2001 TOYOTA SEQUOIA headlights

IN±22
± INTRODUCTIONFOR ALL OF VEHICLES
22 Author: Date:
2005 SEQUOIA (RM1146U)
DOOR LOCK:
DISPLAY (ITEM)DEFAULTCONTENTSSETTING
AUTO LOCK/SHIFTONLocks doors when shift lever is moved from P to another
position.ON/OFF
ILLUMINATED ENTRY:
DISPLAY (ITEM)DEFAULTCONTENTSSETTING
I/L ON/UNLOCKONIlluminates interior light when ignition switch is turned from
ACC to LOCK position.ON/OFF
LIGHTING TIME15SChanges lighting time after closing doors (light quickly fades
out when ignition switch is turned on).15S/7.5S/30S
LIGHT CONTROL:
DISPLAY (ITEM)DEFAULTCONTENTSSETTING
SENSITIVITYNORMALSensitivity adjustment is difficult to confirm. Check by driving
the customer's vehicle.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2
LIGHT OFF DELAY30S
Keeps headlights on for a certain period of time after closing
all doors with ignition switch on, light control switch in HEAD
or AUTO position, and headlights on.
OFF/30S/60S/90S
DISP EX ON SENNORMALChanges brightness of lights such as combination meter
indicator light, A/C indicator lamp, and clock lamp.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2
DISP OFF SENNORMALChanges brightness of lights such as combination meter
indicator light, A/C indicator lamp, and clock lamp.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2

MA002±35
MA±2
± MAINTENANCEINSIDE VEHICLE
49 Author: Date:
2005 SEQUOIA (RM1146U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are maintenance and inspection items which are considered to be the owner's responsibility.
They can be done by the owner or they can have them done at a service shop.
These items include those which should be checked on a daily basis, those which, in most cases, do not
require (special) tools and those which are considered to be reasonable for the owner to do.
Items and procedures for general maintenance are as follows.
1. GENERAL NOTES

Maintenance items may vary from country to country. Check the owner's manual supplement in which
the maintenance schedule is shown.

Every service item in the periodic maintenance schedule must be performed.

Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).

Maintenance service after the last period should be performed at the same interval as before unless
otherwise noted.

Failure to do even one item can cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlight aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and are mounted securely.
10. STEERING WHEEL
Check that it has the specified free play. Be alert for changes in steering condition, such as hard steering,
excessive free play or strange noises.
11. SEATS
(a) Check that the seat adjusters operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For fold±down seat backs, check that the latches lock securely.
12. SEAT BELTS
(a) Check that the seat belt system such as the buckles, retractors and anchors operate properly and
smoothly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.

± DIAGNOSTICSENGINE
DI±53
247 Author: Date:
2005 SEQUOIA (RM1146U)A/C SIG
A/C signal: ON or OFFON: A/C ON'
ELECT LOAD SIGElectrical load signal:
ON or OFFON: Headlights or defogger is
turned ON'
STOP LIGHT SWStop lamp switch:
ON or OFFON: brake pedal is depressed.'
+BM
Whether or not electric throttle
control system power inputted:
ON or OFF
ON: Idling'
+BM VOLTAGE+BM voltage:
Min.: 0, Max.: 19.9210 to 15 V: IdlingETCS service data
BATTERY VOLTAGEBattery voltage:
Min.: 0 V, Max.: 65.535 V9 to 14 V: Idling'
ACTUATOR POWERActuator power supply:
ON or OFFON: IdlingETCS service data
ATM PRESSUREAtmospheric pressure:
Min.: 0 kPa, Max.: 150 kPaEquivalent to atmospheric pres-
sure (absolute pressure)'
SECOND AIR VSVSecondary air injection system
statusON: Secondary air injection sys-
tem operation'
ACT VSVA/C cut status for Active Test:
ON or OFF'Active Test support data
EVAP (Purge) VSVVSV status for EVAP control:
ON or OFF'Active Test support data
FUEL PUMP / SPDFuel pump/speed status:
ON or OFF'Active Test support data
VVT CTRL B1VVT control status:
ON or OFF'Active Test support data
VVT CTRL B2VVT control status:
ON or OFF'Active Test support data
VACUUM PUMP
Key±off EVAP system pump sta-
tus:
ON or OFF
'Active Test support data
EVAP VENT VAL
Key±off EVAP system vent valve
status:
ON or OFF
'Active Test support data
TC/TE1TC and TE1 terminal of DLC3:
ON or OFF''
VVTL AIM ANGL #1VVT aim angle (bank 1):
Min.: 0 %, Max.: 100 %0 %: IdlingVVT duty signal value during intru-
sive operation
VVTL AIM ANGL #2VVT aim angle (bank 1):
Min.: 0 %, Max.: 100 %0 %: IdlingVVT duty signal value during intru-
sive operation
VVT CHNG ANGL #1VVT change angle:
Min.: 0FR, Max.: 60FR0 to 5 FR: IdlingDisplacement angle during intru-
sive operation
VVT CHNG ANGL #2VVT change angle:
Min.: 0FR, Max.: 60FR0 to 5 FR: IdlingDisplacement angle during intru-
sive operation
VVT OCV DUTY B1VVT OCV operation duty:
Min.: 0 %, Max.: 100 %0 %: IdlingRequested duty value for intrusive
operation
VVT OCV DUTY B2VVT OCV operation duty:
Min.: 0 %, Max.: 100 %0 %: IdlingRequested duty value for intrusive
operation
FC IDLFuel cut idle:
ON or OFFON: Fuel cut operation
FC IDL = ºONº when throttle valve
fully closed and engine speed over
2,800 rpm

