SA143±10
F14316
N´m (kgf´cm, ft´lbf) : Specified torque
Non±reusable part
64 (650, 47)
Brake CaliperHub Bolt Cotter Pin
105 (1,100, 77)
8.0 (82, 71 in.´lbf)
Speed Sensor
Shock Absorber
135 (1,400, 100)
65 (663, 48)
123 (1,250, 90)
28 (285, 21)Steering Knuckle with Axle Hub
Disc
4WD:
Cotter Pin
235 (2,400, 173)
Lock Cap
Grease Cap
Grease Cap2WD:
4WD:
Oil Seal
Speed Sensor
Rotor
Dust Cover
Steering Knuckle
18 (185, 13)
Oil Seal Bearing
Snap Ring
Axle Hub
Bearing Spacer4WD:
274 (2,800, 203)
Lock Nut 2WD:
± SUSPENSION AND AXLEFRONT AXLE HUB
SA±21
3017 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT AXLE HUB
COMPONENTS
Page 3026 of 4323
SA23I±04
R13426
F07263
F07264
F07265
SA±22
± SUSPENSION AND AXLEFRONT AXLE HUB
3018 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE FRONT WHEEL
2. REMOVE GREASE CAP
Using a screwdriver and hammer, remove the grease cap.
3. 4WD:
DISCONNECT DRIVE SHAFT
(a) Remove the cotter pin and lock cap.
(b) While applying the brakes, remove the lock nut.
4. DISCONNECT SPEED SENSOR AND WIRE HARNESS
CLAMP FROM STEERING KNUCKLE
Remove the 2 bolts and disconnect the speed sensor and wire
harness clamp from the steering knuckle.
5. REMOVE BRAKE CALIPER AND DISC
(a) Remove the bolt and brake line clamp from the steering
knuckle.
(b) Remove the 2 bolts, brake caliper and disc.
NOTICE:
Do not damage the brake tube.
(c) Support the brake caliper securely.
6. REMOVE SHOCK ABSORBER (See page SA±64)
7. DISCONNECT LOWER BALL JOINT
Remove the 4 bolts and disconnect the lower ball joint.
8. REMOVE STEERING KNUCKLE
(a) Remove the cotter pin and loosen the nut.
Page 3027 of 4323
R13196
SST
± SUSPENSION AND AXLEFRONT AXLE HUB
SA±23
3019 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Using SST, disconnect the steering knuckle.
SST 09950±40011 (09951±04010, 09952±04010,
09553±04020, 09554±04010, 09955±04031,
09958±04011)
(c) Remove the nut and steering knuckle.
NOTICE:
4WD:
Be careful not to damage the oil seal and drive shaft boot.
HINT:
4WD:
When it is difficult to disconnect the drive shaft, tap the tip of the
drive shaft with a plastic hammer.
Page 3028 of 4323

SA145±08
R13215
SST
R13275
SST
SST SA±24
± SUSPENSION AND AXLEFRONT AXLE HUB
3020 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. 2WD:
REMOVE GREASE CAP
(a) Mount the axle hub in a soft jaw vise.
HINT:
Close the vise until it holds hub bolts. Do not tighten further.
(b) Using a screwdriver, remove the grease cap.
2. 4WD:
REMOVE OIL SEAL (INSIDE)
(a) Mount the axle hub in a soft jaw vise.
HINT:
Close the vise until it holds hub bolts. Do not tighten further.
(b) Using a screwdriver, remove the oil seal (inside).
3. 2WD:
REMOVE LOCK NUT AND SPEED SENSOR ROTOR
(a) Using a chisel and hammer, loosen the staked part of the
lock nut.
NOTICE:
Be careful not to damage the bushing.
(b) Using SST, remove the lock nut.
SST 09318±12010
(c) Remove the speed sensor rotor.
NOTICE:
Take care not to scratch the serration of the speed sensor
rotor.
4. REMOVE AXLE HUB FROM STEERING KNUCKLE
(a) Remove the 4 bolts and shift the dust cover towards the
hub side (outside).
(b) Using SST, remove the axle hub from the steering
knuckle.
SST 09710±30021 (09710±03051),
09950±40011 (09951±04020, 09952±04010,
09953±04020, 09954±04010, 09955±04031,
09957±04010, 09958±04011)
(c) Remove the dust cover from the steering knuckle.
(d) 4WD:
Remove the bearing spacer and speed sensor rotor.
NOTICE:
Take care not to scratch the serration of the speed sensor
rotor.
5. REMOVE OIL SEAL (OUTSIDE)
Using a screwdriver, remove the oil seal (outside) from the
steering knuckle.
6. REMOVE BEARING FROM STEERING KNUCKLE
(a) Using snap ring pliers, remove the snap ring.
Page 3029 of 4323
R13276
SST
± SUSPENSION AND AXLEFRONT AXLE HUB
SA±25
3021 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Using SST and a press, remove the bearing from the
steering knuckle.
SST 09950±60020 (09951±00810),
09950±70010 (09951±07150)
Page 3030 of 4323

