2001 TOYOTA SEQUOIA Service Repair Manual

radiator cap headlights maintenance schedule coolant spark plugs replace wiring diagram

Load previous 8 pages

Page 1745 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A08841
Hand±held Tester
DLC3
DIDEZ±01
A04550
DLC3 1 2345678
9
10 11 12 1314 15 16
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1543
1737 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSIS SYSTEM
1. DESCR

Page 1746 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual I11929
CRUISE Main
Indicator Light
BE4034
Indicator Light
1.5 secs.0.5 secs.
ON
OFF DI±1544
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1738 Author: Date:
2005 SEQUOIA (RM1146U)
3. CHECK THE INDICATOR
(

Page 1747 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDF0±01
A04550
TC CG
1 2345678
9
10 11 12 1314 15 16
I11929
CRUISE Main
Indicator Light
I28693
Normal System Code:
ON
OFF
Code 52
Code 21 0.25 sec.
0.25 sec.
ON
OFFDiagnostic Trouble Code:
4.5 sec

Page 1748 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual A08841DLC3
Hand±held Tester
DI±1546
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1740 Author: Date:
2005 SEQUOIA (RM1146U)
3. DTC CHECK (USING HAND±HELD TESTER)
(a) Connect the hand±held tester to the

Page 1749 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDF1±01
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1547
1741 Author: Date:
2005 SEQUOIA (RM1146U)
FAIL±SAFE CHART
If the following condition is detected while the cruise control is in operation, t

Page 1750 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DIDF2±01
A08841DLC3
Hand±held Tester
DI±1548
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1742 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
DATA LIST
HINT:
According to the DATA LIST dis

DIDF2±01
A08841DLC3
Hand±held Tester
DI±1548
± DIAGNOSTICSCRUISE CONTROL SYSTEM
1742 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
DATA LIST
HINT:
According to the DATA LIST displayed by the the hand±held
tester, you can read the values of the switches, the sensors and
so on without parts removal. Reading the DATA LIST as a first
step in troubleshooting is one of the methods to shorten labor
time.
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
(c) According to the display on the tester, read the ºDATA
LISTº.
CCS (ECM):
ItemMeasurement Item
/Display (Range)Normal ConditionDiagnostic Note
VEHICLE SPDVehicle speed/min.: 0 km/h (0
mph), max.: 255 km/h (158 mph)Actual vehicle speed±
MEMORY SPD
Cruise control memorized speed
/min.: 36 km/h (22.5 mph), max.:
200 km/h (125 mph)
Actual stored vehicle speed±
THROTTLERequired throttle opening angle
/min.: 0, max.: 125Actual required throttle opening
angle±
CRUISE CONTROLCruise control system active
condition/ON or OFFON: Cruise control activated
OFF: Cruise control inactivated±
MAIN SW (MAIN)Main SW signal (Main CPU)
/ON or OFFON: Main SW ON (Pushed on)
OFF: Main SW OFF (Pushed off)±
MAIN SW (SUB)Main SW signal (Sub CPU)
/ON or OFFON: Main SW ON (Pushed on)
OFF: Main SW OFF (Pushed off)±
CCS INDICATORCruise indicator signal (Main CPU)
/ON or OFFON: ºCRUISE main indicatorº ON
OFF: ºCRUISE main indicatorº
OFF
±
CCS INDICATOR SCruise indicator signal (Sub CPU)
/ON or OFFON: ºCRUISE main indicatorº ON
OFF: ºCRUISE main indicatorº
OFF
±
CANCEL SWCANCEL SW signal/ON or OFFON: CANCEL SW ON
OFF: CANCEL SW OFF±
SET/COAST SW±/SET SW signal/
ON or OFFON: ±/SET SW ON
OFF: ±SET OFF±
RES/ACC SW+/RES SW signal/ON or OFFON: +/RES SW ON
OFF: +/RES SW OFF±
STP LIGHT SW2 MStop light SW signal (Main CPU)
/ON or OFFON: Brake pedal depressed
OFF: Brake pedal released±
STP LIGHT SW2 SStop light SW signal (Sub CPU)
/ON or OFFON: Brake pedal depressed
OFF: Brake pedal released±
STP LIGHT SW1 SStop light SW signal (Sub CPU)
/ON or OFFON: Brake pedal depressed
OFF: Brake pedal released±
SHIFT D POSPNP SW signal (D position)
/ON or OFFON: Shift position D
OFF: Any shift position except D±

Page 1751 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI26U±39
± DIAGNOSTICSCRUISE CONTROL SYSTEM
DI±1549
1743 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
If a trouble code is displayed during the DTC check, check the circui

Page 1752 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual DI3CG±10
I28396
DLC3
Instrument Panel J/B
Ignition SwitchECM Cruise Control Switch
Stop Light Switch
STOP Fuse
IGN1 Fuse
AM1 Fuse
GAUGE FuseCombination Meter
CRUISE Main Indicator Light
Spi
