
large leakage.Fuel tank cap (loose)
Leakage from EVAP line
(Canister ± Fuel tank)
Leakage from EVAP line
(Purge VSV ± Canister)
Pump module
Leakage from fuel tank
Leakage from canister
While
ignition
switch
OFF
2 trip
P0456EVAP small leak
Vacuum pump creates negative pressure
(vacuum) in EVAP system and EVAP sys-
tem pressure measured. 0.02 inch leak
pressure standard is measured at the start
and at the end of the leak check.
If stabilized pressure larger than second
0.02 inch leak pressure, ECM determines
that EVAP system has small leakage.
Same above
While
ignition
switch
OFF
2 trip
CIRCUIT DESCRIPTION
The circuit description can be found in the EVAP (Evaporative Emission) Inspection Procedure (see page
DI±460).
DID8A±01
Page 476 of 4323

B17399
Fuel Tank Canister
Vacuum Pump: OFF Pressure Sensor 0.02 Inch Orifice
Pump Module
Operation A: Atmospheric Pressure Measurement
Vent Valve: OFF (vent)
Operation D: Purge VSV monitor Operation B: 0.02 Inch Leak Pressure Measurement
Negative
Pressure Atmospheric
Pressure
Operation C: EVAP Leak Check
Air Filter
Purge VSV: OFFOFF (vent)
ON
OFF
OFF
ON
ON (closed)ON
ON
ON (closed)
DI±274
± DIAGNOSTICSENGINE
468 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR DESCRIPTION
5 hours* after the ignition switch is turned OFF, the electric vacuum pump creates negative pressure (vacu-
um) in the EVAP (Evaporative Emission) system. The ECM monitors for leaks and actuator malfunctions
based on the EVAP pressure.
HINT:
*: If the engine coolant temperature is not below 35C (95F) 5 hours after the ignition switch is turned off,
the monitor check starts 2 hours later. If it is still not below 35C (95F) 7 hours after the ignition switch is
turned off, the monitor check starts 2.5 hours later.
SequenceOperationsDescriptionsDuration
±ECM activationActivated by soak timer, 5 hours (7 or 9.5 hours) after ignition switch turned to OFF.±
AAtmospheric pressure
measurement
Vent valve turned OFF (vent) and EVAP system pressure measured by ECM in order to
register atmospheric pressure.
If EVAP pressure is not between 70 kPa and 110 kPa (525 mmHg and 825 mmHg), ECM
cancels EVAP system monitor.
10 seconds
B
First 0.02 inch leak
pressure measure-
mentIn order to determine 0.02 inch leak pressure standard, vacuum pump creates negative pres-
sure (vacuum) through 0.02 inch orifice and them ECM checks if vacuum pump and vent
valve operate normally.
60 seconds
CEVAP system pres-
sure measurement
Vent valve turned ON (closed) to shut EVAP system.
Negative pressure (vacuum) created in EVAP system, and EVAP system pressure then
measured.
Write down the measured value as it will be used in the leak check.
If EVAP pressure does not stabilize within 15 minutes, ECM cancels EVAP system monitor.
15 minutes*
DPurge VSV monitorPurge VSV opened and then EVAP system pressure measured by ECM.
Large increase indicates normal.10 seconds
E
Second 0.02 inch leak
pressure measure-
mentLeak check is performed after second 0.02 inch leak pressure standard is measured.
If stabilized system pressure higher than second 0.02 inch leak pressure standard, ECM
determines that EVAP system leaking.
60 seconds
FFinal checkAtmospheric pressure measured and then monitoring result recorded by ECM.±
* If only a small amount of fuel is in the fuel tank, it takes longer for the EVAP pressure to stabilize.
Page 477 of 4323

A23486
Purge VSV
Vent Valve
Vacuum Pump
EVAP Pressure
Positive
Leak Pressure
sec NegativeONON
Sequence
TimeA
10
sec60
Within 15 minutes
sec ON
First 0.02 inch
BCD
P0455
ON: Open
OFF: Closed
OFF: Vent ON: Closed
10
Standard
sec60
E
P0456
OK
EVAP Pressure when EVAP system Leaks:
Leak PressureSecond 0.02 inch
Standard x 0.2
± DIAGNOSTICSENGINE
DI±275
469 Author: Date:
2005 SEQUOIA (RM1146U)
(a) P0455: EVAP (Evaporative Emission) gross leak
In operation C, the vacuum pump creates negative pressure (vacuum) in the EVAP system and the EVAP
system pressure is measured. If the stabilized system pressure is higher than [second 0.02 inch leak pres-
sure standard x 0.2] (near atmospheric pressure), the ECM determines that the EVAP system has a large
leakage, illuminates the MIL and sets the DTC (2 trip detection logic).
(b) P0456: EVAP very small leak
In operation C, the vacuum pump creates negative pressure (vacuum) in the EVAP system and the EVAP
system pressure is measured. If the stabilized system pressure is higher than second 0.02 inch leak pres-
sure standard, the ECM determines that the EVAP system has a small leakage, illuminates the MIL and sets
the DTC (2 trip detection logic).
MONITOR STRATEGY
RltdDTCP0455Gross leak detectedRelated DTCsP0456Very small leak (0.020 inch hole) detected
Required sensors/componentsPurge VSV, Pump module
Frequency of operationOnce per driving cycles
DurationWithin 15 min. (varies with amount of fuel in tank)
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page DI±18
Following values are when atmospheric is
760 mmHg (100 kPa)±
EVAP key±off monitor runs when all of the
following conditions met:±
Page 478 of 4323

