± DIAGNOSTICSENGINE
DI±95
289 Author: Date:
2005 SEQUOIA (RM1146U)DTC No.
DTC Detecting ConditionTrouble Area
P0037Heater current is 0.25 A or less when the heater operates with

Open in heater circuit of heated oxygen sensor

Heated ox
ygen sensor heaterP0037
P0057
Heater current is 0.25 A or less when the heater o erates with
more than 10.5 V positive battery voltage

Heated oxygen sensor heater

EFI relay

ECM
P0038
P0058When heater operates, heater current exceeds 2.0 A

Short in heater circuit of heated oxygen sensor

Heated oxygen sensor heater

EFI relay

ECM
HINT:

Bank 1 refers to bank that includes cylinder No. 1.

Bank 2 refers to bank that does not includes cylinder No. 1.

Sensor 1 refers to the sensor closer to the engine assembly.

Sensor 2 refers to the sensor farther away from the engine assembly.
MONITOR DESCRIPTION
The sensing portion of the heated oxygen sensor has a zirconia element which is used to detect oxygen
concentration in the exhaust. If the zirconia element is at the proper temperature and difference of the oxy-
gen concentration between the inside and outside surface of sensor is large, the zirconia element will gener-
ate voltage signals. In order to increase the oxygen concentration detecting capacity in the zirconia element,
the ECM supplements the heat from the exhaust with heat from a heating element inside the sensor. When
current in the sensor is out of the standard operating range, the ECM interprets this as a fault in the heated
oxygen sensor and sets a DTC.
Example:
The ECM will set a high current DTC if the current in the sensor is more than 2.0 A when the heater is OFF.
Similarly, the ECM will set a low current DTC if the current is less than 0.3 A when the heater is ON.
MONITOR STRATEGY
P0037Rear HO2S heater (Bank 1) range check (Low
Current)
RltdDTC
P0038Rear HO2S heater (Bank 1) range check (High
Current)
Related DTCs
P0057Rear HO2S heater (Bank 2) range check (Low
Current)
P0058Rear HO2S heater (Bank 2) range check (High
Current)
Rid / tMain sensors/componentsHO2S heaterRequired sensors/componentsRelated sensors/componentsVehicle speed sensor (VSS)
Frequency of operationContinuous
Duration0.3 sec.
MIL operationImmediate
Sequence of operationNone

DI±152
± DIAGNOSTICSENGINE
346 Author: Date:
2005 SEQUOIA (RM1146U) A/F sensor status
Activated
Fuel±cutOFF
Engine load10 to 70%
Shift position4th±
Heated oxygen sensor impedance (Low):
Battery voltage11 V±
Estimated sensor temperature±700°C (1,292°F)
ECM monitorCompleted
P0606Not set
Heated oxygen sensor impedance (High):
Battery voltage11 V±
Estimated sensor temperature450°C (842°F)±
ECM monitorCompleted
P0606Not set
Heated oxygen sensor output voltage (Extremely high):
Battery voltage11 V±
Time after engine start2 sec.±
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Heated oxygen sensor output voltage (Output voltage):
Either of the following conditions is met:Condition 1 or 2
1. All of the following conditions are met:Condition (a), (b) and (c)
(a) Commanded air±fuel ratio14.3 or less
(b) Rear HO2S voltage0.21 to 0.59 V
(c) OSC (Oxygen Storage Capacity of catalyst)3 g or more
2. All of the following conditions are met:Condition (a), (b) and (c)
(a) Commanded air±fuel ratio14.9 or more
(b) Rear HO2S voltage0.21 to 0.59 V
(c) OSC (Oxygen Storage Capacity of catalyst)3 g or more
Heated oxygen sensor output voltage (Low voltage):
All of the following conditions are met:Condition 1, 2 and 3
1. Commanded air±fuel ratio14.3 or less
2. Rear HO2S voltageLess than 0.21 V
3. OSC (Oxygen Storage Capacity of catalyst)3 g or more
Heated oxygen sensor output voltage (High voltage):
All of the following conditions are met:Condition 1, 2 and 3
1. Commanded air±fuel ratio14.9 or more
2. Rear HO2S voltageMore than 0.59 V
3. OSC (Oxygen Storage Capacity of catalyst)3 g or more
Heated oxygen sensor impedance (Low):
Duration of following condition30 sec. or more
Heated oxygen sensor impedanceLess than 5 W
Heated oxygen sensor impedance (High):
Duration of following condition90 sec. or more