SA146±08
R13277
SST
SST
R13278
SST
SST
R13279
SST
R13215
SST
R13418
SST SA±26
± SUSPENSION AND AXLEFRONT AXLE HUB
3022 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
1. INSTALL NEW BEARING
(a) Using SST and a press, install a new bearing to the steer-
ing knuckle.
SST 09527±17011, 09950±60020 (09951±00910)
(b) Using snap ring pliers, install a new snap ring.
2. INSTALL NEW OIL SEAL (OUTSIDE)
(a) Using SST and a plastic hammer, install a new oil seal
(outside).
SST 09223±15030, 09527±17011
(b) Coat MP grease to the oil seal lip.
3. INSTALL AXLE HUB TO STEERING KNUCKLE
(a) Install the dust cover to the steering knuckle with the 4
bolts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(b) Using SST and a press, install the axle hub to the steering
knuckle.
SST 09649±17010
4. INSTALL SPEED SENSOR ROTOR
NOTICE:
Do not scratch the serration of the speed sensor rotor.
5. 2WD:
INSTALL NEW LOCK NUT
(a) Using SST, install and torque a new lock nut to the axle
hub.
SST 09318±12010
Torque: 274 N´m (2,800 kgf´cm, 203 ft´lbf)
(b) Using a chisel and hammer, stake the lock nut.
6. 4WD:
INSTALL BEARING SPACER
Using SST and a press, install the bearing spacer.
SST 09950±60010 (09951±00650),
09950±70010 (09951±07150)
7. 2WD:
INSTALL GREASE CAP
Page 3031 of 4323
R13280
SST
± SUSPENSION AND AXLEFRONT AXLE HUB
SA±27
3023 Author: Date:
2005 SEQUOIA (RM1146U)
8. 4WD:
INSTALL NEW OIL SEAL (INSIDE)
(a) Using SST and a plastic hammer, install a new oil seal (in-
side).
SST 09527±17011
HINT:
Lightly strike the SST on its circumference evenly.
(b) Coat MP grease to the oil seal lip.
Page 3032 of 4323

SA23J±05
SA±28
± SUSPENSION AND AXLEFRONT AXLE HUB
3024 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL STEERING KNUCKLE
(a) 4WD:
Insert the drive shaft into the axle hub and temporarily tighten the nut.
NOTICE:
Be careful not to damage the oil seal and drive shaft boot.
(b) Connect the steering knuckle to the upper suspension arm.
(c) Install the nut and a new cotter pin.
If the holes for the cotter pin are not aligned, tighten the nut further up to 60°.
Torque: 105 N´m (1,100 kgf´cm, 77 ft´lbf)
2. CONNECT LOWER BALL JOINT
Connect the lower ball joint to the steering knuckle with the 4 bolts.
Torque: 65 N´m (663 kgf´cm, 48 ft´lbf)
3. INSTALL SHOCK ABSORBER (See page SA±70)
4. INSTALL BRAKE CALIPER
(a) Install the disc, brake caliper and 2 bolts.
Torque: 123 N´m (1,250 kgf´cm, 90 ft´lbf)
(b) Install the brake line clamp to the steering knuckle with the bolt.
Torque: 28 N´m (285 kgf´cm, 21 ft´lbf)
5. CONNECT SPEED SENSOR AND WIRE HARNESS CLAMP
Connect the speed sensor and wire harness clamp to the steering knuckle with the 2 bolts.
Torque: 8.0 N´m (82 kgf´cm, 71 ft´lbf)
6. 4WD:
INSTALL DRIVE SHAFT LOCK NUT
(a) While applying the brakes, tighten the nut.
Torque: 235 N´m (2,400 kgf´cm, 173 ft´lbf)
(b) Install the lock cap and a new cotter pin.
If the holes for the cotter pin are not aligned, tighten the nut further up to 60°.
7. INSTALL GREASE CAP
8. INSTALL FRONT WHEEL
Torque: 110 N´m (1,150 kgf´cm, 83 ft´lbf)
9. DEPRESS BRAKE PEDAL SEVERAL TIMES
10. CHECK FRONT WHEEL ALIGNMENT (See page SA±4)
11. CHECK SPEED SENSOR SIGNAL (See page DI±899)
12. PERFORM ZERO POINT CALIBRATION OF STEERING ANGLE, MASTER CYLINDER PRES-
SURE, YAW RATE AND DECELERATION SENSORS (See page DI±897)
