Page 1249 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±1047 1241 Author: Date: 2005 SEQUOIA (RM1146U) 5 Check SLIP indicator light. See combination meter troubleshooting on page DI±1614. NG Repa

Page 1250 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI±1048 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1242 Author: Date: 2005 SEQUOIA (RM1146U) VSC OFF *1 (TRAC OFF)*2 Indicator Light, Center Diff. Lock *1 (TRAC OFF)*2 Switch Circuit *1:

Page 1251 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19780 ABS & VSC Actuator (Skid Control ECU) Translate ECU CANH CANL IG1 VSC± VSC+ IG17 T5 11 T5 1 T56 S1 2 S1 13 S1 7 IL2 6 IL2 1 IL2 A J38 A J37 A J37 8 3C8 3A L W B±RL W B±R B±R B±R B±R B±R

Page 1252 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F13991 GNDCSW*1 Center Integration Panel Assembly CSW *2 C3C6 DI±1050 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1244 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION PROCEDURE HINT: Star

Page 1253 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±1051 1245 Author: Date: 2005 SEQUOIA (RM1146U) 3 Check for open and short circuit in harness and connector between terminal CSW of the trans

Page 1254 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F19781 Translate ECU O J43 J/C O A A 8 5 BF10 Fusible Link Block ALTW±B 40 T5 GND A A J18 J/CW±B W±B W±B IL11 S1 32 S1 9 IL1GND1 GND2 Battery IGIGABS & VSC Actuator (Skid Control ECU) VSC+ VSC

Page 1255 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM DI±1053 1247 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION PROCEDURE HINT: Start the inspection from step 1 when using the hand±held tester

Page 1256 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F02192 2 1 (+) (±) DI±1054 ± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM 1248 Author: Date: 2005 SEQUOIA (RM1146U) 3 Check VSC buzzer. PREPARATION: Disconnect the VSC buzzer connector. CH
