Page 2177 of 4323
± DIAGNOSTICSAUDIO SYSTEM
DI±1975
2169 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Service Check Mode Result Display (for checking the current and the past system conditions).
(1) Press the ºSEEK TRACKº switch to see the check result of each component.
I28309
The illustration shows the case that the system has 2 devices with codes 190 and 360, and the device (code
360) has a trouble.
The check result is displayed in ascending order of device code. The device code is displayed first, and then
the check result.P±±±indicates physical address
190±±±physical address
good±±±ºThe component is normalº.
P±±±indicates physical address
360±±±physical address
CHEC±±±ºCheck neededº.
: TUNE/TRACK UP
: TUNE/TRACK DOWN
Page 2178 of 4323

DI±1976
± DIAGNOSTICSAUDIO SYSTEM
2170 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Check Result Display.
DisplayOriginal LanguageMeaningAction to be taken
goodGood (normal)No DTCs are detected in both ºSystem Check Modeº and
ºDiagnostic Memory Modeº.±
NCONNo connection
The system recognized the component when it was regis-
tered, but the component gives no response to the ºDiagnos-
tic Mode ON Requestº.
Check the power source cir-
cuit and the communication
circuit of the component indi-
cated by the component
code (physical address).
ECHNExchangeOne or more DTCs for ºExchangeº are detected in either
ºSystem Check Modeº or ºDiagnostic Memory Modeº.
Go to the detailed informa-
tion mode to check the
trouble area referring to the
DTC list.
CHECCheck
When no DTCs are detected for ºExchangeº, one or more
DTCs for ºCheckº are detected in either ºSystem Check
Modeº or ºDiagnostic Memory Modeº.Go to the detailed informa-
tion mode to check the
trouble area referring to the
DTC list.
OLDOld versionOld DTC application is identified and DTC is detected in ei-
ther ºSystem Check Modeº or ºDiagnostic Memory Modeº.±
NRESNo response
The device gives no response to any one of ºSystem Check
Mode ON Requestº, ºSystem Check Result Requestº and
ºDiagnostic Memory Requestº.
Check the power source cir-
cuit and the communication
circuit of the component indi-
cated by the component
code (physical address).
(3) To perform the Service Check again, press the preset switch º1º.
(e) Detailed Information Mode (when displaying the DTC for a trouble component)
(1) With ºCHECº or ºECHNº being displayed, press the preset switch º2º to go to the detailed informa-
tion mode.
(2) Press the ºSEEK TRACKº switch to display the ºSystem Check Result (SYS)º and ºDiagnostic
Memory Response (CODE)º.
Page 2179 of 4323

I28310
Service Check Mode
Detailed Information ModeDISC/CH/PROG DOWN
Detailed information
of the first code
is displayed
Detailed information
of the second code
is displayed
Continue to display detailed information
when more than one DTC is detected.
The illustration shows the case that the component with code 190 has DTC º47º and ºdCº as a result of the
system check and the diagnosis memory response.
The detailed information mode shows the system check result first, then the diagnosis memory response result.
(*1): As for DTC that does not have any sub code, sub code is not displayed.P±±±indicates physical address
190±±±physical address
SYS±±±system check result
P±±±indicates physical address
360±±±sub code
6F±±±connection
check number 1±±±the first code
62±±±logical address
DC±±±DTC CODE±±±diagnosis memory
response result
2±±±the second code
01±±±logical address
05±±±the number of times of
occurrence
(in decimal) 47±±±DTC
Continue to display detailed information
when more than one DTC is detected.*
From *
To *(*1)
: TUNE/TRACK UP
: TUNE/TRACK DOWN
DISC/CH/PROG UP
± DIAGNOSTICSAUDIO SYSTEM
DI±1977
2171 Author: Date:
2005 SEQUOIA (RM1146U)
Page 2180 of 4323

DI±1978
± DIAGNOSTICSAUDIO SYSTEM
2172 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Displayed Items in Detailed Information Mode
Division Code for
DTC displayMeaning
The order of detailed information displayed when the ºTUNE
UPº switch is pressed. (The order is reversed when the
ºTUNE DOWNº switch is pressed.)
SYSSystem check result is displayed.Logical address "
DTC
CODEDiagnostic memory check result is displayed.
Logical address"
DTC"
Sub code"
Connection confirmation number"
The number of times of occurrence
(4) Check the trouble area referring to the DTC list.
(5) To return to the service check mode, press the preset switch º3º.
2. DTC CLEAR
(a) Clearing Individual DTC Memory (when clearing the memory of the DTC detected in the past individual-
ly)
Press the preset switch º5º for 2 seconds or more while the ºECHNº is displayed in the service check
mode or during the detailed information mode.
HINT:
Beep sound is emitted once when the DTC memory is completely cleared.
When the DTC memory is cleared, only the component code (physical address) is displayed for the
target component.
To check DTCs, press the preset switch º1º and perform the service check again.
(b) Clearance of all the DTC memory (when clearing all the memory of the DTCs detected in the past)
(1) Start the diagnostic mode after repairing the trouble area.
(2) Press the preset switch º5º for 2 seconds or more (ºCLRº is displayed at this time).
HINT:
Beep sound is emitted once when the DTC memory is completely cleared.
When the DTC memory for all the component is cleared, only the component codes (physical address)
are displayed.
(3) Press the preset switch º1º to perform the service check again, and check that no DTCs are dis-
played for all the component codes (physical address).
(c) Finishing Diagnostic Mode.
Press the ºDISCº for 2 seconds or more, or turn the ignition switch off.
Page 2181 of 4323

