Page 2873 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08Q±06 B07248 Ignition Coil (with Igniter) Connector Ignition Coil (with Igniter) N´m (kgf´cm, ft´lbf) : Specified torque 7.5 (76, 66 in.´lbf) IG±4 ± IGNITIONIGNITION COIL 2865 Author: Date

Page 2874 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08R±05 B04085 ± IGNITIONIGNITION COIL IG±5 2866 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. DISCONNECT IGNITION COIL (WITH IGNITER) CON- NECTORS 2. REMOVE IGNITION COILS (WITH IGNITER) Re

Page 2875 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG0EN±04 B04085 IG±6 ± IGNITIONIGNITION COIL 2867 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION 1. INSTALL IGNITION COILS (WITH IGNITER) Install the ignition coil (with igniter) with the bo

Page 2876 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08T±08 B17486 Drive Belt Camshaft Position Sensor Connector Grommet Engine Wire Camshaft Position Sensor Oil Cooler Pipe LH No.3 Timing Belt Cover ± IGNITIONCAMSHAFT POSITION SENSOR IG±7 2868 Aut

Page 2877 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08U±08 B17487 IG±8 ± IGNITIONCAMSHAFT POSITION SENSOR 2869 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. DRAIN ENGINE COOLANT 2. REMOVE DRIVE BELT (See page CH±7) 3. REMOVE LH NO.3 TIMING

Page 2878 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08V±06 B17487 ± IGNITIONCAMSHAFT POSITION SENSOR IG±9 2870 Author: Date: 2005 SEQUOIA (RM1146U) INSTALLATION 1. INSTALL CAMSHAFT POSITION SENSOR Install the camshaft position sensor with the

Page 2879 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08W±06 B07249N´m (kgf´cm, ft´lbf): Specified torque Crankshaft Position Sensor Engine Under Cover (2WD)Crankshaft Position Sensor Connector Engine Under Cover (4WD) x 5 6.5 (65, 58 in.´lbf) 29

Page 2880 of 4323

TOYOTA SEQUOIA 2001 Service Repair Manual IG08X±05 B07251 ± IGNITIONCRANKSHAFT POSITION SENSOR IG±11 2872 Author: Date: 2005 SEQUOIA (RM1146U) REMOVAL 1. REMOVE ENGINE UNDER COVER 2. REMOVE CRANKSHAFT POSITION SENSOR (a) Disconnect the
