Page 649 of 4323

A23481
Purge VSV
Vent Valve
Vacuum Pump
EVAP Pressure
Positive
Leak Pressure
sec NegativeONON
Sequence
TimeA
10
sec60
Within 15 minutes
sec ON
First 0.02 inch
BCD
EVAP Pressure when 0.02 Inch Orifice Clogged:
OK
Malfunction
ON: Open
OFF: Closed
OFF: Vent ON: Closed
10
Standard
sec60
E
± DIAGNOSTICSENGINE
DI±447
641 Author: Date:
2005 SEQUOIA (RM1146U)
(a) P043E: 0.02 inch orifice clogged
In operation B, the vacuum pump creates negative pressure (vacuum) through the 0.02 inch orifice. The
EVAP system pressure is then measured by the ECM, using the pressure sensor, to determine the 0.02 inch
leak pressure standard. If the pressure is lower than ±4.85 kPa (±36.38 mmHg)*, the ECM interprets this
as a clog malfunction in the 0.02 inch orifice, and stops the EVAP (Evaporative Emission) system monitor.
The ECM then illuminates the MIL and sets the DTC (2 trip detection logic).
*: The threshold varies according to the atmospheric pressure measured in operation A. The value described
above is based on an atmospheric pressure of 100 kPa (750.1 mmHg): absolute pressure.
Page 650 of 4323

A23482
Purge VSV
Vent Valve
Vacuum Pump
EVAP Pressure
Positive
Leak Pressure
sec NegativeONON
Sequence
TimeA
10
sec60
Within 15 minutes
sec ON
First 0.02 inch
BCD
OK Malfunction
ON: Open
OFF: Closed
OFF: Vent ON: Closed
10
Standard
sec60
E
EVAP Pressure when 0.02 Inch Orifice High±flow malfunction: DI±448
± DIAGNOSTICSENGINE
642 Author: Date:
2005 SEQUOIA (RM1146U)
(b) P043F: 0.02 inch orifice high±flow
In operation B, the vacuum pump creates negative pressure (vacuum) through the 0.02 inch orifice. The
EVAP system pressure is then measured by the ECM using the pressure sensor to determine the 0.02 inch
leak pressure standard. If the pressure is higher than ±1.06 kPa (±7.95 mmHg)*, the ECM interprets this as
a high±flow malfunction in the 0.02 inch orifice, and stops the EVAP system monitor. The ECM then illumi-
nates the MIL and sets the DTC (2 trip detection logic).
*: The threshold varies according to the atmospheric pressure measured in operation A. The value described
above is based on a atmospheric pressure of 100 kPa (750.1 mmHg): absolute pressure.
MONITOR STRATEGY
RltdDTCP043E0.02 inch orifice clog (built±in pump module)Related DTCsP043F0.02 inch orifice high±flow (built±in pump module)
Required sensors/componentsPump module
Frequency of operationOnce per driving cycle
DurationWithin 2 min. (varies with amount of fuel in tank)
MIL operation2 driving cycle
Sequence of operationNone
Page 651 of 4323

± DIAGNOSTICSENGINE
DI±449
643 Author: Date:
2005 SEQUOIA (RM1146U)
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page DI±18
Following values are values when atmo-
spheric is 760 mmHg (100 kPa)±
EVAP key±off monitor runs when all of the
following conditions met:±
Atmospheric pressure525 to 825 mmHg (70 to 110 kPa)
Battery voltage10.5 V±
Vehicle speed±4 km/h (2.5 mph)
Ignition switchOFF
Engine conditionNot running
Time after engine stopped5 hours
FTP sensor malfunction (P0450, P0452,
P0453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of the following conditions are met
before IG switch OFFCondition 1 and 2
1. Duration that vehicle is driven5 min.±
2. Purge flowExecuted
ECT4.4 to 35°C (40 to 95°F)
IAT4.4 to 35°C (40 to 95°F)
Example of re±start time±
First time7 hours
Second time9 hours and 30 min.
Key±off monitor sequence1 to 8
1. Atmospheric pressure±
Next sequence is run if following condition
set±
Atmospheric pressure change for 10 sec.±2.25 mmHg (0.3 kPa) for 1 sec.
2. First reference pressure±
Next sequence is run if all of following
conditions setCondition 1, 2 and 3
1. FTP when 4 sec. after reference pres-
sure measurement±±7.5 mmHg (±1 kPa)
2. Reference pressure±36.38 to ±7.93 mmHg (±4.85 to ±1.057 kPa)
3. Reference pressureSaturated
3. Vent valve stuck closed check±
Next sequence is run if following condition
set±
FTP change for 10 sec. after vent valve
ON (closed)2.25 mmHg (0.3 kPa)±
4. Vacuum introduction and leak±
Page 652 of 4323