DID9T±01
± DIAGNOSTICSAUDIO SYSTEM
DI±1979
2173 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
TermsMeaning
Physical addressThree±digit code (shown in hexadecimal) which is given to each component com-
prising the AVC±LAN.
Corresponding to the function, individual symbols are specified.
Logical addressTwo±digit code (shown in hexadecimal) which is given to each function comprising
the inner system of the AVC±LAN.
HINT:
Titles for each unit are stated in the following order: parts name (physical address) and [Name indicated on
the DTC display]
1. Radio receiver assy (physical address: 190) [AUDIO H/U]
(a) Logical address: 01 (Communication control)
DTCNameDiagnosisVerificationSee page
D6
*1Absence of Master
Component in which this code is recorded was
disconnected from system or master component
with ignition switch in ACC or ON.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
D8
*2
*5No Response to Connection
CheckComponent shown by sub code is or was discon-
nected from system after engine start.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
Page 2182 of 4323

DI±1980
± DIAGNOSTICSAUDIO SYSTEM
2174 Author: Date:
2005 SEQUOIA (RM1146U)D9
*1
Last Mode Error
Audio or visual component operated before en-
gine stop is or was disconnected with ignition
switch in ACC or ON.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DA
*5No Response to ON/OFF
Instruction
No response is identified when changing mode
(audio and visual mode change).
Sound and picture does not change by button op-
eration.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
Page 2183 of 4323

± DIAGNOSTICSAUDIO SYSTEM
DI±1981
2175 Author: Date:
2005 SEQUOIA (RM1146U)DB
*1
Mode Status ErrorDual alarm is detected.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DC
*3Transmission Error
Transmission to component shown by auxiliary
code has been failed.
(Detecting this DTC does not necessarily mean
actual failure.)
1. Power source circuit (Rear seat
audio controller). *6
2. Power source circuit (Multi±dis-
play controller sub±assy) *7
3. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
4. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
5. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
6. Replace stereo component am-
plifier assy.
7. Replace rear seat audio control-
ler. *6
8. Replace multi±display controller
sub±assy. *7DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DD
*4Master Reset (Momentary Inter-
ruption)After the engine was started, master component
was disconnected from system.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
Page 2184 of 4323

DI±1982
± DIAGNOSTICSAUDIO SYSTEM
2176 Author: Date:
2005 SEQUOIA (RM1146U)DE
*4
Slave Reset (Momentary Inter-
ruption)After the engine was started, component shown
by sub code was disconnected from system.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
DF
*4Master Error
Due to defective cognition of component with a
display, master function is switched to audio
equipment.
1. Power source circuit (Stereo
component amplifier assy).
2. Power source circuit (Rear seat
audio controller). *6
3. Power source circuit (Multi±dis-
play controller sub±assy) *7
4. AVC±LAN circuit (Radio receiver
assy ± Stereo component ampli-
fier assy).
5. AVC±LAN (Radio receiver assy
± Rear seat audio controller). *6
6. AVC±LAN (Radio receiver assy
± Multi±display controller sub±
assy). *7
7. Replace stereo component am-
plifier assy.
8. Replace rear seat audio control-
ler. *6
9. Replace multi±display controller
sub±assy. *7DI±1993
DI±2058
DI±2110
DI±2023
DI±2061
DI±2139
±
±
±
HINT:
*1: This code may be recorded depending on the battery condition or engine start voltage even if no
failure is detected.
*2: If the power connector is disconnected after the engine starts, this code is recorded after 180 se-
conds.
*3: This code may be stored if the ignition key is turned to the START position again with the engine
running.
*4: This code may be stored if the ignition key is held in the START position for 1 minute or more before
returning to the ON position.
*5: If the device is reported as not existing during verification, check the power source circuit and AVC±
LAN circuit for the device.
*6: w/ Rear seat audio system only.
*7: w/ Rear seat entertainment system only.
