Page 2881 of 4323
IG0EL±04
B02713
Ohmmeter IG±12
± IGNITIONCRANKSHAFT POSITION SENSOR
2873 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
NOTICE:
ºColdº and ºHotº in these sentences express the tempera-
ture of the coils themselves. ºColdº is from ±10°C (14°F) to
50°C (122°F) and ºHotº is from 50°C (122°F) to 100°C
(212°F).
INSPECT CRANKSHAFT POSITION SENSOR
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance:
Cold1,630 ± 2,740 W
Hot2,065 ± 3,225 W
If the resistance is not as specified, replace the crankshaft posi-
tion sensor.
Page 2882 of 4323
IG0EM±04
B07251
± IGNITIONCRANKSHAFT POSITION SENSOR
IG±13
2874 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL CRANKSHAFT POSITION SENSOR
(a) Install the crankshaft position sensor with the bolt.
Torque: 6.5 N´m (65 kgf´cm, 58 in.´lbf)
(b) Connect the crankshaft position sensor connector.
2. INSTALL ENGINE UNDER COVER
Page 2883 of 4323
ST08X±03
± STARTINGSTARTING SYSTEM
ST±1
2875 Author: Date:
2005 SEQUOIA (RM1146U)
STARTING SYSTEM
ON±VEHICLE INSPECTION
NOTICE:
Before changing the starter, check these items again:
Connector connection
Accessory installation, e.g.: engine immobilizer system
Page 2884 of 4323
ST08Y±06
B17459
Non±reusable partThrottle Body Cover
PS Air Hose
Intake Air Connector
Suction Hose
MAF Meter Wire
PCV Hose
Vacuum Hose
ST±2
± STARTINGSTARTER
2876 Author: Date:
2005 SEQUOIA (RM1146U)
STARTER
COMPONENTS
Page 2885 of 4323
B17496
Injector Connector
VSV Connector
for EVAP
Starter ConnectorStarterIntake Manifold Assembly Engine Wire and Clamp
Gasket
Non±reusable part
39 (400, 29)
Engine Wire
Protector
Fuel Return Hose
Engine Wire
N´m (kgf´cm, ft´lbf) : Specified torque GasketFuel Inlet Hose
Air Switching Valve No.2
Gasket
Gasket
10 (102, 7 )
10 (102, 7 )
10 (102, 7 )
10 (102, 7 )
± STARTINGSTARTER
ST±3
2877 Author: Date:
2005 SEQUOIA (RM1146U)
Page 2886 of 4323
B13802
O±Ring Idler GearStarter Housing
Assembly
Return SpringStarter Clutch
Assembly
Steel Ball
Contact Plate Rear BearingArmatureMagnetic Switch
AssemblyBearing
Front Bearing
O±Ring
End Cover
Brush Holder
Magnetic Switch Assembly
Terminal Nut
O±Ring Wave WasherTerminal Bolt
Terminal C Kit Part
Lead Terminal
Plunger
Gasket
End Cover
Terminal BoltWave Washer O±Ring
Terminal Nut
Terminal 30 Kit Part
Non±reusable part
Dust Protector
Dust Protector
Field Frame (Field Coil)
17 (170, 13)
17 (170, 13)
N´m (kgf´cm, ft´lbf) : Specified torque O±Ring
Contact Plate
ST±4
± STARTINGSTARTER
2878 Author: Date:
2005 SEQUOIA (RM1146U)
Page 2887 of 4323
ST08Z±07
B04548
B04549
Starter
Connector
Engine Wire Protector
± STARTINGSTARTER
ST±5
2879 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE THROTTLE BODY COVER
2. REMOVE INTAKE AIR CONNECTOR
3. DISCONNECT CABLE FROM NEGATIVE (±) BATTERY
TERMINAL
4. DISCONNECT THROTTLE BODY ASSEMBLY FROM
INTAKE MANIFOLD (See page SF±42)
5. REMOVE INTAKE MANIFOLD ASSEMBLY
(See page EM±36)
6. REMOVE AIR PUMP ASSEMBLY (See page EC±22)
7. REMOVE STARTER
(a) Remove the 2 bolts holding the starter from the cylinder
block.
(b) Disconnect the starter from the cylinder block.
(c) Disconnect the starter connector.
(d) Remove the nut, bolt and disconnect the starter wire.
(e) Remove the bolt, and disconnect the engine wire protec-
tor from the starter.
(f) Remove the starter.
Page 2888 of 4323

ST090±06
B12318
B12328
B13804
B13805
(2)(3)
(1) (4)
(5)
ST0948
Magnetic Finger
ST±6
± STARTINGSTARTER
2880 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE FIELD FRAME AND ARMATURE
(a) Remove the nut, and disconnect the lead wire from the
magnetic switch terminal.
Torque: 5.9 N´m (60 kgf´cm, 52 in.´lbf)
(b) Remove the 2 through bolts.
Torque: 9.3 N´m (95 kgf´cm, 82 in.´lbf)
(c) Pull out the field frame together with the armature from the
magnetic switch assembly.
NOTICE:
At the time of assembly, align the protrusion of the field
frame with the groove of the magnetic switch.
(d) Remove the O±ring from the field frame.
HINT:
At the time of assembly, use a new O±ring.
2. REMOVE STARTER HOUSING, CLUTCH ASSEMBLY
AND GEAR
(a) Remove the 2 screws.
Torque: 9.3 N´m (95 kgf´cm, 82 in.´lbf)
(b) Remove these parts from the magnetic switch assembly:
(1) Starter housing
(2) Return spring
(3) Idler gear
(4) Bearing
(5) Starter clutch assembly
HINT:
At the time of assembly, please refer to the following items.
Apply grease to the return spring and insert the return spring
into the clutch shaft hole.
3. REMOVE STEEL BALL
Using a magnetic finger, remove the steel ball from the clutch
shaft hole.
HINT:
At the time of assembly, apply grease to the steel ball and insert
the steel ball into the clutch shaft hole.
