Page 3201 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR±26 ± BRAKEFRONT BRAKE PAD 3193 Author: Date: 2005 SEQUOIA (RM1146U) HINT: Apply disc brake grease to both sides of inner anti±squeal shims (See page BR±24). (d) Install new pads. NOTICE: Do

Page 3202 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10L±03 F07751 Bleeder Plug 11 (110, 8) Brake Caliper 15 (155, 11) 123 (1,250, 90) Piston Seal Piston Boot Set Ring ClipInner Pad Outer Pad Anti±squeal Shim Anti±rattle Spring Inner Anti±squeal S

Page 3203 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10M±03 F07752 SST F07753 BR±28 ± BRAKEFRONT BRAKE CALIPER 3195 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE FRONT WHEEL Torque: 110 N´m (1,122 kgf´cm, 81 ft´lbf) 2. DISCONNECT BR

Page 3204 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10N±03 R13540 Z08697 170 mm (6.70 in.) 28 mm (1.10 in.)(1.97 in.)50 mm R13541 R13542 ± BRAKEFRONT BRAKE CALIPER BR±29 3196 Author: Date: 2005 SEQUOIA (RM1146U) DISASSEMBLY 1. REMOVE CYLINDER

Page 3205 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10O±04 R13543 R13544 R13545 BR±30 ± BRAKEFRONT BRAKE CALIPER 3197 Author: Date: 2005 SEQUOIA (RM1146U) INSPECTION 1. MEASURE PAD LINING THICKNESS Using a ruler, measure the pad lining thickne

Page 3206 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10P±03 ± BRAKEFRONT BRAKE CALIPER BR±31 3198 Author: Date: 2005 SEQUOIA (RM1146U) REASSEMBLY Reassembly is in the reverse order of disassembly (See page BR±29). NOTICE: Apply lithium soap b

Page 3207 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR10Q±03 BR±32 ± BRAKEFRONT BRAKE CALIPER 3199 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION Installation is in the reverse order of removal (See page BR±28). HINT: After installation, fi

Page 3208 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual BR0JP±15 F13330 Brake Caliper Anti±squeal Shim Inner PadPad Support Plate Pad Support PlateOuter Pad Anti±squeal Shim N´m (kgf´cm, ft´lbf) : Specified torque88 (900, 65) Pad Wear Indicator Plat