DI±250
± DIAGNOSTICSENGINE
444 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR STRATEGY
RltdDTCP0420Bank 1 catalyst is deterioratedRelated DTCsP0430Bank 2 catalyst is deteriorated
Main sensors/componentsFront and rear heated oxygen sensor
Required sensors/componentsRelated sensors/components
Mass air flow meter, Engine coolant temperature
sensor, Engine speed sensor, Intake air tempera-
ture sensor
Frequency of operationOnce per driving cycle
Duration20 sec.
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page DI±18
Battery voltage11 V±
Intake air temperature±10C (14F)±
Engine coolant temperature75°C (167°F)±
Atmospheric pressure coefficient0.75±
IdleOFF
Engine RPM±3,200 rpm
A/F sensorActivated
Fuel system statusClosed loop
Engine load10 to 70 %
All of the following conditions are metCondition 1, 2 and 3
1. MAF6to 75 g/sec
2. Front catalyst temperature (estimated)620to 830C (1,148 to 1,526F)
3. Rear catalyst temperature (estimated)410 to 830C (770 to 1,526F)
Rear HO2S monitorCompleted
Shift position4th±
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Oxygen storage capacity (OSC) of catalystLess than 0.16

DI±250
± DIAGNOSTICSENGINE
444 Author: Date:
2005 SEQUOIA (RM1146U)
MONITOR STRATEGY
RltdDTCP0420Bank 1 catalyst is deterioratedRelated DTCsP0430Bank 2 catalyst is deteriorated
Main sensors/componentsFront and rear heated oxygen sensor
Required sensors/componentsRelated sensors/components
Mass air flow meter, Engine coolant temperature
sensor, Engine speed sensor, Intake air tempera-
ture sensor
Frequency of operationOnce per driving cycle
Duration20 sec.
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever these
DTCs are not presentSee page DI±18
Battery voltage11 V±
Intake air temperature±10C (14F)±
Engine coolant temperature75°C (167°F)±
Atmospheric pressure coefficient0.75±
IdleOFF
Engine RPM±3,200 rpm
A/F sensorActivated
Fuel system statusClosed loop
Engine load10 to 70 %
All of the following conditions are metCondition 1, 2 and 3
1. MAF6to 75 g/sec
2. Front catalyst temperature (estimated)620to 830C (1,148 to 1,526F)
3. Rear catalyst temperature (estimated)410 to 830C (770 to 1,526F)
Rear HO2S monitorCompleted
Shift position4th±
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Oxygen storage capacity (OSC) of catalystLess than 0.16

N30016
I21529
BE±100
± BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
3504 Author: Date:
2005 SEQUOIA (RM1146U)
2. CHECK BATTERY CAPACITY
HINT:

Make sure to use the TOYOTA electrical tester.

With the battery unloaded, judge can not be made wheth-
er the battery is available or not on the test.

When the transmitter is faulty, the energy amount left in
the battery might not be checked correctly.

On the lithium battery used for the transmitter, the voltage
more than 2.5 V with the battery unloaded is shown on the
tester until the energy is completely consumed.
Accordingly when inspecting the energy amount left in the
battery, it is necessary to measure the voltage when the
battery is loaded (1.2 kW).
(a) Remove the cover using a (±) driver.
(b) Remove the battery (lithium battery) from the transmitter.
(c) Connect the lead to the (±) terminal of the transmitter and
install the battery.
(d) Connect the (+) tester to the (+) battery (lithium battery),
and (±) tester to the lead respectively.
(e) Press one of the transmitting switches on the transmitter
for approx. 1 second.
(f) Press the transmitting switch on the transmitter again to
check the voltage.
Standard: 2.1 V or more

05_SEQUOIA_U (L/O 0408)
314
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
After it finishes heating up, it automati-
cally pops out ready for use.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
ASHTRAYS
Front: To use the ashtray, pull it out.
Rear: To use the ashtray, raise the lid.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
FrontÐTo remove the ashtray, press down
on the lock spring plate and pull out.
RearÐTo remove the ashtray, pull it out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always completely close
the ashtray after use.
Instrument panel
Rear console box
Luggage compartment
The power outlets are designed for
power supply for car accessories.
NOTICE

To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W.

