CIRCUIT DESCRIPTION
The ATF (Automatic Transmission Fluid) temperature sensor
converts the fluid temperature into a resistance value which is
input into the ECM.
The ECM applies a voltage to the temperature sensor through
ECM terminal THO1.
The sensor resistance changes with the transmission fluid tem-
perature. As the temperature becomes higher, the sensor resis-
tance decreases.
One terminal of the sensor is grounded so that the sensor resis-
tance decreases and the voltage goes down as the tempera-
ture becomes higher.
The ECM calculates the fluid temperature based on the voltage
signal.
DTC No.DTC Detection ConditionTrouble Area
P0710
(a) and (b) are detected momentarily within 0.5 sec. when
neither P0712 nor P0713 is detected (1±trip detection logic)
(a) ATF temperature sensor No.1 resistance is less than 79 W.
(b) ATF temperature sensor No.1 resistance is more than 156
kW.
HINT:
Within 0.5 sec., the malfunction switches from (a) to (b) or from
(b) to (a)
Open or short in ATF temperature sensor No.1 circuit
Transmission wire (ATF temperature sensor No.1)
ECM
P0712ATF temperature sensor No.1 resistance is less than 79 W for
0.5 sec. or more (1±trip detection logic)Short in ATF temperature sensor No.1 circuit
Transmission wire (ATF temperature sensor No.1)
ECM
P0713
ATF temperature No.1 sensor resistance is more than 156 kW
when 15 minutes or more have elapsed after the engine start
DTC is detected for 0.5 sec. or more (1±trip detection logic)Open in ATF temperature sensor No.1 circuit
Transmission wire (ATF temperature sensor No.1)
ECM
MONITOR DESCRIPTION
These DTCs indicate an open or short in the automatic transmission fluid (ATF) temperature sensor circuit.
The automatic transmission fluid (ATF) temperature sensor converts ATF temperature to an electrical resis-
tance value. Based on the resistance, the ECM determines the ATF temperature, and the ECM detects an
open or short in the ATF temperature circuit. If the resistance value of the ATF temperature is less than 79W
*1
or more than 156kW*2, the ECM interprets this as a fault in the ATF sensor or wiring. The ECM will turn on
the MIL and store the DTC.
*1: 150C (302F) or more is indicated regardless of the actual ATF temperature.
*2: ±40C (±40F) is indicated regardless of the actual ATF temperature.
HINT:
The ATF temperature can be checked on the OBD II scan tool or hand±held tester display.
Page 786 of 4323

DI±584
± DIAGNOSTICSAUTOMATIC TRANSMISSION
778 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR STRATEGY
P0710ATF temperature sensor/Range check (Fluttering)
Related DTCsP0712ATF temperature sensor/Range check (Low resistance)Related DTCs
P0713ATF temperature sensor/Range check (High resistance)
Required sensors/ComponentsATF temperature sensor (TFT sensor)
Frequency of operationContinuous
Duration0.5 sec.
MIL operationImmediate
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not present.See page DI±545
Range check (Fluttering, Low resistance)
The typical enabling condition is not avail-
able.±
Range check (High resistance)
Time after engine start15 min. or more±
TYPICAL MALFUNCTION THRESHOLDS
Detection criteriaThreshold
Range check (Fluttering)
TFT (transmission fluid temperature) sensor resistance
Less than 79 W
or
More than 156 kW
Range check (Low resistance)
TFT (transmission fluid temperature) sensor resistanceLess than 79 W
Range check (High resistance)
TFT (transmission fluid temperature) sensor resistanceMore than 156 kW
COMPONENT OPERATING RANGE
ParameterStandard value
TFT (transmission fluid temperature) sensorAtmospheric temperature to approx. 130°C (266°F)
Page 787 of 4323

D14157
O E1 Electronically Controlled
Transmission Solenoid
OT±O
OT+
L
OT2±L
OT2+ G±W
G±W
G±WG
B±L
G±W 2
110
9E7
E7
E828 32 24
THO2 THO1
E2ECM
± DIAGNOSTICSAUTOMATIC TRANSMISSION
DI±585
779 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
According to the DATA LIST displayed by the OBD II scan tool or hand±held tester, you can read the value
of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of
troubleshooting is one method to shorten labor time.