DI±450
± DIAGNOSTICSENGINE
644 Author: Date:
2005 SEQUOIA (RM1146U) Next sequence is run if both of following
conditions set
Condition 1 and 2
1. Vacuum introduction time±15 min.
2. FTPFTP was saturated
5. Purge VSV stuck closed check±
Next sequence is run if following condition
set±
FTP change for 10 sec. after purge VSV
ON (open)2.25 mmHg (0.3 kPa)±
6. Second reference pressure measure-
ment±
Next sequence is run if all of following
conditions setCondition 1, 2, 3 and 4
1. FTP when 4 sec. after reference pres-
sure measurement±±7.5 mmHg (±1 kPa)
2. Reference pressure±36.38 to ±7.93 mmHg (±4.85 to ±1.057 kPa)
3. Reference pressureSaturated
4. Reference pressure difference between
first and second±5.25 mmHg (0.7 kPa)
7. Leak check±
Next sequence is run if following condition
set±
FTP when vacuum introduction was com-
plete±Second reference pressure
8. Atmospheric pressure±
Monitor is complete if following±
Atmospheric pressure difference between
sequence 1 and 8±2.25 mmHg (0.3 kPa)
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Following values are when atmospheric pressure is 760
mmHg (100 kPa)±
One of the following conditions is met±
FTP when 4 sec. after reference pressure measurement
beganMore than ±7.5 mmHg (±1 kPa)
Reference pressureLess than ±36.38 mmHg (±4.85 kPa)
Reference pressure±7.93 mmHg (±1.057 kPa) or more
Reference pressureNot saturated
Reference pressure difference between first and second5.3 mmHg (0.7 kPa) or more
MONITOR RESULT (MODE 06 DATA)
Refer to page DI±26 for detailed information on Monitor Result.
INSPECTION PROCEDURE
Refer to the EVAP Inspection Procedure (see page DI±460).
Page 653 of 4323

A23458
Air±fuel Ratio Sensor Output:
Active A/F Control
A/F Sensor Output
Fuel Injection VolumeON
OFF
NormalMalfunction 10 Seconds
± DIAGNOSTICSENGINE
DI±451
645 Author: Date:
2005 SEQUOIA (RM1146U)
DTC P2A00 A/F Sensor Circuit Slow Response (Bank 1
Sensor 1)
DTC P2A03 A/F Sensor Circuit Slow Response (Bank 2
Sensor 1)
CIRCUIT DESCRIPTION
Refer to DTC P2195 on page DI±383.
DTC No.DTC Detection ConditionsTrouble Areas
P2A00
P2A03Calculated test value for A/F sensor response rate deteriora-
tion level is less than threshold.Open or short in A/F sensor (sensor 1) circuit
A/F sensor (sensor 1)
ECM
MONITOR DESCRIPTION
After engine is warmed up, the ECM performs air±fuel ratio feedback control to regulate the air±fuel ratio
at stoichiometric ratio. In addition, this vehicle performs Active A/F Ratio Control for approximately 10 se-
conds after preconditions met in order to measure the A/F sensor response rate. During active air±fuel ratio
control, the ECM forcibly increases and decreases the injection volume for certain amount based on learned
stoichiomentric air ±fuel ratio during usual air±fuel feedback control, and measures the A/F sensor response
rate. The ECM calculates the signal from the A/F sensor while value for A/F sensor response rate deteriora-
tion level.
If the test value for A/F sensor response rate deterioration level is less than threshold, ECM interprets this
as a malfunction, and sets the DTC.
DIDFY±01
Page 654 of 4323