± DIAGNOSTICSBODY CONTROL SYSTEM
DI±1685
1879 Author: Date:
2005 SEQUOIA (RM1146U)
ILLUMINATED ENTRY:
DISPLAY (ITEM)DEFAULTCONTENTSSETTING
I/L ON/UNLOCKONIlluminates interior light when ignition switch is turned from
ACC to LOCK position.ON/OFF
LIGHTING TIME15SChanges lighting time after closing doors (light quickly fades
out when ignition switch is turned on).15S/7.5S/30S
LIGHT CONTROL:
DISPLAY (ITEM)DEFAULTCONTENTSSETTING
SENSITIVITYNORMALSensitivity adjustment is difficult to confirm. Check by driving
the customer's vehicle.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2
LIGHT OFF DELAY30S
Keeps headlights on for a certain period of time after closing
all doors with ignition switch on, light control switch in HEAD
or AUTO position, and headlights on.
OFF/30S/60S/90S
DISP EX ON SENNORMALChanges brightness of lights such as combination meter
indicator light, A/C indicator lamp, and clock lamp.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2
DISP OFF SENNORMALChanges brightness of lights such as combination meter
indicator light, A/C indicator lamp, and clock lamp.NORMAL/DARK2/DARK1/
LIGHT1/LIGHT2

DI1OH±18
DI±1686
± DIAGNOSTICSBODY CONTROL SYSTEM
1880 Author: Date:
2005 SEQUOIA (RM1146U)
PROBLEM SYMPTOMS TABLE
DOOR LOCK CONTROL
SymptomSuspected AreaSee page
Lock or unlock cannot be operated with door lock control switch.
1. Door lock control switch (Power source circuit)
(Driver's)
(Passenger's)
2. Body ECU
DI±1788
DI±1826
IN±35
Door key linked function does not operate.
1. Door key lock and unlock switch circuit (Driver's)
(Passenger's)
2. Body ECUDI±1794
DI±1832
IN±35
Key confinement prevention function does not operate.1. Key unlock warning switch circuit
2. Body ECUDI±1715
IN±35
Door lock function does not operate.1. Door lock motor circuit
2. Body ECUDI±1720
IN±35
THEFT DETERRENT SYSTEM
SymptomSuspected AreaSee page
No alerting condition is operated. (The system cannot be set.)
1. Security indicator circuit
2. Key unlock warning switch circuit
3. Courtesy light switch circuit
4. Door unlock detection switch circuit (Driver's)
(Passenger's)
5. Engine hood courtesy light switch circuit
6. Back door courtesy light switch circuit
7. Back door ECU
8. Body ECUDI±1731
DI±1715
DI±1728
DI±1791
DI±1829
DI±1725
DI±1864
IN±35
IN±35
Cannot be canceled when IG is turned ON with a key.
1. Key unlock warning switch circuit
2. Ignition switch
3. Body ECUDI±1715
BE±24
IN±35
Cannot be canceled when unlocking the back door with a key.1. Back door ECU
2. Body ECUIN±35
IN±35
Headlights do not light up as an alert function.1. Headlight relay circuit
2. Body ECUDI±1708
IN±35
Taillights do not light up as an alert function.1. Taillight relay circuit
2. Body ECUDI±1706
IN±35
Theft deterrent horn or vehicle horn does not sound.
1. Security horn circuit
2. Horn circuit
3. Body ECUDI±1734
DI±1764
IN±35
During warning condition, cannot be canceled by unlocking the
door with a key.1. Door key lock and unlock switch circuit (Driver's)
(Passenger's)
2. Body ECUDI±1794
DI±1832
IN±35
During warning condition, cannot be canceled by unlocking the
door with a key. (transmitter)1. Transmitter
2. Body ECUBE±99
IN±35
During warning condition, cannot be canceled by turning the igni-
tion ON with a key.1. Ignition switch
2. Key unlock warning switch circuit
3. Body ECUBE±24
DI±1715
IN±35
The system operated for more than 60 seconds.Body ECUIN±35
Glass breakage sensor does not operate.1. Glass breakage sensor circuit
2. Body ECUDI±1774
IN±35

