Page 3121 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual R04328
R12920
SST
SST
RA0997
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±117
3113 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Using a dial indicator, measure the differential case run-
out.
M

Page 3122 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA15P±07
R04465
SST Socket Wrench
R04331
SST
Steel Plate SA±118
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3114 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACE COMPANION FLANGE DUS

Page 3123 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual FA1121
SA24G±03
FA1123
FA1124
R13423
SST
SST
SSTSST
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±119
3115 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
1. ASSEMBLE DIFFERENTIAL CASE
(a)

Page 3124 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual SA1143
Boiling Water
R04332
Matchmarks
Thread Lock
R04334
R04335
SST SA±120
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3116 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Heat the ring gear to abo

Page 3125 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual R00055
SST
R11163SST
F14486
40 mm
(1.57 in.)
F14485
SST
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±121
3117 Author: Date:
2005 SEQUOIA (RM1146U)
HINT:
First fit a washer with the same thi

Page 3126 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual F14520SST
SA2347
SST
SA2446
R04453
SA±122
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3118 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Adjust the drive pinion preload by tightening the
companion

Page 3127 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual R04535
R04558
R04453
R04455
R04338
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
SA±123
3119 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Tap on the ring gear with a plastic hammer so that the
wash

Page 3128 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual R04456
RA0090
R04456
SA±124
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3120 Author: Date:
2005 SEQUOIA (RM1146U)
(j) Using a dial indicator, while holding the companion flange
measure the ri

R04456
RA0090
R04456
SA±124
± SUSPENSION AND AXLEREAR DIFFERENTIAL CARRIER
3120 Author: Date:
2005 SEQUOIA (RM1146U)
(j) Using a dial indicator, while holding the companion flange
measure the ring gear backlash.
Backlash: 0.13 ± 0.18 mm (0.0051 ± 0.0071 in.)
If the backlash is not within the specified value, adjust it by ei-
ther increasing or decreasing the thickness of washers on both
sides by an equal amount.
HINT:
There should be no clearance between the plate washer and
the case.
Make sure that there is a ring gear backlash.
10. ADJUST SIDE BEARING PRELOAD
(a) Remove the ring gear teeth side plate washer and using
a micrometer, measure the thickness.
(b) Using the backlash as a reference, install a new washer
that is 0.05 ± 0.20 mm (0.0019 ± 0.0078 in.) thicker than
the washer removed.
HINT:
Select a washer which can be pressed in 2/3 of the way with
your finger.
(c) Using a plastic hammer, install the plate washer.
(d) Recheck the ring gear backlash.
Backlash: 0.13 ± 0.18 mm (0.0051 ± 0.0071 in.)
If the backlash is not within the specified value, adjust it by ei-
ther increasing or decreasing the thickness of washers on both
sides by equal amount.
HINT:
The backlash will change by about 0.02 mm (0.0008 in.) corre-
sponding to 0.03 mm (0.0012 in.) change in the plate washer.
Washer thickness:
Thickness
Mark mm (in.)Thickness
Mark mm (in.)Thickness
Mark mm (in.)
58 2.58 (0.1015)90 2.90 (0.1142)22 3.22 (0.1268)
60 2.60 (0.1024)92 2.92 (0.1150)24 3.24 (0.1276)
62 2.62 (0.1031)94 2.94 (0.1157)26 3.26 (0.1283)
64 2.64 (0.1039)96 2.96 (0.1165)28 3.28 (0.1291)
66 2.66 (0.1047)98 2.98 (0.1173)30 3.30 (0.1299)
68 2.68 (0.1055)00 3.00 (0.1181)32 3.32 (0.1307)
70 2.70 (0.1063)02 3.02 (0.1189)34 3.34 (0.1315)
72 2.72 (0.1071)04 3.04 (0.1197)36 3.36 (0.1323)
74 2.74 (0.1079)06 3.06 (0.1205)38 3.38 (0.1331)
76 2.76 (0.1087)08 3.08 (0.1213)40 3.40 (0.1339)
78 2.78 (0.1094)10 3.10 (0.1220)42 3.42 (0.1346)
80 2.80 (0.1102)12 3.12 (0.1228)44 3.44 (0.1354)
82 2.82 (0.1110)14 3.14 (0.1236)46 3.46 (0.1362)
84 2.84 (0.1118)16 3.16 (0.1244)48 3.48 (0.1370)