Vehicle speed
(40 ±120 km/h)25 ± 75mph)
(g)(h)
Warm up
3 minutes DI±452
± DIAGNOSTICSENGINE
646 Author: Date:
2005 SEQUOIA (RM1146U)
CONFIRMATION DRIVING PATTERN
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch to ON.
(c) Turn the hand±held tester ON.
(d) Clear DTCs.
(e) Select the following menu items: DIAGNOSIS/ENHANCED OBD II/MONITOR INFO/MONITOR RE-
SULT.
(f) Check that RES RATE B1 S1 is INCOMPL.
(g) Start the engine and warm it up.
(h) Drive the vehicle at between 25 mph and 75 mph (40 km/h and 120km/h) for 3 minutes. However, the
vehicle should be driven at constant±speed.
(i) When detection is complete, Response rate of MONITOR RESULT changes.
If the value does not change, perform step (g) once more.
(j) Notes the value of the Monitor Result.
(k) Select the following menu items: DIAGNOSIS/ENHANCED OBD II/DTC INFO/ PENDING CODES.
(l) Check if any DTCs (any pending DTCs) are set.
MONITOR STRATEGY
RltdDTCP2A00A/F sensor (Bank 1) slow responseRelated DTCsP2A03A/F sensor (Bank 2) slow response
Required sensors/componentsA/F sensor
Frequency of operationOnce per driving cycle
Duration10 to 15 sec.
MIL operation2 driving cycles
Sequence of operationNone
Page 655 of 4323

± DIAGNOSTICSENGINE
DI±453
647 Author: Date:
2005 SEQUOIA (RM1146U)
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page DI±18
Battery voltage11 V±
ECT75°C (167°F)±
IdleOFF
Engine RPM±4,000 rpm
A/F sensor statusActivated
Fuel cutOFF
Engine load10 to 70%
Estimated catalyst temperature500 to 800°C (932 to 1,472°F)
Shift position2nd±
Catalyst monitorNot executing
Intake air amount2.5 to 12 g/sec
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Response rate deterioration levelLess than 0.2 V
Number of average5 or more
MONITOR RESULT
Refer to page DI±26 for detailed information.
The test value and test limit information are described as shown in the following table. Check the monitor
result and test values after performing the monitor drive pattern (refer to ºConfirmation Monitorº).
MID (Monitor Identification Data) is assigned to each emissions±related component.
TID (Test Identification Data) is assigned to each test value.
Scaling is used to calculate the test value indicated on generic OBD ll scan tools.
A/F sensor bank 1 sensor 1
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$01$8EMultiply by 0.0003
(no dimension)Response rate deterioration level for
A/F sensorMalfunction criterionFF
A/F sensor bank 2 sensor 1
MIDTIDScalingDescription of Test ValueMinimum Test LimitMaximum Test Limit
$05$8EMultiply by 0.0003
(no dimension)Response rate deterioration level for
A/F sensorMalfunction criterionFF
WIRING DIAGRAM
Refer to DTC P2195 on page DI±383.
Page 656 of 4323

DI±454
± DIAGNOSTICSENGINE
648 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
HINT:
Hand±held tester only:
Malfunctioning areas can be identified by performing the A/F CONTROL function provided in the ACTIVE
TEST. The A/F CONTROL function can help to determine whether the Air±Fuel Ratio (A/F) sensor, Heated
Oxygen (HO2) sensor and other potential trouble areas are malfunctioning.
The following instructions describe how to conduct the A/F CONTROL operation using a hand±held tester.
(1) Connect a hand±held tester to the DLC3.
(2) Start the engine and turn the tester ON.
(3) Warm up the engine at an engine speed of 2,500 rpm for approximately 90 seconds.
(4) On the tester, select the following menu items: DIAGNOSIS / ENHANCED OBD II / ACTIVE
TEST / A/F CONTROL.
(5) Perform the A/F CONTROL operation with the engine in an idling condition (press the RIGHT
or LEFT button to change the fuel injection volume).
(6) Monitor the voltage outputs of the A/F and HO2 sensors (AFS B1S1 (AFS B2S1) and OS2 B1S2
(O2S B2S2)) displayed on the tester.
HINT:
The A/F CONTROL operation lowers the fuel injection volume by 12.5 % or increases the injection
volume by 25 %.
Each sensor reacts in accordance with increases and decreases in the fuel injection volume.
Standard:
Tester Display
(Sensor)Injection VolumesStatusVoltages
AFS B1S1 (AFS B2S1)
(A/F)+25 %RichLess than 3.0
AFS B1S1 (AFS B2S1)
(A/F)±12.5 %LeanMore than 3.35
O2S B1S2 (O2S B2S2)
(HO2)+25 %RichMore than 0.55
O2S B1S2 (O2S B2S2)
(HO2)±12.5 %LeanLess than 0.4
