Page 3225 of 4323
BR1NH±03
F16314
Connector
11 (112, 8)
Actuator BracketActuator CushionActuator Assembly
11 (112, 8)
1.8 (18, 16 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf)
19.5 (195, 14)
15 (155, 11)
Non±reusable part
19.5 (195, 14)
15 (155, 11)
15 (155, 11)
9.5 (97, 84 in.´lbf)
9.5 (97, 84 in.´lbf)
Skid Control ECU
Cushion
To left rear brake
To right front brake To right rear brake
To left front brake From master cylinder
(front port)From master cylinder
(rear port)
15 (155, 11)
1.8 (18, 16 in.´lbf)
BR±50
± BRAKEABS & VSC ACTUATOR
3217 Author: Date:
2005 SEQUOIA (RM1146U)
COMPONENTS
Page 3226 of 4323
BR1NI±03
F16315
Release Bar
F16316
± BRAKEABS & VSC ACTUATOR
BR±51
3218 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. DISCONNECT CONNECTOR
Pull the release bar and disconnect the connector.
2. DISCONNECT BRAKE LINES
Using SST, disconnect the 6 brake lines from the actuator as-
sembly.
SST 09023±00101, 09023±38201
Torque:
10 mm nut: 15 N´m (155 kgf´cm, 11 ft´lbf)
12 mm nut: 19.5 N´m (195 kgf´cm, 14 ft´lbf)
HINT:
When disconnecting the brake lines, use tags or make a
memo to identify the place to reconnect (See page
BR±50).
At the time of installation, connect each brake line to the
correct position (See page BR±50).
3. REMOVE ACTUATOR ASSEMBLY
Remove the 3 nuts and actuator assembly with the actuator
bracket.
Torque: 11 N´m (112 kgf´cm, 8 ft´lbf)
Page 3227 of 4323
BR1NJ±03
F13898
Sealing
Surface
BR±52
± BRAKEABS & VSC ACTUATOR
3219 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE ACTUATOR BRACKET
(a) Remove the 3 bolts and actuator bracket.
Torque: 9.5 N´m (97 kgf´cm, 84 in.´lbf)
(b) Remove the 3 cushions from the actuator bracket.
2. REMOVE SKID CONTROL ECU
Using a E5 torx® wrench, remove the 3 screws and skid control
ECU.
Torque: 1.8 N´m (18 kgf´cm, 16 in.´lbf)
NOTICE:
Protect the actuator in order to prevent sealing surface
from getting dirty and causing damage on the valve body.
If the dirt and the like is stuck to the sealing surface, use
plastic tools or soft objects to remove the dirt. Do not use
chemical solvents.
Page 3228 of 4323
BR1NK±02
± BRAKEABS & VSC ACTUATOR
BR±53
3220 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BR±52).
Page 3229 of 4323
BR1NL±04
BR±54
± BRAKEABS & VSC ACTUATOR
3221 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±51).
HINT:
After installation, fill the brake reservoir with brake fluid and bleed brake system (See page BR±4).
Check for leaks.
NOTICE:
In case of replacing the skid control ECU, perform the zero point calibration of the steering angle,
master cylinder pressure, yawrate and deceleration sensors (See page DI±897).
Page 3230 of 4323
BR0A2±05
F08184
8.0 (82, 71 in.´lbf)
8.0 (82, 71 in.´lbf)
Front Speed Sensor
: Specified torque
N´m (kgf´cm, ft´lbf)
8.0 (82, 71 in.´lbf)
± BRAKEFRONT SPEED SENSOR
BR±55
3222 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT SPEED SENSOR
COMPONENTS
Page 3231 of 4323
BR0A3±04
F08186
BR±56
± BRAKEFRONT SPEED SENSOR
3223 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 110 N´m (1,122 kgf´cm, 81 ft´lbf)
2. DISCONNECT SPEED SENSOR CONNECTOR
3. REMOVE SPEED SENSOR
(a) Remove the clips and 3 clamp bolts holding the sensor
harness from the frame, upper arm and steering knuckle.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
(b) Remove the bolt and speed sensor from the steering
knuckle.
Torque: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
Page 3232 of 4323
BR0A4±07
± BRAKEFRONT SPEED SENSOR
BR±57
3224 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BR±56).
HINT:
After installation, check speed sensor signal (See page DI±899).