To prevent the battery from being
discharged, do not use the power
outlets longer than necessary when
the engine is not running.
Power outlets (12 VDC)

05_SEQUOIA_U (L/O 0408)
353
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Ti r e relat ed ter mMeaning
Normal occupant weight68 kg (150 lb.) times the number of occupants specified in the second
column of Table 1 that follows
Occupant distributiondistribution of occupants in a vehicle as specified in the third column of Table
1 that follows
Production options weight
the combined weight of those installed regular production options weighing
over 2.3 kg (5 lb.) in excess of those standard items which they replace,
not previously considered in curb weight or accessory weight, including
heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special
trim
Recommended inflation pressurecold tire inflation pressure recommended by a manufacturer
Rima metal support for a tire or a tire and tube assembly upon which the tire beads
are seated
Rim diameter (Wheel diameter)nominal diameter of the bead seat
Rim size designationrim diameter and width
Rim type designationthe industry of manufacturer 's designation for a rim by style or code
Rim widthnominal distance between rim flanges
Vehicle capacity weight
(Total load capacity)the rated cargo and luggage load plus 68 kg (150 lb.) times the vehicle's desig-
nated seating capacity
Vehicle maximum load on the tirethe load on an individual tire that is determined by distributing to each axle
its share of the maximum loaded vehicle weight and dividing by two

05_SEQUOIA_U (L/O 0408)
367
2005 SEQUOIA from Aug. '04 Prod. (OM34424U)
Make sure your coolant is properly pro-
tected against freezing.
Only use ªToyota Super Long Life Coolantº
or similar high quality ethylene glycol
based non±silicate, non±amine, non±nitrite,
and non±borate coolant with long±life
hybrid organic acid technology. (Coolant
with long±life hybrid organic acid
technology is a combination of low
phosphates and organic acids.)
See ªChecking the engine coolant levelº
on page 426 in Section 7±2 for details of
coolant type selection.
For the U.S.A.ЪToyota Super Long Life
Coolantº is a mixture of 50% coolant and
50% deionized water. This coolant pro-
vides protection down to about ±35C
(±31F).
For CanadaЪToyota Super Long Life
Coolantº is a mixture of 55% coolant and
45% deionized water. This coolant pro-
vides protection down to about ±42C
(±44F).
NOTICE
Do not use plain water alone.
Check the condition of the battery and
cables.
Cold temperatures reduce the capacity of
any battery, so it must be in top shape
to provide enough power for winter start-
ing. Section 7±3 tells you how to visually
inspect the battery. Your Toyota dealer
and most service stations will be pleased
to check the level of charge.
Make sure the engine oil viscosity is
suitable for the cold weather.
See page 424 in Section 7±2 for recom-
mended viscosity. Leaving a heavy sum-
mer oil in your vehicle during winter
months may cause harder starting. If you
are not sure about which oil to use, call
your Toyota dealerÐthey will be pleased
to help.
Keep the door locks from freezing.
Squirt lock de±icer or glycerine into the
locks to keep them from freezing.Use a washer fluid containing an anti-
freeze solution.
This product is available at your Toyota
dealer and most auto parts stores. Follow
the manufacturer 's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle's paint.
Do not use your parking brake when
there is a possibility it could freeze.
When parking, put the transmission into
ªPº and block the front wheels. Do not
use the parking brake, or snow or water
accumulated in and around the parking
brake mechanism may freeze, making it
hard to release.
Winter driving tips