(a) Warm up the engine.
(b) Turn the ignition switch off.
(c) Connect the OBD II scan tool or hand±held tester to the DLC3.
(d) Turn the ignition switch to the ON position.
(e) Push the ºONº button of the OBD II scan tool or the hand±held tester.
(f) When you use the hand±held tester:
Select the item ºDIAGNOSIS / ENHANCED OBD II / DATA LISTº.
(g) According to the display on the tester, read the ºDATA LISTº.
ItemMeasurement Item/
Range (display)Normal Condition
AT FLUID TEMP 1
ATF Temp. Sensor Value/
min.: ±40C (±40F)
max.: 215C (419F)After Stall Test;
Approx. 80C (176F)
Equal to ambient temperature when cold soak
HINT:
When DTC P0712 is output and hand±held tester output is 150C (302F) or more, there is a short circuit.
When DTC P0713 is output and hand±held tester output is ±40C (±40F), there is an open circuit.
Measure the resistance between terminal THO1 (OT) and body ground.
Temperature DisplayedMalfunction
±40°C (±40°F)Open circuit
150°C (302°F) or moreShort circuit
HINT:
If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 second).
When P0713 is set, P0711 cannot be detected.
It is not necessary to inspect the circuit when P0711 is set.
Page 788 of 4323
1
152 3 4 5 6 7 8
9 10 11 12
13 14
D11994OT+OT±
E1
Transmission Wire Side:
(Connector Front View):
DI±586
± DIAGNOSTICSAUTOMATIC TRANSMISSION
780 Author: Date:
2005 SEQUOIA (RM1146U)
1 Inspect transmission wire (ATF temperature sensor No.1).
PREPARATION:
Disconnect the transmission wire connector from the transmis-
sion.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionSpecified Condition
2 (OT±) ± 10 (OT+)79 W to 156 kW
2 (OT±) ± Body ground10 kW or higher
10 (OT+) ± Body ground10 kW or higher
HINT:
If the resistance is out of the specified range with either the ATF
temperature shown in the table below, the driveability of the ve-
hicle may decrease.
ATF TemperatureSpecified Condition
20°C (68°F)3 to 4 kW
110°C (230°F)0.22 to 0.28 kW
NG Repair or replace the transmission wire
(ATF temperature sensor No.1)
(See page AT±7).
OK
Page 789 of 4323
D14161
E8E7E6E5E4ECM:
THO1
E2
± DIAGNOSTICSAUTOMATIC TRANSMISSION
DI±587
781 Author: Date:
2005 SEQUOIA (RM1146U)
2 Check harness and connector (Transmission wire ± ECM).
PREPARATION:
(a) Connect the transmission wire connector.
(b) Disconnect the connector of the ECM.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionSpecified Condition
E7 ± 24 (THO1) ± E8 ± 28 (E2)79 W to 156 kW
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionSpecified Condition
E7 ± 24 (THO1) ± Body ground10 kW or higher
E8 ± 28 (E2) ± Body ground=
NG Repair or replace the harness or connector
(See page IN±35).
OK
Replace the ECM (See page SF±80).
Page 790 of 4323

DI±588
± DIAGNOSTICSAUTOMATIC TRANSMISSION
782 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P0711 Transmission Fluid Temperature Sensor ºAº
Performance
CIRCUIT DESCRIPTION
See page DI±582.
DTC No.DTC Detection ConditionTrouble Area
P0711
Both (a) and (b) are detected: (2±trip detection logic)
(a) Intake air and engine coolant temps. are more than ±20°C
(±4F) at engine start
(b) After normal driving for over 22 min. and 9 km (6 mile) or
more, ATF temp. is less than 10°C (50F)
Transmission wire (ATF temperature sensor No.1)
MONITOR DESCRIPTION
This DTC indicates that there is a problem with output from the automatic transmission fluid (ATF) tempera-
ture sensor and that the sensor itself is defective. The ATF temperature sensor converts the ATF tempera-
ture to an electrical resistance value. Based on the resistance, the ECM determines the ATF temperature
and detects an open or short in the ATF temperature circuit or a fault in the ATF temperature sensor.