I24144
Body ECU
MAINEngine Room J/B
HEAD Relay
Instrument Panel J/B
Battery
LG±R 2D
B12FL
R±W
12 532F
2G
2C
B7 1G 1JL
R±L
R±L
HRLY 8
6
1
6
1
2
(*1): w/ Daytime Running Light
(*2): w/o Daytime Running LightLG±R69 8 To Headlight RH To Headlight LH To DRL No.4 Relay To DIMMER Relay To DIMMER Relay
B 4
5 F10
FL Block(*2) (*2) (*1)
(*1)
(*1)
H±LP RH (*2)
DRL (*1)
H±LP LH (*2)
(*1) DI±1708
± DIAGNOSTICSBODY CONTROL SYSTEM
1902 Author: Date:
2005 SEQUOIA (RM1146U)
Headlight Relay Circuit
CIRCUIT DESCRIPTION
HEAD relay will be ºONº by operating the light control switch. The transistor which activates the HEAD relay
has two sorts: one is activated by the light control switch for fail safe and the other is activated by CPU. The
one that is activated by CPU prevents the headlight from turning off at the time of trouble with the other sys-
tem in the automatic operation circuit.
When the theft deterrent system is activated, it causes the transistor in the ECU to switch ON and OFF at
approximately 0.25 sec. intervals. This switches the HEAD relay ON and OFF, and thus flashing the head-
lights (See the wiring diagram below).
In this condition, if any of the following operations is done, the transistor in the ECU goes OFF and the HEAD
control relay switches OFF, and thus stopping the headlights flashing:
(1) Unlock the front LH or RH door with a key.
(2) Turn the ignition switch to ACC or ON position.
(3) Unlock the doors with the wireless door lock control system.
(4) Wait for approximately 60 seconds.
WIRING DIAGRAM
DI5VQ±14

± DIAGNOSTICSBODY CONTROL SYSTEM
DI±1709
1903 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
HINT:
When using the hand±held tester, start the inspection from step 1 and when not using the hand±held tester,
start from step 2.
1 Check HEAD relay using hand±held tester.
PREPARATION:
(a) Connect the hand±held tester to the DLC3.
(b) Turn the ignition switch ON.
CHECK:
According to the display on the tester, perform the ºACTIVE TESTº.
BODY ECU:
ItemTest DetailsDiagnostic Note
HEAD LIGHTHeadlight relay ON/OFF±
OK:
The headlights turn on or off correctly when operating them through the hand±held tester.
OK Proceed to next circuit inspection shown in
problem symptoms table (See page DI±1686).
NG
2 Check HEAD relay (See page BE±27).
NG Replace HEAD relay.
OK
3 Check wire harness and connector between HEAD relay and body ECU, battery
and HEAD relay (See page IN±35).
NG Repair or replace wire harness or connector.
OK
Proceed to next circuit inspection shown in
problem symptoms table
(See page DI±1686).

I18747
Body ECU
Instrument Panel J/BHEAD
TAIL
A G±Y
G
L±R (*1)B6
137 9
H
TELA
OFF
TAIL
HEAD
AUTO Light
Control
Switch
16
W±B
1B7 9
1F J8
J/C
W±B
A
IE10
14 12
(*1): w/ Automatic Light ControlB6
B6
C8
Combination Switch DI±1750
± DIAGNOSTICSBODY CONTROL SYSTEM
1944 Author: Date:
2005 SEQUOIA (RM1146U)
Light control switch circuit
CIRCUIT DESCRIPTION
The body ECU detects the light control switch position and drives the DRL No. 4 and HEAD relays.
If the vehicle is equipped with an automatic light control system, the light control switch includes the AUTO
position.
The body ECU turns the headlights ON and OFF based on the ambient light level outside the vehicle, which
is detected by the automatic light control sensor.
WIRING DIAGRAM
DI1OL±27