DI±276
± DIAGNOSTICSENGINE
470 Author: Date:
2005 SEQUOIA (RM1146U) Atmospheric pressure
525 to 825 mmHg (70 to 110 kPa)
Battery voltage10.5 V±
Vehicle speed±4 km/h (2.5 mph)
Ignition switchOFF
Engine conditionNot running
Time after engine stopped5 hours
FTP sensor malfunction (P0450, P0452,
P0453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions are met
before IG switch OFFCondition 1 and 2
1. Duration that vehicle is driven5 min.±
2. Purge flowExecuted
ECT4.4 to 35°C (40 to 95°F)
IAT4.4 to 35°C (40 to 95°F)
Example of re±start time±
First time7 hours
Second time9 hours and 30 min.
Key±off monitor sequence1 to 8
1. Atmospheric pressure±
Next sequence is run if following condition
set±
Atmospheric pressure change for 10 sec.±2.25 mmHg (0.3 kPa) for 1 sec.
2. First reference pressure±
Next sequence is run if all of following
conditions setCondition 1, 2 and 3
1. FTP when 4 sec. after reference pres-
sure measurement±±7.5 mmHg (±1 kPa)
2. Reference pressure±36.38 to ±7.93 mmHg (±4.85 to ±1.057 kPa)
3. Reference pressureSaturated
3. Vent valve stuck closed check±
Next sequence is run if following condition
set±
FTP change for 10 sec. after vent valve
ON (closed)2.25 mmHg (0.3 kPa)±
4. Vacuum introduction and leak±
Next sequence is run if both of following
conditions setCondition 1 and 2
1. Vacuum introduction time±15 min.
2. FTPFTP was saturated
5. Purge VSV stuck closed check±
Next sequence is run if following condition
set±
FTP change for 10 sec. after purge VSV
ON (open)2.25 mmHg (0.3 kPa)±
Page 479 of 4323

± DIAGNOSTICSENGINE
DI±277
471 Author: Date:
2005 SEQUOIA (RM1146U) 6. Second reference pressure measure-
ment
±
Next sequence is run if all of following
conditions setCondition 1, 2, 3 and 4
1. FTP when 4 sec. after reference pres-
sure measurement±±7.5 mmHg (±1 kPa)
2. Reference pressure±36.38 to ±7.93 mmHg (±4.85 to ±1.057 kPa)
3. Reference pressureSaturated
4. Reference pressure difference between
first and second±5.25 mmHg (0.7 kPa)
7. Leak check±
Next sequence is run if following condition
set±
FTP when vacuum introduction was com-
plete±Second reference pressure
8. Atmospheric pressure±
Monitor is complete if following±
Atmospheric pressure difference between
sequence 1 and 8±2.25 mmHg (0.3 kPa)
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Small leak (0.020 inch) malfunction detection:
FTP when vacuum introduction was compleatBetween 1 and 2
Condition 1.Higher than second reference pressure
Condition 2.Lower than reference pressure x 0.2
Gross leak detection:
FTP when vacuum introduction was compleatHigher than reference pressure x 0.2
MONITOR RESULT (MODE 06 DATA)
Refer to page DI±26 for detailed information on Monitor Result.
INSPECTION PROCEDURE
Refer to the EVAP Inspection Procedure (see page DI±460).
Page 480 of 4323

P22487
Vehicle Speed
SensorCombination
MeterECM 4±pulse 4±pulse DI±278
± DIAGNOSTICSENGINE
472 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P0500 Vehicle Speed Sensor ºAº
DTC P0503 Vehicle Speed Sensor ºAº Intermittent/
Erratic/High
CIRCUIT DESCRIPTION
The No.1 vehicle speed sensor outputs a 4±pulse signal for every revolution of the rotor shaft, which is ro-
tated by the transmission output shaft via the driven gear. After this signal is converted into a more precise
rectangular waveform by the waveform shaping circuit inside the combination meter, it is then transmitted
to the ECM. The ECM determines the vehicle speed based on the frequency of these pulse signals.
DTC No.Proceed toDTC Detection ConditionTrouble Area
P0500Step 1
No vehicle speed sensor sig-
nal to ECM under following
conditions: (2 trip detection
logic)
Vehicle is being driven
Combination meter
Open or short in vehicle speed sensor circuit
Vehicle speed sensor
ECM
P0503DI±11Intermittent problem in the ve-
hicle speed sensor circuitECM
MONITOR DESCRIPTION
The ECM assumes that the vehicle is driven when the park/neutral position switch is OFF and it has been
over 4 sec. since the actual vehicle speed was 9 km/h (6 mph) or more.
If there is no signal from the vehicle speed sensor when these conditions are satisfied, the ECM concludes
that there is a fault in the vehicle speed sensor. The ECM will turn on the MIL and a DTC is set.
DID8B±01