After running the vehicle for a certain period, the ATF temperature should increase. If the ATF temperature
is below 20C (68F) after running the vehicle for a certain period, the ECM interprets this as a fault, and
turns on the MIL.
MONITOR STRATEGY
Related DTCsP0711ATF temperature sensor/Rationality check
Required sensors/ComponentsATF temperature sensor (TFT sensor)
Frequency of operationContinuous
Duration3 sec.
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever this DTC is
not present.See page DI±545
TFT (transmission fluid temperature) sen-
sor circuitNot circuit malfunction
ECT (Engine coolant temperature) sensor
circuitNot circuit malfunction
IAT (Intake air temperature) sensor circuitNot circuit malfunction
Time after engine start21 min. and 40 sec.
Driving distance after engine start9 km (5.6 mile) or more±
IAT (12 sec. after engine start)±10°C (14°F) or more±
ECT (12 sec. after engine start)±10°C (14°F) or more±
DIDJ7±01
Page 791 of 4323

± DIAGNOSTICSAUTOMATIC TRANSMISSION
DI±589
783 Author: Date:
2005 SEQUOIA (RM1146U)
TYPICAL MALFUNCTION THRESHOLDS
Detection criteriaThreshold
TFT (transmission fluid temperature)Less than 20°C (68°F)
(varies with TFT (transmission fluid temperature) at engine start)
WIRING DIAGRAM
See page DI±582.
INSPECTION PROCEDURE
HINT:
According to the DATA LIST displayed by the OBD II scan tool or hand±held tester, you can read the value
of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of
troubleshooting is one method to shorten labor time.
(a) Warm up the engine.
(b) Turn the ignition switch off.
(c) Connect the OBD II scan tool or hand±held tester to the DLC3.
(d) Turn the ignition switch to the ON position.
(e) Push the ºONº button of the OBD II scan tool or the hand±held tester.
(f) When you use the hand±held tester:
Select the item ºDIAGNOSIS / ENHANCED OBD II / DATA LISTº.
(g) According to the display on the tester, read the ºDATA LISTº.
ItemMeasurement Item/
Range (display)Normal Condition
AT FLUID TEMP 1
ATF Temp. Sensor Value/
min.: ±40C (±40F)
max.: 215C (419F)After Stall Test;
Approx. 80C (176F)
Equal to ambient temperature when cold soak
HINT:
When DTC P0712 is output and hand±held tester output is 150C (302F) or more, there is a short circuit.
When DTC P0713 is output and hand±held tester output is ±40C (±40F), there is an open circuit.
Measure the resistance between terminal THO1 (OT) and body ground.
Temperature DisplayedMalfunction
±40°C (±40°F)Open circuit
150°C (302°F) or moreShort circuit
HINT:
If a circuit related to the ATF temperature sensor becomes open, P0713 is immediately set (in 0.5 second).
When P0713 is set, P0711 cannot be detected.
It is not necessary to inspect the circuit when P0711 is set.
Page 792 of 4323
DI±590
± DIAGNOSTICSAUTOMATIC TRANSMISSION
784 Author: Date:
2005 SEQUOIA (RM1146U)
1 Check other DTCs output (in addition to DTC P0711).
PREPARATION:
(a) Turn the ignition switch off.
(b) Connect the OBD II scan tool or hand±held tester to the DLC3.
(c) Turn the ignition switch to the ON position.
(d) Turn on the tester.
(e) Select the item ºDIAGNOSIS / ENHANCED OBD II / DTC INFO / CURRENT CODESº.
CHECK:
Read the DTCs using the OBD II scan tool or the hand±held tester.
RESULT:
Display (DTC output)Proceed to
Only ºP0711º is outputA
ºP0711º and other DTCsB
HINT:
If any other codes besides ºP0711º are output, perform troubleshooting for those DTCs first.
B Go to DTC chart (See page DI±573).
A
2 Check transmission fluid level (See page DI±524).
OK:
Automatic transmission fluid level is correct.
NG Add fluid
(See page DI±524).
OK
Replace the transmission wire (ATF tempera-
ture sensor) (See page AT±7).
